IP4283CZ10-TBR,115

Important notice Dear Customer, On 7 February 2017 the former NXP Standard Product business became a new company with the tradename Nexperia. Nexperia is an industry leading supplier of Discrete, Logic and PowerMOS semiconductors with its focus on the automotive, industrial, computing, consumer and wearable application markets In data sheets and application notes which still contain NXP or Philips Semiconductors references, use the references to Nexperia, as shown below. Instead of http://www.nxp.com, http://www.philips.com/ or http://www.semiconductors.philips.com/, use http://www.nexperia.com Instead of sales.addresses@www.nxp.com or sales.addresses@www.semiconductors.philips.com, use salesaddresses@nexperia.com (email) Replace the copyright notice at the bottom of each page or elsewhere in the document, depending on the version, as shown below: - © NXP N.V. (year). All rights reserved or © Koninklijke Philips Electronics N.V. (year). All rights reserved Should be replaced with: - © Nexperia B.V. (year). All rights reserved. If you have any questions related to the data sheet, please contact our nearest sales office via e-mail or telephone (details via salesaddresses@nexperia.com). Thank you for your cooperation and understanding, Kind regards, Team Nexperia IP4283CZ10 series ESD protection for ultra high-speed interfaces Rev. 4 — 8 April 2013 Product data sheet 1. Product profile 1.1 General description The devices are designed to protect high-speed interfaces such as High-Definition Multimedia Interface (HDMI), DisplayPort, external Serial Advanced Technology Attachment (eSATA) and Low-Voltage Differential Signaling (LVDS) interfaces against ElectroStatic Discharge (ESD). The devices include four high-level ESD protection diode structures for ultra high-speed signal lines. They are available in three package variants: DFN2510-10 (SOT1165-1), DFN2510A-10 (SOT1176-1) and TSSOP10 (SOT552-1). All signal lines are protected by a special diode configuration offering ultra low line capacitance of only 0.6 pF. These diodes provide protection to downstream components from ESD voltages up to 8 kV contact according to IEC 61000-4-2, level 4. 1.2 Features and benefits  System ESD protection for HDMI, DisplayPort, eSATA and LVDS  All signal lines with integrated rail-to-rail clamping diodes for downstream ESD protection of 8 kV according to IEC 61000-4-2, level 4  Matched 0.5 mm trace spacing  Signal lines with  0.05 pF matching capacitance between signal pairs  Line capacitance of only 0.6 pF for each channel  Design-friendly ‘pass-thru’ signal routing 1.3 Applications The devices are designed for high-speed receiver and transmitter port protection:  TVs, monitors  DVD recorders and players  Notebooks, main board graphics cards and ports  Set-top boxes and game consoles IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 2. Pinning information Table 1. Pin Pinning Symbol Description Simplified outline Graphic symbol IP4283CZ10-TBA (SOT1165-1) 1 2 TMDS_CH1 TMDS_CH1+ negative channel 1 ESD protection positive channel 1 ESD protection 3 GND ground 4 TMDS_CH2 negative channel 2 ESD protection 5 TMDS_CH2+ positive channel 2 ESD protection 6 n.c. not connected 7 n.c. not connected 8 GND ground 9 n.c. not connected 10 n.c. not connected 10 9 8 7 6 1 2 3 4 5 1 2 4 5 Transparent top view DFN2510-10 3, 8 001aai619 IP4283CZ10-TBR (SOT1176-1) 1 IP4283CZ10_SER Product data sheet TMDS_CH1 negative channel 1 ESD protection 2 TMDS_CH1+ positive channel 1 ESD protection 3 GND ground 4 TMDS_CH2 negative channel 2 ESD protection 5 TMDS_CH2+ positive channel 2 ESD protection 6 n.c. not connected 7 n.c. not connected 8 GND ground 9 n.c. not connected 10 n.c. not connected 10 8 7 6 1 2 4 5 1 2 3 4 5 Transparent top view DFN2510A-10 All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 9 3, 8 001aai619 © NXP B.V. 2013. All rights reserved. 2 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces Table 1. Pin Pinning …continued Symbol Description Simplified outline Graphic symbol IP4283CZ10-TT (SOT552-1) 1 TMDS_CH1 negative channel 1 ESD protection 2 TMDS_CH1+ positive channel 1 ESD protection 3 GND ground 4 TMDS_CH2 negative channel 2 ESD protection 5 TMDS_CH2+ positive channel 2 ESD protection 6 n.c. not connected 7 n.c. not connected 8 GND ground 9 n.c. not connected 10 n.c. not connected 10 6 1 2 4 3, 8 1 5 001aai619 5 TSSOP10 3. Ordering information Table 2. Ordering information Type number Package IP4283CZ10-TBA Name Description Version DFN2510-10 plastic extremely thin small outline package; SOT1165-1 no leads; 10 terminals; body 1  2.5  0.5 mm IP4283CZ10-TBR DFN2510A-10 plastic extremely thin small outline package; SOT1176-1 no leads; 10 terminals; body 1  2.5  0.5 mm IP4283CZ10-TT plastic thin shrink small outline package; 10 leads; body width 3 mm TSSOP10 SOT552-1 4. Marking Table 3. IP4283CZ10_SER Product data sheet Marking codes Type number Marking code IP4283CZ10-TBA 83 IP4283CZ10-TBR 83 IP4283CZ10-TT 4283 All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 3 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 5. Limiting values Table 4. Limiting values In accordance with the Absolute Maximum Rating System (IEC 60134). Symbol Parameter VI input voltage VESD Conditions electrostatic discharge voltage Min Max Unit 0.5 +5.5 V contact discharge 8 8 kV air discharge 15 15 kV IEC 61000-4-2, level 4 [1] Tstg storage temperature 55 +125 C Tamb ambient temperature 40 +85 C [1] All pins to ground. 6. Characteristics Table 5. Characteristics Tamb = 25 C unless otherwise specified. Symbol Parameter Conditions Min Typ Max Unit VBR breakdown voltage Itest = 1 mA 6 - 9 V ILR reverse leakage current per TMDS channel; V=3V - - 1 A VF forward voltage Itest = 1 mA - V - 0.6 - pF line capacitance f = 1 MHz; Vbias = 2.5 V Cline line capacitance difference f = 1 MHz; Vbias = 2.5 V [1] - 0.05 - pF Cline(mutual) mutual line capacitance f = 1 MHz; Vbias = 2.5 V [1][2] - 0.07 - pF rdyn dynamic resistance surge - 0.8 -  [3] - 0.85 -  positive transient; IPP = 3.8 A [3] - 9.5 - V negative transient; IPP = 2.8 A [3] - 3.2 - V negative transient VCL Product data sheet 0.7 Cline positive transient IP4283CZ10_SER [1] clamping voltage [1] This parameter is guaranteed by design. [2] Between signal pin and pin n.c. [3] According to IEC 61000-4-5 (8/20 s). All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 4 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 7. Application information The devices are designed to provide high-level ESD protection for high-speed serial data buses such as HDMI, DisplayPort, eSATA and LVDS data lines. When designing the Printed-Circuit Board (PCB), give careful consideration to impedance matching, and signal coupling. Basic application diagrams for the ESD protection of an HDMI interface are shown in Figure 1 and 2. IP4283CZ10-TBR 5 4 8 3 2 1 TMDS_D2+ TMDS_CH2+ TMDS_GND TMDS_CH2– TMDS_D2– GND TMDS_D1+ TMDS_CH1+ TMDS_GND TMDS_CH1– TMDS_D1– IP4283CZ10-TBR 5 TMDS_D0+ TMDS_CH2+ TMDS_GND 4 8 3 2 1 TMDS_CH2– TMDS_D0– GND TMDS_CLK+ TMDS_CH1+ HDMI CONNECTOR TMDS_GND TMDS_CH1– TMDS_CLK– CEC n.c. DDC_CLK DDC_DAT GND +5 V HOT PLUG DETECTION 6 5 4 IP4221CZ6 1 2 100 nF 3 018aaa144 Fig 1. IP4283CZ10_SER Product data sheet Application diagram of HDMI ESD protection using IP4283CZ10-TBR All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 5 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces IP4283CZ10-TT TMDS_D2+ TMDS_D2+ TMDS_GND TMDS_D2− TMDS_D2− TMDS_D1+ TMDS_D1+ TMDS_GND TMDS_D1− TMDS_D1− IP4283CZ10-TT TMDS_D0+ TMDS_D0+ TMDS_GND TMDS_D0− TMDS_D0− TMDS_CLK+ TMDS_CLK+ HDMI CONNECTOR TMDS_GND TMDS_CLK1− TMDS_CLK− CEC n.c. DDC_CLK DDC_DAT GND +5 V HOT PLUG DETECTION IP4220CZ6 100 nF 001aaj794 Fig 2. IP4283CZ10_SER Product data sheet Application diagram of HDMI ESD protection using IP4283CZ10-TT All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 6 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 8. Package outline 0.5 max 1.1 0.9 0.25 0.15 0.2 min 0.05 max 6 5 2.6 2.4 2 0.45 0.35 0.5 10 1 0.127 0.43 0.33 Dimensions in mm Fig 3. 13-02-21 Package outline DFN2510-10 (SOT1165-1) 1.1 0.9 0.127 0.2 min 6 5 2.6 2 2.4 0.25 0.15 0.5 10 1 0.4 0.3 0.45 0.35 Dimensions in mm Fig 4. 0.05 max 0.5 max 12-05-23 Package outline DFN2510A-10 (SOT1176-1) 3.1 2.9 10 1.1 max 6 0.7 0.4 5.0 4.8 3.1 2.9 pin 1 index 1 0.5 5 0.30 0.15 0.23 0.15 Dimensions in mm Fig 5. 03-02-18 Package outline TSSOP10 (SOT552-1) IP4283CZ10_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 7 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 9. Soldering Footprint information for reflow soldering of DFN2510-10 package SOT1165-1 Hx P C Hy Ay By 0.05 D D1 0.05 Generic footprint pattern Refer to the package outline drawing for actual layout solder land solder paste deposit solder land plus solder paste occupied area solder resist Dimensions in mm P Ay By C D D1 Hx Hy 0.500 1.3 0.25 0.525 0.20 0.40 2.45 1.6 Fig 6. Remark: Stencil of 75 μm is recommended. A stencil of 75 μm gives an aspect ratio of 0.77 With a stencil of 100 μm one will obtain an aspect ratio of 0.58 sot1165-1_fr Reflow soldering footprint DFN2510-10 (SOT1165-1) IP4283CZ10_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 8 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces Footprint information for reflow soldering of DFN2510A-10 package SOT1176-1 Hx C Hy Ay By 0.05 D P 0.05 Generic footprint pattern Refer to the package outline drawing for actual layout solder land solder paste deposit solder land plus solder paste occupied area solder resist Dimensions in mm P Ay By C D Hx Hy 0.5 1.25 0.3 0.475 0.2 2.45 1.5 Fig 7. Remark: Stencil of 75 μm is recommended. A stencil of 75 μm gives an aspect ratio of 0.77 With a stencil of 100 μm one will obtain an aspect ratio of 0.58 sot1176-1_fr Reflow soldering footprint DFN2510A-10 (SOT1176-1) IP4283CZ10_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 9 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces Footprint information for reflow soldering of TSSOP10 package SOT552-1 Hx Gx P2 (0.125) Hy Gy (0.125) By Ay C D2 (4x) D1 P1 Generic footprint pattern Refer to the package outline drawing for actual layout solder land occupied area DIMENSIONS in mm P1 P2 Ay By C D1 D2 Gx Gy Hx Hy 0.500 0.550 5.400 3.200 1.100 0.300 0.400 2.750 3.900 3.700 5.650 Fig 8. sot552-1_fr Reflow soldering footprint TSSOP10 (SOT552-1) IP4283CZ10_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 10 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 10. Revision history Table 6. Revision history Document ID Release date Data sheet status Change notice Supersedes IP4283CZ10_SER v.4 20130408 Product data sheet - IP4283CZ10_SER v.3 Modifications: • • • • • • • • Section 1.1 “General description”: updated Section 1.2 “Features and benefits”: updated Section 2 “Pinning information”: updated Section 3 “Ordering information”: updated Table 5 “Characteristics”: updated; rdyn value corrected Section 8 “Package outline”: drawings replaced with minimized package outline drawings Section 9 “Soldering”: updated Section 11 “Legal information”: updated IP4283CZ10_SER v.3 20110624 Product data sheet - IP4283CZ10_SER v.2 IP4283CZ10_SER v.2 20100827 Product data sheet - IP4283CZ10 v.1 IP4283CZ10 v.1 20090507 Product data sheet - - IP4283CZ10_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 11 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 11. Legal information 11.1 Data sheet status Document status[1][2] Product status[3] Definition Objective [short] data sheet Development This document contains data from the objective specification for product development. Preliminary [short] data sheet Qualification This document contains data from the preliminary specification. Product [short] data sheet Production This document contains the product specification. [1] Please consult the most recently issued document before initiating or completing a design. [2] The term ‘short data sheet’ is explained in section “Definitions”. [3] The product status of device(s) described in this document may have changed since this document was published and may differ in case of multiple devices. The latest product status information is available on the Internet at URL http://www.nxp.com. 11.2 Definitions Draft — The document is a draft version only. The content is still under internal review and subject to formal approval, which may result in modifications or additions. NXP Semiconductors does not give any representations or warranties as to the accuracy or completeness of information included herein and shall have no liability for the consequences of use of such information. Short data sheet — A short data sheet is an extract from a full data sheet with the same product type number(s) and title. A short data sheet is intended for quick reference only and should not be relied upon to contain detailed and full information. For detailed and full information see the relevant full data sheet, which is available on request via the local NXP Semiconductors sales office. In case of any inconsistency or conflict with the short data sheet, the full data sheet shall prevail. Product specification — The information and data provided in a Product data sheet shall define the specification of the product as agreed between NXP Semiconductors and its customer, unless NXP Semiconductors and customer have explicitly agreed otherwise in writing. In no event however, shall an agreement be valid in which the NXP Semiconductors product is deemed to offer functions and qualities beyond those described in the Product data sheet. 11.3 Disclaimers Limited warranty and liability — Information in this document is believed to be accurate and reliable. However, NXP Semiconductors does not give any representations or warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the consequences of use of such information. NXP Semiconductors takes no responsibility for the content in this document if provided by an information source outside of NXP Semiconductors. In no event shall NXP Semiconductors be liable for any indirect, incidental, punitive, special or consequential damages (including - without limitation - lost profits, lost savings, business interruption, costs related to the removal or replacement of any products or rework charges) whether or not such damages are based on tort (including negligence), warranty, breach of contract or any other legal theory. Notwithstanding any damages that customer might incur for any reason whatsoever, NXP Semiconductors’ aggregate and cumulative liability towards customer for the products described herein shall be limited in accordance with the Terms and conditions of commercial sale of NXP Semiconductors. Right to make changes — NXP Semiconductors reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. This document supersedes and replaces all information supplied prior to the publication hereof. IP4283CZ10_SER Product data sheet Suitability for use — NXP Semiconductors products are not designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical systems or equipment, nor in applications where failure or malfunction of an NXP Semiconductors product can reasonably be expected to result in personal injury, death or severe property or environmental damage. NXP Semiconductors and its suppliers accept no liability for inclusion and/or use of NXP Semiconductors products in such equipment or applications and therefore such inclusion and/or use is at the customer’s own risk. Applications — Applications that are described herein for any of these products are for illustrative purposes only. NXP Semiconductors makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification. Customers are responsible for the design and operation of their applications and products using NXP Semiconductors products, and NXP Semiconductors accepts no liability for any assistance with applications or customer product design. It is customer’s sole responsibility to determine whether the NXP Semiconductors product is suitable and fit for the customer’s applications and products planned, as well as for the planned application and use of customer’s third party customer(s). Customers should provide appropriate design and operating safeguards to minimize the risks associated with their applications and products. NXP Semiconductors does not accept any liability related to any default, damage, costs or problem which is based on any weakness or default in the customer’s applications or products, or the application or use by customer’s third party customer(s). Customer is responsible for doing all necessary testing for the customer’s applications and products using NXP Semiconductors products in order to avoid a default of the applications and the products or of the application or use by customer’s third party customer(s). NXP does not accept any liability in this respect. Limiting values — Stress above one or more limiting values (as defined in the Absolute Maximum Ratings System of IEC 60134) will cause permanent damage to the device. Limiting values are stress ratings only and (proper) operation of the device at these or any other conditions above those given in the Recommended operating conditions section (if present) or the Characteristics sections of this document is not warranted. Constant or repeated exposure to limiting values will permanently and irreversibly affect the quality and reliability of the device. Terms and conditions of commercial sale — NXP Semiconductors products are sold subject to the general terms and conditions of commercial sale, as published at http://www.nxp.com/profile/terms, unless otherwise agreed in a valid written individual agreement. In case an individual agreement is concluded only the terms and conditions of the respective agreement shall apply. NXP Semiconductors hereby expressly objects to applying the customer’s general terms and conditions with regard to the purchase of NXP Semiconductors products by customer. No offer to sell or license — Nothing in this document may be interpreted or construed as an offer to sell products that is open for acceptance or the grant, conveyance or implication of any license under any copyrights, patents or other industrial or intellectual property rights. All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 12 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces Export control — This document as well as the item(s) described herein may be subject to export control regulations. Export might require a prior authorization from competent authorities. Quick reference data — The Quick reference data is an extract of the product data given in the Limiting values and Characteristics sections of this document, and as such is not complete, exhaustive or legally binding. Non-automotive qualified products — Unless this data sheet expressly states that this specific NXP Semiconductors product is automotive qualified, the product is not suitable for automotive use. It is neither qualified nor tested in accordance with automotive testing or application requirements. NXP Semiconductors accepts no liability for inclusion and/or use of non-automotive qualified products in automotive equipment or applications. In the event that customer uses the product for design-in and use in automotive applications to automotive specifications and standards, customer (a) shall use the product without NXP Semiconductors’ warranty of the product for such automotive applications, use and specifications, and (b) whenever customer uses the product for automotive applications beyond NXP Semiconductors’ specifications such use shall be solely at customer’s own risk, and (c) customer fully indemnifies NXP Semiconductors for any liability, damages or failed product claims resulting from customer design and use of the product for automotive applications beyond NXP Semiconductors’ standard warranty and NXP Semiconductors’ product specifications. 11.4 Trademarks Notice: All referenced brands, product names, service names and trademarks are the property of their respective owners. 12. Contact information For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com IP4283CZ10_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 4 — 8 April 2013 © NXP B.V. 2013. All rights reserved. 13 of 14 IP4283CZ10 series NXP Semiconductors ESD protection for ultra high-speed interfaces 13. Contents 1 1.1 1.2 1.3 2 3 4 5 6 7 8 9 10 11 11.1 11.2 11.3 11.4 12 13 Product profile . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General description . . . . . . . . . . . . . . . . . . . . . 1 Features and benefits . . . . . . . . . . . . . . . . . . . . 1 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Pinning information . . . . . . . . . . . . . . . . . . . . . . 2 Ordering information . . . . . . . . . . . . . . . . . . . . . 3 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Limiting values. . . . . . . . . . . . . . . . . . . . . . . . . . 4 Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Application information. . . . . . . . . . . . . . . . . . . 5 Package outline . . . . . . . . . . . . . . . . . . . . . . . . . 7 Soldering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Revision history . . . . . . . . . . . . . . . . . . . . . . . . 11 Legal information. . . . . . . . . . . . . . . . . . . . . . . 12 Data sheet status . . . . . . . . . . . . . . . . . . . . . . 12 Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Disclaimers . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Contact information. . . . . . . . . . . . . . . . . . . . . 13 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Please be aware that important notices concerning this document and the product(s) described herein, have been included in section ‘Legal information’. © NXP B.V. 2013. All rights reserved. For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com Date of release: 8 April 2013 Document identifier: IP4283CZ10_SER
