BZT55C20

BZT55C2V4 - BZT55C75 Taiwan Semiconductor 500mW, 5% Tolerance Zener Diodes FEATURES KEY PARAMETERS ● Wide zener voltage range selection: 2.4V to 75V ● VZ tolerance selection of ± 5% ● Compliant to RoHS directive 2011/65/EU and in accordance to WEEE 2002/96/EC ● Halogen-free according to IEC 61249-2-21 PARAMETER VALUE UNIT VZ 2.4-75 V PD 500 mW VF at IF=10mA 1 V TJ Max. Package APPLICATIONS ● ● ● ● Configuration Low voltage stabilizers or voltage references Adapters Lighting application On-board DC/DC converter 175 °C Quadro MiniMELF (LS34) Single die MECHANICAL DATA ● ● ● ● Case: Quadro Mini-MELF (LS34) Terminal: Matte tin plated leads, solderable per J-STD-002 Polarity: Indicated by cathode band Weight: 29 ± 2.5mg ABSOLUTE MAXIMUM RATINGS (TA = 25°C unless otherwise noted) PARAMETER Forward voltage @ IF=10mA SYMBOL VALUE UNIT VF 1 V Power dissipation PD 500 mW Junction temperature range TJ -65 to +175 °C Storage temperature range TSTG -65 to +175 °C SYMBOL TYP UNIT RӨJA 500 °C/W THERMAL PERFORMANCE PARAMETER Junction-to-ambient thermal resistance 1 Version: G1804 BZT55C2V4 - BZT55C75 Taiwan Semiconductor ELECTRICAL SPECIFICATIONS (TA = 25°C unless otherwise noted) ZENER VOLTAGE PART NUMBER TEST REGULAR TEST CURRENT IMPEDANCE CURRENT VZ @ IZT IZT ZZT @ IZT ZZK @ IZK IZK V mA Ω Ω mA LEAKAGE CURRENT IR @ V R µA V Min. Nom. Max. Max. Max. BZT55C2V4 2.4 2.28 2.56 5 85 600 1 50 1 BZT55C2V7 2.7 2.51 2.89 5 85 600 1 10 1 BZT55C3V0 3.0 2.8 3.2 5 85 600 1 4 1 BZT55C3V3 3.3 3.1 3.5 5 85 600 1 2 1 BZT55C3V6 3.6 3.4 3.8 5 85 600 1 2 1 BZT55C3V9 3.9 3.7 4.1 5 85 600 1 2 1 BZT55C4V3 4.3 4.0 4.6 5 75 600 1 1 1 BZT55C4V7 4.7 4.4 5.0 5 60 600 1 0.5 1 BZT55C5V1 5.1 4.8 5.4 5 35 550 1 0.1 1 BZT55C5V6 5.6 5.2 6.0 5 25 450 1 0.1 1 BZT55C6V2 6.2 5.8 6.6 5 10 200 1 0.1 2 BZT55C6V8 6.8 6.4 7.2 5 8 150 1 0.1 3 BZT55C7V5 7.5 7.0 7.9 5 7 50 1 0.1 5 BZT55C8V2 8.2 7.7 8.7 5 7 50 1 0.1 6.2 BZT55C9V1 9.1 8.5 9.6 5 10 50 1 0.1 6.8 BZT55C10 10 9.4 10.6 5 15 70 1 0.1 7.5 BZT55C11 11 10.4 11.6 5 20 70 1 0.1 8.2 BZT55C12 12 11.4 12.7 5 20 90 1 0.1 9.1 BZT55C13 13 12.4 14.1 5 26 110 1 0.1 10 BZT55C15 15 13.8 15.6 5 30 110 1 0.1 11 BZT55C16 16 15.3 17.1 5 40 170 1 0.1 12 BZT55C18 18 16.8 19.1 5 50 170 1 0.1 13 BZT55C20 20 18.8 21.1 5 55 220 1 0.1 15 BZT55C22 22 20.8 23.3 5 55 220 1 0.1 16 BZT55C24 24 22.8 25.6 5 80 220 1 0.1 18 BZT55C27 27 25.1 28.9 5 80 220 1 0.1 20 BZT55C30 30 28 32 5 80 220 1 0.1 22 BZT55C33 33 31 35 5 80 220 1 0.1 24 BZT55C36 36 34 38 5 80 220 1 0.1 27 BZT55C39 39 37 41 2.5 90 500 0.5 0.1 28 BZT55C43 43 40 46 2.5 90 600 0.5 0.1 32 BZT55C47 47 44 50 2.5 110 700 0.5 0.1 35 BZT55C51 51 48 54 2.5 125 700 0.5 0.1 38 BZT55C56 56 52 60 2.5 135 1,000 0.5 0.1 42 BZT55C62 62 58 66 2.5 150 1,000 0.5 0.1 47 BZT55C68 68 64 72 2.5 160 1,000 0.5 0.1 51 BZT55C75 75 70 79 2.5 170 1,000 0.5 0.1 56 2 Max. Version: G1804 BZT55C2V4 - BZT55C75 Taiwan Semiconductor Notes: 1. The zener voltage (VZ) is tested under pulse condition of 30ms 2. The device numbers listed have a standard tolerance on the nomial zener voltage of ±5% 3. For detailed information on price, availability and delivery of nominal zener voltages between the voltages shown and tighter voltage tolerances, contact your nearest Taiwan Semiconductor representative 4. The zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an rms value equal to 10% of the DC zener current(IZT or IZK) is superimposed to IZT or IZK ORDERING INFORMATION PART NO. (Note) PACKAGE PACKING BZT55Cxxx L0 Quadro Mini-MELF 10K / 13" Reel BZT55Cxxx L0G Quadro Mini-MELF 10K / 13" Reel BZT55Cxxx L1 Quadro Mini-MELF 2.5K / 7" Reel BZT55Cxxx L1G Quadro Mini-MELF 2.5K / 7" Reel Note: "xxx" defines voltage from 2.4V (BZT55C2V4) to 75V (BZT55C75) 3 Version: G1804 BZT55C2V4 - BZT55C75 Taiwan Semiconductor CHARACTERISTICS CURVES (TA = 25°C unless otherwise noted) Fig. 1 Typical Forward Characteristics Fig. 2 Admissible Power Dissipation Curve 600 500 TA=25oC Power Dissipation (mW) Forward Current (mA) 1000 100 10 400 300 200 100 0 1 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 0 1.2 50 100 150 200 Ambient Temperature (oC) Forward Voltage (V) Fig. 3 Typical Capacitance 1000 Capacitance (pF) 100 1V Bias 10 Bias at 50% of VZ (Nom) 1 1 10 100 Zener Voltage (V) 4 Version: G1804 BZT55C2V4 - BZT55C75 Taiwan Semiconductor PACKAGE OUTLINE DIMENSION Quadro Mini-MELF Unit (mm) DIM. Unit (inch) Min Max Min Max A 3.30 3.70 0.130 0.146 B 1.40 1.60 0.055 0.063 C 0.20 0.45 0.008 0.018 D 1.8 TYP. 0.071 TYP. SUGGEST PAD LAYOUT Unit (mm) Unit (inch) Typ. Typ. A 1.25 0.049 B 2.00 0.079 C 2.50 0.098 D 5.00 0.197 DIM. 5 Version: G1804 BZT55C2V4 - BZT55C75 Taiwan Semiconductor Notice Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf, assumes no responsibility or liability for any errors or inaccuracies. Information contained herein is intended to provide a product description only. No license, express or implied, to any intellectual property rights is granted by this document. Except as provided in TSC’s terms and conditions of sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications. Customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify TSC for any damages resulting from such improper use or sale. 6 Version: G1804 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Taiwan Semiconductor: BZT55C10 BZT55C11 BZT55C12 BZT55C13 BZT55C15 BZT55C16 BZT55C18 BZT55C20 BZT55C22 BZT55C24 BZT55C27 BZT55C2V0 BZT55C2V2 BZT55C2V4 BZT55C2V7 BZT55C30 BZT55C33 BZT55C36 BZT55C39 BZT55C3V0 BZT55C3V3 BZT55C3V6 BZT55C3V9 BZT55C43 BZT55C47 BZT55C4V3 BZT55C4V7 BZT55C51 BZT55C56 BZT55C5V1 BZT55C5V6 BZT55C62 BZT55C68 BZT55C6V2 BZT55C6V8 BZT55C75 BZT55C7V5 BZT55C8V2 BZT55C9V1 BZT55C11 L1G BZT55C3V0 L1G BZT55C24 L1G BZT55C3V9 L1G BZT55C13 L1G BZT55C39 L1G BZT55C7V5 L1G BZT55C75 L1G BZT55C3V3 L1G BZT55C15 L1G BZT55C4V7 L1G BZT55C62 L1G BZT55C68 L1G BZT55C22 L1G BZT55C2V4 L1G BZT55C33 L1G BZT55C2V7 L1G BZT55C12 L1G BZT55C5V6 L1G BZT55C5V1 L1G BZT55C56 L1G BZT55C20 L1G BZT55C6V2 L1G BZT55C27 L1G BZT55C43 L1G BZT55C3V6 L1G BZT55C47 L1G BZT55C10 L1G BZT55C51 L1G BZT55C6V8 L1G BZT55C9V1 L1G BZT55C4V3 L1G BZT55C36 L1G BZT55C8V2 L1G BZT55C16 L1G BZT55C18 L1G BZT55C30 L1G BZT55C11 L1 BZT55C20 L1 BZT55C3V6 L1 BZT55C36 L1 BZT55C15 L1 BZT55C62 L1 BZT55C6V2 L1 BZT55C56 L1 BZT55C6V8 L1 BZT55C9V1 L1 BZT55C47 L1 BZT55C2V7 L1 BZT55C22 L1 BZT55C43 L1 BZT55C33 L1 BZT55C68 L1 BZT55C10 L1 BZT55C30 L1 BZT55C16 L1 BZT55C5V6 L1 BZT55C51 L1 BZT55C3V3 L1 BZT55C27 L1 BZT55C75 L1
