PJ4054B

PJ4054B

  • 厂商:

    PJ(平晶)

  • 封装:

    SOT23-5

  • 描述:

    电池管理 5V 500μA SOT23-5

  • 数据手册
  • 价格&库存
PJ4054B 数据手册
Description PJ4054B Linear Lithium-ion Battery Charger PJ4054B is a complete single lithium ion battery with constant current/constant voltage linear charger. Its SOT package and small number of external components make the PJ4054B ideal for portable applications.PJ4054B can be suitable for USB power and adapter power supply work. Due to the internal PMOSFET architecture, plus the anti-inverted charging circuit, there is no need for external detection resistor and isolation diode. Thermal feedback adjusts the charging current to limit chip temperature at high power operation or ambient temperature conditions.The charging voltage is fixed at 4.2V, and the charging current can be set externally through a resistor. When the charging current reaches the final floating charging voltage and drops to the set value of 1/10,PJ4054B will automatically terminate the charging cycle. When the input voltage (ac adapter or USB power supply) is removed, PJ4054B automatically enters a low current state, reducing the battery leakage current below 1uA.PJ4054B can also be placed in stop mode to reduce the power supply current to 25uA.Other features of the PJ4054B include a charging current monitor, undervoltage latching, automatic recharging, and a status pin to indicate the end of charging and input voltage access. Features  500mA programmable charging current;  No MOSFET, test resistor or isolation diode required;  A complete linear charger with SOT-23-5 package for single lithium ion battery;  Constant current/voltage operation, with thermal regulation function;  Charge single lithium ion battery directly from USB port;  4.2V charging voltage is preset;  Output of charging current monitor for battery quantity detection;  1/10 Charge termination, automatic recharging;  Power supply current in standby mode is 25uA;  Soft boot limits the surge current;  2.9V trickle charge device version Applications Rprog resistance and charging current Ibat corresponding table Rprog Ibat Ibat=1000/Rprog www.pingjingsemi.com Revision:1.0 May-2019 10K 100mA 5K 200mA 3.3K 300mA 2.5K 400mA 2K 500mA 1.65K 600mA 1/6 PJ4054B Linear Lithium-ion Battery Charger Pin Distribution SOT-23-5 4.VCC 5.PROG 1.CHRG 2.GND 3.BAT Pin Function CHRG(Pin1) Output of open drain charging state. The CHRG pin is pulled to low level by an internal N-channel MOSFET during battery charging. When the charging cycle ends, CHRG pin is off and all lights are off. When PJ4054B detects an under voltage blocking condition, the CHRG pin is forced to a high impedance state. GND(Pin2) GND BAT(Pin3) Charging current output.The pin provides charging current to the battery and adjusts the final floating charging voltage to 4.2V. A precise internal resistance voltage divider of the pin sets the floating charging voltage. In the shutdown mode, the internal resistance voltage divider is disconnected. VCC(Pin4) PROG(Pin5) www.pingjingsemi.com Revision:1.0 May-2019 Positive input power voltage.This pin supplies power to the charger.VCC shall vary from 4.25V to 6.5V and shall be bypassed by at least one 1uF capacitor.When the VCC drops to less than 30mV of BAT pin voltage,PJ4054B enters the stop mode, and the Ibat falls below 2uA. Charging current setting, charging current monitoring and stop pin.The charging current can be set by connecting a 1% precision resistor Pprog between the pin and the ground.When charging in constant current mode, the voltage of this pin is maintained at 1V. In all modes, the voltage on this pin can be used to calculate the charging current. The formula is Ibat=(Vprog/Rprog)*1000.Short connect the set resistor to the ground, and an internal 2.5uA current pulls the PROG pin to a high level.When the voltage of this pin reaches the stop threshold voltage of 1.21V, the charger enters the stop mode, the charging stops and the input power current drops to 25uA.Reconnecting the Rprog to the ground will restore the charger to normal operation. 2/6 PJ4054B Linear Lithium-ion Battery Charger Absolute Maximum Rating Input Voltage VSS-0.3V~VSS+7V PROG VSS-0.3V~VSS+0.3V BAT VSS-0.3V~VSS+7V CHRG VSS-0.3V~VSS+10V BAT short-circuit period Continue BAT Pin Current 500mA PROG Pin Current 800uA -40℃~85℃ Operating Temperature Range Storage Temperature -65℃~125℃ Pin temperature (welding time: 10s) 260℃ Block Diagram 4 VCC 120℃ TA TDIE 1X 1000X BAT 5μA MA 3 R1 VA CA SHDN R2 C1 REF 1.21V R3 1V R4 1 0.1V C2 CHRG R5 STANDBY 3μA C3 TO BAT 2.9V VCC 5 www.pingjingsemi.com Revision:1.0 May-2019 GND PROG RPROG 2 3/6 PJ4054B Linear Lithium-ion Battery Charger Electrical Characteristics (TA =25℃ unless otherwise specified.) Parameter Symbol Input Voltage VCC Input Current ICC Min. Typ. 4.2 charging mode,Rprog=10K 5 300 standby mode(Charge termination) 50 150 25 50 Test Condition stop mode(RPROG ununited) VCC
PJ4054B 价格&库存

很抱歉,暂时无法提供与“PJ4054B”相匹配的价格&库存,您可以联系我们找货

免费人工找货
PJ4054B
    •  国内价格
    • 50+0.14060
    • 500+0.12635
    • 5000+0.11685
    • 10000+0.11210
    • 30000+0.10735
    • 50000+0.10450

    库存:2990
