1TJF125DP1A000A

Serial No. : 2014-1329 DATE : 2014/11/11 CRYSTAL RESONATOR ITEM : DST310S TYPE : ---------------------- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - 32.768kHz NOMINAL FREQUENCY : ---------------------- - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - 1TJF125DP1A000A SPEC No. : ---------------------- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- -- - ---------------------- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- - - - - - - -- -- - RECEIPT DATE RECEIVED (signature) (name) General Manufacture of Quartz Devices 1389 Shinzaike, Hiraoka-cho, Kakogawa, Hyogo 675-0194 Japan Phone (81)79-425-3141 Fax (81)79-425-1134 http://www.kds.info/index_en.htm C.ENG. ENG. Serial No.2014-1329 1. ELECTRICAL CHARACTERISTICS (This test shall be performed under the conditions of temp.at +25±3°C,Relative humidity 60%max.) 1.1. NOMINAL FREQUENCY 32.768 kHz 1.2. OVERTONE ORDER Fundamental 1.3. LOADING CAPACITANCE(CL) 12.5 pF 1.4. FREQUENCY TOLERANCE ±20 ×10-6 max. (at +25±3°C) 1.5. DRIVE LEVEL 0.2 μW ± 20% (1μW max.) 1.6. SERIES RESISTANCE 80 kΩ max. (at Series) 1.7. TURNOVER TEMPERATURE +25 ±5°C -0.04×10-6 / °C2 max. 1.8. PARABOLIC COEFFICIENT 1.9. SHUNT CAPACITANCE 1.3 pF typ. 1.10. OPERATING TEMPERATURE RANGE - 40 ~ +85 °C 1.11. STORAGE TEMPERATURE RANGE - 40 ~ +85 °C 1.12. INSULATION RESISTANCE 500 MΩ min. (at DC100±15V) Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 1 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 2. DIMENSIONS AND MARKING 2.1. DIMENSIONS unit : mm Tolerance ± 0.1 Fig.-1 2.2. MARKING Marking should be printed as follows: Logo(*1),Nominal Frequency(*2),Lot No.(*3),Plants(*4) *1 Manufacturer's trademark shall be marked 'D' as Logo. *2 In case of 32.768kHz, nominal frequency shall be marked 'A'. *3 Lot No. shall be marked three figures. (1) Year:The last digit of the year. Week:We gave the sequence of week numbers 01(first week) for production date. There are starting from 1st of Jan. However,add '0' figure to the first week during the 9th weeks. The week means are from Sunday to Saturday. ex. Manufactured day: 2014.11.11 4 46 Year Week *4 Manufactured in TIANJIN KDS CORP. shall be marked 'C' as Plants. Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 2 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 3. PACKING 3.1. EMBOSS CARRIER TAPE & REEL (1)Dimensions of Emboss carrier tape DA446C Fig.-2 (2)Dimensions of tape reel Pulling direction The direction of drawing out of the tape is made the inside and outside of the reel as shown in figure. Fig.-3 Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 3 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 Table-1 Item Diameter Inside width Outside width Out Line diameter Flange Center core slit Center Core Width Length Position Spindle diameter Width key Seats Length Position Indication of type unit:mm Mark Dimensions / Angle A Φ180 +0 -3.0 W1 13.0 ± 0.3 W2 15.5 ± 1.0 B Φ60 +1.0 -0 F1 3.0 ± 0.2 F2 4.0 ± 0.2 F3 5.0 ± 0.2 V 11.9 q 120 ° C Φ13 ± 0.2 E 2.0 ± 0.5 U 10.5 ± 0.4 q 120 ° Sticker label on one side of flange (3)Storage Condition Temperature;+40°C max.,Relative Humidity;80% max. Storage Period:6months max. (4)Standard packing quantity 3,000pcs./reel for Φ180 (5)Material of the tape tape Carrier tape Cover tape Material Polystyrene,Carbon Polyester (6)Label Contents HOLDER SPEC No. USER PARTS No. TYPE SPEC NO. PARTS NO. LOT NO. FREQ. Q'TY LOT No. FREQUENCY QUANTITY COUNTRY OF ORIGIN MADE IN Stick a label on the each reel. Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 4 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 (7)Taping Dimension Leader Cover tape Carrier tape Terminal Cover tape Carrier tape Terminal The length of cover tape in the leader is more than 400mm including empty embossed area. After all products were packaged,must remain more than twenty pieces or 400mm empty embossed area,which should be sealed by cover tape. The tip of cover tape shall be fixed temporary by paper tape and roll around the core of reel one round. The empty embossed area which are sealed by cover tape must remain more than 40mm. Leader Component Empty Components Unreeling direction Empty Components Cover tape Carrier tape Fig.-4 (8)Joint of tape The carrier tape and cover tape should not be jointed. (9)Release strength cover tape It has between 0.1~0.7N under following condition. Pulling direction 165~180 ° Speed 300mm/min Otherwise unless specifiied 165~180 ° Pulling direction Fig.-5 The component must be free fall,when tear away the cover tape with upside-down the emboss carrier tape. Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 5 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 3.2. PACKING (1)The way of packing and label LABEL Label contents The type of product Lot No. Specification Quantity Shipment Day Remark Fig.-6 (2)The size of packing carton There may be different size of packing carton used depending on the lot size. Also,the product packed inside shall be protected by air cushion. Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 6 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 4. REFLOW CONDITIONS (REFERENCE) During the solder reflow process,please complete within following temperature period. Reflow soldering shall be allowed only 2 times. +260±5°C +220±5°C +170±10°C 10s 60s 120s Fig.-7 HANDSOLDERING METHOD HANDSOLDERING METHOD : +350±10°C,3+1/-0s Each terminal once (Please take care so that a soldering iron should not touch a lid directly.) 5. LAND PATTERN (REFERENCE) 1.8 2.5 unit:mm 1.0 Fig.-8 Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 7 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 6. MECHANICAL ENDURANCE 6.1. SHOCK After the following test,parts shall conform specification table-2-B. 3times free drop from 75cm heights to hard wood board of minimum thickness 30mm. 6.2. VIBRATION After the following test,parts shall conform specification table-2-A, and no abnormal appearance shall be observed. (1)Frequency of Vibration : 10~55Hz 1~2min (2)Amplitude total : 1.5mm (3)Vibration axis : X,Y,Z (4)Vibration period : 2h for X,Y,Z axis 6.3. SUBSTRATE BENDING After the following test,parts shall conform specification table-2-A, and no abnormality shall be observed in external appearance and sealing tightnen and others shall be based on ET-7403 of EIAJ. 20 pressure jig R230 Mount the specimen on substrate. Apply the following pressure Direction : see Fig.-9 Speed : 0.5mm/s Hours : 5±1s Amount of substrate: 3mm max. P.C.B. 45+/-2 45+/-2 Fig.-9 6.4. SHEAR After the following test,parts shall conform specification table-2-A, and no abnormality shall be observed in external appearance and sealing pressure jig tightness and others shall be based on ET-7403 of EIAJ. Mount the specimen on substrate. Apply the following pressure R0.5 specimen Weight : 10N Hours : 10±1s Direction : see Fig.-10 P.C.B. Fig.-10 Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 8 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 6.5. BODY STRENGTH After the following test,parts shall conform specification table-2-A, and no abnormality shall be observed in external appearance and sealing tightnen and others shall be based on ET-7403 of EIAJ. Mount the specimen on substrate. Apply the following pressure Pressure jig : R0.5 Weight : 10N Hours : 10±1s Direction : see Fig.-11 Fig.-11 6.6. SEAL Less than 2.0×10-9 Pa*m3/s by Helium leak detector. Also,no bubble is observed by Fluorinert tests. 6.7. SOLDERABILITY After the following test. More than 90% of lead shall be covered by new solder. 3±1s dip in +235±5°C solder. (Use rosin type flux for solder.) 6.8. RESISTANCE TO SOLDERING HEAT (REFLOW) 48h past at room temperature from following test,parts shall conform specification table-2-C. perform the attached reflow conditions to reference. 6.9. RESISTANCE TO SOLDERING HEAT (HAND SOLDERING METHOD) 48h past at room temperature from following test,parts shall conform specification table-2-C. +350±10°C,3+1/-0s Each terminal once Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 9 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 7. ENVIRONMENTAL ENDURANCE 7.1. HUMIDITY 2h past at room temperature after following test,parts shall conform specification table-2-C. 240h +85±2°C,relative humidity 85±5%. 7.2. LOW TEMPERATURE 2h past at room temperature after following test,parts shall conform specification table-2-C. 240h -40±3°C 7.3. HIGH TEMPERATURE 2h past at room temperature after following test,parts shall conform specification table-2-C. 240h +85±2°C 7.4. TERMAL SHOCK TEST 2h past at room temperature after 25cycles of following test,parts shall conform specification table-2-C. 30min +85°C +25°C Transport Time 2~3min -40°C 30min 1cycle Fig.-12 8. SPECIFICATION Table-2 A B C Frequency Variation -6 ±5×10 ±8×10-6 ±10×10-6 Equivalent Resistance ±25 % or ±10kΩ max. (Use larger specification) ±25 % or ±10kΩ max. (Use larger specification) ±25 % or ±10kΩ max. (Use larger specification) Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 10 / 12 DM-Z0002:Style-010Ver.1 Serial No.2014-1329 9. THE CAUTIONS ON USE FOR DST310S 9.1. SOLDERING Please perform reflow conditions within 2 times. 9.2. MOUNT Crystal products are designed to be compatible with automatic mounting. Be sure to have a mounting test in advance by using the actual mounting machine and check that the characteristics of the products are not damaged by the automatic mounting. In the process where the boad is warped,such as board separation process, be careful that the warping does not influence the characteristics and soldering of crystal products. Since mounting by Ultrasonic welding and processing have a possibility of an excessive vibration spreading inside a tuning fork crystal resonator and becoming the cause of characteristic deterioration and not oscillating,it does not recommend. 9.3. WASHING About use of the washing liquid of a basin system, an alcoholic system,and a chlorofluorocarbon-replacing material system,it is checking that it is satisfactory. However please consult in advance about other washing liquid. Tuning fork crystal resonators should not have ultrasonic washing because their frequency band is close to the washing frequency band of ultrasonic washing machines,very probably causing resonance destruction. To use ultrasonic washing to clean these resonators, tests must be performed in advance under actual application conditions. 9.4. DRIVE LEVEL The piece of crystal it is processed very smaller than the conventional thing inside DST310S series crystal unit may be damaged, if crystal resonators are exposed to an excessively high drive level. Please use the products within the limits specified in the catalogs and specifications. 9.5. HANDLING OF A PRODUCT DST310S series has sufficient intensity to fall and vibration. Crystal resonators should not have pattern to avoid causing base crack. 9.6. STORAGE Since the solderability of pins may deteriorate, please avoid storage in high-temperature,high-humidity place. Please store crystal products in a place free from direct sunlight and condensation. Title Remark DST310S TYPE QUARTZ CRYSTAL SPECIFICATION Date 2014/11/11 Spec No. 1TJF125DP1A000A DAISHINKU CORP. Rev. Page - 11 / 12 DM-Z0002:Style-010Ver.1 2014-1329 REVISION RECORD Rev.No Date Reason - 2014/11/11 - Contents The first edition. Approved Checked Drawn T.Kusai T.Fujii H.Nasu DM-Z0002:Style-008Ver.1 - 12/12 -
