ICSRC3908SFR

REV 0,15 DATE APPROVED 2009.06.05 P.K.KO +0.1 0 2 ±0.05 1, 5 4 ±0.1 0,3 5,34 0,8 12 1,1 1,75 ±0.1 TAPING사양도 SCALE 3/1 2,25 3,9 0,9 신규 제정 A O 0,8 1,15 0,25 REVISION HISTORY DESCRIPTION 0,72 +0.02 -0.05 1 SCALE : 20/1 1,3 4,1 RECOMMENDED PCB LAYOUT 1,2 1,3 NOTES 1. MATERIAL : SUS301 2. MATERIAL THICKNESS :0.15t 3. FINISHED : Sn(100%) PLATING ON BOTH SIDE 4. PACKING MATERIALS. - REEL : HIPS 0.3t - COVER TAPE : PS _ Q'TY/REEL : 10,000ea 5. AVAILABLE SHIELD CASE THICKNESS : 0.2 ± 0.02 6. CONTACT RESISTANCE 300mmΩMAX 7. INTENTION FORCE/RETENTION FORCE SPEC SPEC 0,8 0,9 MAX 0,63 0,15 3,8 RECOMMENDED STENCIL LAY-OUT 0.1T 1,35 INTENTION FORCE RETENTION FORCE MAX 1.3Kg MIN 0.5Kg 0.2T UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS TOLERANCES ARE ANGLES ± 0. 3° 0 ~ 1 ± 0.05 1 ~ 5 ± 0.1 5 ~ 10 ± 0.15 TITLE SHLED CLIP SIZE DWG NO A3 ICSRC3908SFR FILE NAME: ICSRC3908SFR.dft SCALE: WEIGHT: SHEET 1 OF 1 REV B
