SHENZHEN ORIENT TECHNOLOGY CO., LTD DATA SHEET ● DEVICE NUMBER：ORH-W46G (For: 客户) SHEET DATE 2010.07.10 1 2 3 4 5 6 7 8 9 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 CONTENTS Original Released 深圳市奥伦德科技有限公司 SHENZHEN ORIENT TECHNOLOGY CO. ,LTD. 深圳市宝安区西乡鹤洲鸿图工业园 1 栋 Block 1,Hongtu industry Park,Hezhou,xixiang Town,Baoan district, Shenzhen,P.R.C Tel: 0755-29681816 29980591 Fax: 0755-29681200 E-Mail:saleselec@ orient-opto.com salesdev@ orient-opto.com www.orient-opto.com. SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G ● Features: 1. Emitted Color : White ●Package Dimensions: 2. Mono-color type. 3. 1.6x0.8x0.4mm(0603) standard package 4. Suitable for all SMT assembly methods. 5. Compatible with infrared and vapor phase reflow solder process. 6. Compatible with automatic placement equipment. 7. This product doesn’t contain restriction Substance, comply ROHS standard. ● Applications: 1. Automotive : Dashboards, stop lamps, turn signals. 2. Backlighting : LCDs, Key pads advertising. 3. Status indicators : Comsumer & industrial NOTES: 1.All dimensions are in millimeters (inches). 2.Tolerance is ± 0.10mm (0.004”) unless otherwise specified. 3.Specifications are subject to change without notice. electronics. 4. General use. ● Absolute Maximum Ratings(Ta=25℃) Parameter Symbol Rating Unit Power Dissipation Pd 120 mW Forward Current IF 30 mA Peak Forward Current ＊1 IFP 100 mA Reverse Volage VR 5 V Operating Temperature Topr -40℃~85℃ - Storage Temperature Tstg -40℃~85℃ - Soldering Temperature Tsol See Page 8 - ＊1 Condition for IFp is pulse of 1/10 duty and 0.1msec width. Ver.1.0 Page 1 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G ● Electrical and optical characteristics(Ta=25℃) Parameter Symbol Condition Min. Typ. Max. Unit 2.8 3.2 V Forward Voltage Vf IF=5mA Luminous Intensity Iv IF=5mA 42 90 - mcd Reverse Current IR VR=5V - - 1 μA Chromaticity x IF=5mA - 0.30 - - Coordinates y IF=5mA - 0.28 - - Veiwing Angle 2θ1/2 IF=5mA - 120 - deg ● Typical Electro-Optical Characteristics Curves Fig.2 Forward current derating curve vs. ambient temperature Fig.1 Relative intensity vs. wavelength 60 50 Forward current (mA) Relative radiant intensity 1.0 0.5 0 350 400 450 500 550 600 650 700 750 40 30 20 10 800 0 Wavelength (nm) 60 80 100 3.0 2.5 30 20 10 (Normalized @20mA) Relative Luminous intensity 40 Forward current (mA) 40 Fig.4 Relative luminous intensity vs. ambient temperature Fig.3 Forward current vs. forward voltage 50 0 20 Ambient temperature Ta( C) 2.0 1.5 1.0 0.5 1 2 3 4 0 -40 5 -20 Forward voltage(V) 0 20 40 60 Ambient temperature Ta( C) Fig.5 Relative luminous intensity vs. forward current Fig.6 Radiation diagram 0 2.0 10 20 1.5 Relative radiant intensity Relative luminous intensity (@20mA) 30 1.0 0.5 1.0 40 0.9 50 0.8 60 70 0.7 80 90 0 10 20 30 40 50 0.5 0.3 0.1 0.2 0.4 0.6 Forward current (mA) Ver.1.0 Page 2 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G ● Tapping and packaging specifications(Units: mm) USER DIRECTION OF FEED 13.0 ∮0.5 0.5 ∮0.05 4.0∮0.1 1.5!O0.1 4.0∮0.1 2.0!O0.05 TRAILER 179 ∮1 13.0∮0.5 71.0∮1 1.75∮0.05 8.0∮0.3 CATHODE 3.5∮0.05 5.3∮0.05 END 1.75 ∮0.1 ANODE 0.9 ∮0.05 START LEADER 0.3 FIXING TAPE NOTE: 3000 pcs PER REEL ●Package Method:(unit:mm) Vacuum ● Bin Limits I n t e n s i t y B i n L i m i ts ( A t 5 m A ) BIN CODE Min. (mcd) Max. (mcd) P 63 94 Q 94 140 R 140 210 To l e r a n c e f o r e a c h B i n l i m i t i s ± 1 5 % Ver.1.0 Page 3 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G V F B i n L i m i ts ( A t 5 m A ) BIN CODE Min.(v) Max.(v) F1 2.6 2.7 F2 2.7 2.8 G1 2.8 2.9 G2 2.9 3.0 H1 3.0 3.1 H2 3.1 3.2 To l e r a n c e f o r e a c h B i n l i m i t i s ± 0 . 0 5 V ● B IN： x x x VF BIN CODE Color BIN CODE Intensity BIN CODE y 4-7 4-6 4-5 4-4 4-3 4-2 4-1 5-7 5-6 5-5 5-4 5-3 5-2 5-1 6-7 6-6 6-5 6-4 6-3 6-2 6-1 x Ver.1.0 Page 4 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G C o l o r B i n L i m i ts ( A t 5 m A ) BIN 3-3 3-4 3-5 3-6 3-7 3-8 3-9 4-3 4-4 4-5 4-6 4-7 4-8 4-9 5-3 5-4 5-5 5-6 5-7 5-8 5-9 x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y x y 0.265 0.200 0.265 0.210 0.265 0.220 0.265 0.230 0.265 0.240 0.265 0.250 0.265 0.260 0.305 0.240 0.305 0.250 0.305 0.260 0.305 0.270 0.305 0.280 0.305 0.290 0.305 0.300 0.345 0.280 0.345 0.290 0.345 0.300 0.345 0.310 0.345 0.320 0.345 0.330 0.345 0.340 Chromaticity Coordinates 0.225 0.200 0.225 0.210 0.225 0.220 0.225 0.230 0.225 0.240 0.225 0.250 0.225 0.260 0.265 0.240 0.265 0.250 0.265 0.260 0.265 0.270 0.265 0.280 0.265 0.290 0.265 0.300 0.305 0.280 0.305 0.290 0.305 0.300 0.308 0.310 0.305 0.320 0.305 0.330 0.305 0.340 0.225 0.210 0.225 0.220 0.225 0.230 0.225 0.240 0.225 0.250 0.225 0.260 0.225 0.270 0.265 0.250 0.265 0.260 0.265 0.270 0.265 0.280 0.265 0.290 0.265 0.300 0.265 0.310 0.305 0.290 0.305 0.300 0.305 0.310 0.305 0.320 0.305 0.330 0.305 0.340 0.305 0.350 0.265 0.210 0.265 0.220 0.265 0.230 0.265 0.240 0.265 0.250 0.265 0.260 0.265 0.270 0.305 0.250 0.305 0.260 0.305 0.270 0.305 0.280 0.305 0.290 0.305 0.300 0.305 0.310 0.345 0.290 0.345 0.300 0.345 0.310 0.345 0.320 0.345 0.330 0.345 0.340 0.345 0.350 Ver.1.0 Page 5 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G ● Reliability Test Classification Test Item Reference Standard Operation Life MIL-STD-750D:1026 MIL-STD-883D:1005 JIS-C-7021 :B-1 High Temperature MIL-STD-202F:103B High Humidity JIS-C-7021 :B-11 Endurance Storage Test High MIL-STD-883:1008 Temperature JIS-C-7021 :B-10 Storage Low Temperature JIS-C-7021 :B-11 Storage Temperature MIL-STD-202F:107D Cycling MIL-STD-750D:1051 MIL-STD-883D:1010 JIS-C-7021 :A-2 Thermal Shock MIL-STD-202F:107D Environmental MIL-STD-750D:1051 Test MIL-STD-883D:1011 Solder MIL-STD-202:201A Resistance MIL-STD-750:2031 JIS-C-7021 :A-1 Test Conditions Connect with a power If=5mA Ta=Under room temperature Test time=1,000hrs Ta=+85℃±5℃ RH=90%-95% Test time=240hrs Result 0/20 0/20 High Ta=+100℃±5℃ Test time=1,000hrs 0/20 Low Ta=-40℃±5℃ Test time=1,000hrs 0/20 -35℃ ~ +25℃ ~ +85℃ ~ +25℃ 30min 5min 30min 5min Test Time=10cycle -40℃±5℃ ~+85℃±5℃ 20min 20min Test Time=10cycle Preheating： 140℃-160℃,within 2 minutes. Operation heating： 260℃(Max.), within 10seconds. (Max.) 0/20 0/20 0/20 ● Judgment criteria of failure for the reliability Measuring items Forward voltage Reverse current Luminous intensity Note: Symbol VF ( V) IR(uA) Iv ( mcd ) Measuring conditions IF=5mA VR=5V IF=5mA 1.U means the upper limit of specified characteristics. Judgement criteria for failure Initial Level*1.1 Over Ux2 Initial Level*0.7 S means initial value. 2.Measurment shall be taken between 2 hours and after the test pieces have been returned to normal ambient conditions after completion of each test. Ver.1.0 Page 6 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G ● Soldering : 1. Manual Of Soldering The temperature of the iron tip should not be higher than 300℃(572℉) and Soldering within 3 seconds per solder-land is to be observed. 2. Reflow Soldering Preheating : 140℃~160℃±5℃,within 2 minutes. Operation heating : 260℃(Max.) within 10 seconds.(Max) Gradual Cooling (Avoid quenching). 10 SEC. MAX. Temperature 140~160℃ 260℃ MAX. 4℃ /SEC. MAX. 4℃ /SEC. MAX. OVER 2 MIN. Time 3. DIP soldering (Wave Soldering) : Preheating : 120℃~150℃,within 120~180 sec. Operation heating : 245℃±5℃ within 5 sec.260℃ (Max) Gradual Cooling (Avoid quenching). Temperature Soldering heat Max. 260 ℃ 245 ±5℃ within 5 sec. 120~150℃ Preheat 120~180 sec. Time ● Handling : Care must be taken not to cause to the epoxy resin portion of ORIENT leds while it is exposed to high temperature. Care must be taken not rub the epoxy resin portion of ORIENT leds with hard or sharp article such as the sand blast and the metal hook. Ver.1.0 Page 7 of 8 SHENZHEN ORIENT TECHNOLOGY CO., LTD ORH-W46G ● Notes for designing: Care must be taken to provide the current limiting resistor in the circuit so as to drive the ORIENT leds within the rated figures. Also, caution should be taken not to overload ORIENT leds with instantaneous voltage at the turning ON and OFF of the circuit. When using the pulse drive care must be taken to keep the average current within the rated figures. Also, the circuit should be designed so as be subjected to reverse voltage when turning off the bright ORIENT leds. ● Storage: In order to avoid the absorption of moisture, it is recommended to solder ORIENT leds as soon as possible after unpacking the sealed envelope. If the envelope is still packed, to store it in the environment as following: (1) Temperature : 5℃-30℃(41℉)Humidity : RH 60﹪Max. (2) After this bag is opened, devices that will be applied to infrared reflow, vapor-phase reflow, or equivalent soldering process must be: a. Completed within 168 hours. b. Stored at less than 30% RH. (3) Devices require baking before mounting, if: (2) a or (2) b is not met. (4) If baking is required, devices must be baked under below conditions: 48hours at 60℃±3℃. ● Package and Label of Products: (1) Package: Products are packed in one bag of 4000 pcs (one taping reel) and a label is attached on each bag. (2) Label: ORIENT LOGO Part No. Quantity BIN Sealing Date x xx xx xx Year Month Day Manufacture Location Ver.1.0 Page 8 of 8
