ICSRC4408-015SFR

,2 R0 1,2 REV A B C D 인인부 인인 변변 0.66 +0.1 -0.05 SHIELD CASE THICKNESS 0.15±0.02 => 0.15 +0.02 -0 1,75 ±0.1 0,15 0,6 SCALE 20/1 0,75 1 0,9 0,8 RECOMMENDED PCB LAYOUT P.K.KOH 2012.03.30 P.K.KOH 1,2 0,3 2 ±0.05 1,5 NOTES 1. MATERIAL : SUS301 2. MATERIAL THICKNESS :0.15t 3. FINISHED : Sn(100%) PLATING ON BOTH SIDE ( NI 0.5㎛ Sn 1.27㎛ ) 4. PACKING MATERIALS. - REEL : HIPS 0.3t - COVER TAPE : PS _ Q'TY/REEL : 10,000ea 5. AVAILABLE SHIELD CASE THICKNESS : 0.15 +0.02 -0 6. CONTACT RESISTANCE : MAX 300mmΩ 7. STENCIL THICKNESS : 0.12T 8. Maintain 90˚±3 while engage & disengage shield can & shield clip to prevent deformation & to maintain retention force of shield clip 0,75 4,5 2012. 02. 17 5,34 ±0.1 9,2 12 1,5 0,8 ±0.05 0,66 ±0.1 0,1 +0.02 -0.03 0,9 APPROVED P.K.KOH p.k.koh +0.1 0 2,7 4 ±0.1 0,75 ±0.05 0,8 DATE 2010.08.12 2010.10.25 TAPING 사양도 ( SCALE 4 /1 ) O 0,8 4,4 REVISION HISTORY DESCRIPTION 신신 제제 pick-up부 형형 변변 4,4 RECOMMENDED MASK LAYOUT DATA APP. 2010.08.12 CHECK 2010.08.12 DESG. UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS TOLERANCES ARE ANGLES ± 0. 3° 0 ~ 1 ± 0.05 1 ~ 5 ± 0.1 5 ~ 10 ± 0.15 NAME LEE Solution Provider TITLE P.K.KO SIZE DWG NO SHIELD CLIP A3 ICSRC-4408-015SFR FILE NAME: ICSRC-4408-015SFR.dft SCALE: WEIGHT: SHEET 1 OF 1 REV D
