Confidential Degree：Confidential SPL06-007 Digital pressure sensor Pb-free, halogen-free and RoHS compliant Version1.0 Confidential in Goertek, shall not be spread if not be privileged Page 1 / 37 Confidential Degree：Confidential Restricted 1. Security warning The information contained in this document is the exclusive property of GoerTek Inc. and should not be disclosed to any third party without the written consent of GoerTek Inc. 2. Publication history Version Date Description Author Approved 1.0 2017.5.17 New design Bruno Sammy Version1.0 Confidential in Goertek, shall not be spread if not be privileged Page 2 / 37 Confidential Degree：Confidential Index of Contents 1. INTRODUCTION ........................................................................................................................................................5 2. TEST CONDITION .....................................................................................................................................................6 3. ABSOLUTE MAXIMUM RATINGS ...........................................................................................................................6 4. ELECTRICAL CHARACTERISTICS ........................................................................................................................6 5. OPERATION ...............................................................................................................................................................8 6. 5.1 OPERATING MODES..................................................................................................................................................... 8 5.2 MEASUREMENT PRECISION AND RATE........................................................................................................................ 8 5.3 SENSOR INTERFACE .................................................................................................................................................... 9 5.3.1 I2C interface ...................................................................................................................................................... 9 5.3.2 SPI interface .................................................................................................................................................... 10 5.4 INTERRUPT................................................................................................................................................................. 11 5.5 FIFO OPERATION ...................................................................................................................................................... 11 5.6 CALIBRATION AND MEASUREMENT COMPENSATION ................................................................................................. 12 5.6.1 How to Calculate Compensated Pressure Values ................................................................................ 12 5.6.2 How to Calculate Compensated Temperature Values .............................................................................. 13 5.6.3 Compensation Scale Factors ........................................................................................................................ 13 APPLICATIONS........................................................................................................................................................ 14 6.1 MEASUREMENT SETTINGS AND USE CASE EXAMPLES ............................................................................................ 14 6.2 APPLICATION CIRCUIT EXAMPLE ............................................................................................................................... 15 6.3 CALCULATING ABSOLUTE ALTITUDE AND CALCULATING PRESSURE AT SEA LEVEL .................................................... 16 7. REGISTER MAP ....................................................................................................................................................... 17 8. REGISTER DESCRIPTION ..................................................................................................................................... 18 8.1 PRESSURE DATA (PRS_BN) ..................................................................................................................................... 18 8.1.1 PRS_B2 ........................................................................................................................................................... 18 8.1.2 PRS_B1 ........................................................................................................................................................... 18 8.1.3 PRS_B0 ........................................................................................................................................................... 19 8.2 TEMPERATURE DATA (TMP_TN)............................................................................................................................... 19 8.2.1 TMP_B2 ........................................................................................................................................................... 19 8.2.2 TMP_B1 ........................................................................................................................................................... 20 8.2.3 TMP_B0 ........................................................................................................................................................... 20 8.3 PRESSURE CONFIGURATION (PRS_CFG) ............................................................................................................... 20 8.4 TEMPERATURE CONFIGURATION (TMP_CFG) ........................................................................................................ 22 8.5 SENSOR OPERATING MODE AND STATUS (MEAS_CFG) .................................................................................... 23 8.6 INTERRUPT AND FIFO CONFIGURATION (CFG_REG) ............................................................................................. 24 8.7 INTERRUPT STATUS (INT_STS) ............................................................................................................................... 26 8.8 FIFO STATUS (FIFO_STS) ...................................................................................................................................... 26 Version1.0 Confidential in Goertek, shall not be spread if not be privileged Page 3 / 37 Confidential Degree：Confidential 8.9 SOFT RESET AND FIFO FLUSH (RESET) ................................................................................................................. 27 8.10 PRODUCT AND REVISION ID (ID) .............................................................................................................................. 27 8.11 CALIBRATION COEFFICIENTS (COEF) ...................................................................................................................... 28 MECHANICAL CHARACTERISTICS ..................................................................................................................... 29 9. 9.1 PIN CONFIGURATION .................................................................................................................................................. 29 9.2 OUTLINE DIMENSIONS................................................................................................................................................ 30 9.3 MARKING AND 2D BARCODE ..................................................................................................................................... 32 10. STORAGE AND TRANSPORTATION ................................................................................................................ 32 11. SOLDERING RECOMMENDATION ................................................................................................................... 33 12. PACKAGE SPECIFICATIONS ............................................................................................................................ 33 13. RELIABILITY SPECIFICATIONS........................................................................................................................ 37 Version1.0 Confidential in Goertek, shall not be spread if not be privileged Page 4 / 37 Confidential Degree：Confidential 1. Introduction The SPL06-007 is a miniaturized Digital Barometric Air Pressure Sensor with a high accuracy and a low current consumption. The SPL06-007 is both a pressure and a temperature sensor. The pressure sensor element is based on a capacitive sensing principle which guarantees a high precision during temperature changes. The small package makes the SPL06-007 ideal for mobile applications and wearable devices. The SPL06-007‘s internal signal processor converts the output from the pressure and temperature sensor elements to 24-bit results. Each pressure sensor has been calibrated individually and contains calibration coefficients. The coefficients are used in the application to convert the measurement results to true pressure and temperature values. The SPL06-007 has a FIFO that can store the latest 32 measurements. By using the FIFO, the host processor can remain in a sleep mode for a longer period of time between readouts. This can reduce the overall system power consumption. Sensor measurements and calibration coefficients are available through the serial I2C interface. Key features  Pressure range: 300 ... 1100hPa (+9000m ... -500m relating to sea level)  Temperature Range: -40…+85°C  Supply voltage: 1.7 ... 3.6V (VDD), 1.2 ... 3.6V (VDDIO)  Package: LGA package with metal lid Small footprint: 2.5mm x 2.0mm; Super-flat: 0.95mm height  Relative accuracy: ±0.06hPa, equiv. to ±0.5 m  Absolute accuracy: typ. ±1hPa (300 … 1100hPa)  Temperature accuracy: ± 0.5°C.  Pressure temperature sensitivity: < 0.5Pa/K    Measurement time: Typical: 28 ms. Minimum: 3 ms. Average current consumption: High precision: 60 µA, Low power: 3 µA, Standby:
