承認書編號 NO: SFAK2-1511000007 系列 SER.NO.: SJ 承 認 書 APPROVAL SHEET FOR 承 APPROVED AL. ELECTROLYTIC CAPACITORS 認 BY： 料号 (Customer) 料号 (CapXon) 规格 Description HP101M400N260AP 100uF/400V Dφ*L 加工形式 (mm) 25X26 SJ series 簽認後，請送回一份。 PLEASE RETURN US ONE COPY YOUR SIGNED SPECIFICATION AFTER YOU APPROVED OF IT. 核 准 APPROVED BY: 校 對 CHECKED BY: CapXon 豐 賓 電 子 工 業 股 份 有 限 公 司 CAPXON ELECTRONIC INDUSTRIAL CO.,LTD 新北市汐止區大同路二段 165 號 5 樓 5F, 165, Ta-Tung Rd. Sec 2, Shi-Chih Dist. New Taipei City, Taiwan. TEL: +886-2-8692-6611 FAX: +886-2-8692-6477 經 辦 DESIGNED BY: Part Number System When placing and order for Aluminum Electrolytic Capacitors. Please observe following Catalog Part Number format that describes. 3 2 1 5 4 6 7 8 11 10 9 1. Series 12 14 13 16 15 17 19 18 20 6. Height (L) 2. Capacitance 7. Product type 3. Capacitance tolerance 8. Lead Treatment 4. Rated Voltage 9. Special requirement 5. Case φD (1).Series The series name. (2).Capacitance Capacitance is show in microfarad (µF) Capacitance (µF) 0.1 0.47 1 4.7 10 100 1000 10000 Code 0R1 R47 010 4R7 100 101 102 103 (3).Capacitance tolerance Tolerance% ±5 ±10 ±20 ±30 -10to+30 -10to+50 -10to+20 -10to100 0to+20 -30to+0 ±15 Code H K M N Q T V W Z U S Tolerance% 0to+30 0to+40 0to+50 -5to+20 -8to+5 +5to+20 0to-20 -15to+20 -25to+20 Code Y X A J E I B P L -50to+0 -5to+30 O C For tolerance other than these and specified capacitance tolerance, please specify the value on the order sheet. (4).Voltage (W.V) Voltage (W.V) 6.3 10 Code 6R3 010 16 25 35 50 63 80 100 160 200 220 250 350 400 420 450 500 016 025 035 050 063 080 100 160 200 220 250 350 400 420 450 500 (5).Case (φD: mm) Diameter 3 4 5 Code A B C 6.3 7.3 8 E 7 F 10 12 13 16 18 20 22 25 30 35 40 42 45 51 G H I J K L M N O P Q U V R 63.5 S 76.2 89 14.5 12.5 T X Y Z (6). Height (L: mm) Description 5 Code 5.5 7 7.7 8 11 11.5 12 12.5 14 16 20 21 25 25.5 31.5 35 35.5 41 47 52 83 98 118 141 151 050 055 070 077 080 110 115 120 125 140 160 200 210 250 255 315 350 355 410 470 520 830 980 A18 A41 A51 (7). Product type Type Without Lead Treatment Code With Lead Treatment A E (8). Lead Treatment (Radial type) Description Taping Taping (Ammo (Reel Package) Package) TA、TB、 Code TC、TD、 TE、TF、 ETC. Lead Cutting Lead Lead Lead Lead Forming Forming Crimping Cutting & Cutting only & Forming Kink CF FA KF CK Kink Bending & Forming Cutting &Kink CR、CL EF RA、RB、 RC、RD、 CA RE、 Etc. Remarks: The product of V- chip sticks a dish to process form is “TR”. KA th th th th (9) Special & appearance requirement (the 17 , 18 , 19 , 20 code) Code A Special Terminals of Snap-in request Code Special Code H Height requirement R Ripple current countermeasure B Rubber I L.C. S C Lead wire K Vent line T D D.F. L Life V characteristic Code U Special Package & label Temperature characteristic Vt, Electrolyte paper Solder, technics, E Electrolyte N Nude M form, Case with pillar, F Pitch P G Fill glue Q Sleeve, tray, print, PVC sleeve Capacitance, CV, Break Y Z clip loop Impedance & ESR Remarks: 1. If it’s without lead treatment & special requirement, the 15th code is blank. 2. If it’s with lead treatment & without require special requirement, the 17th, 18th, 19th, 20th code is blank. 3. If it’s without lead treatment, but with special requirement, the 15th, 16th code filled with 0. 4. If it’s without lead treatment, but with special requirement, also exceeds 4 kinds, keystone characteristic is 4 codes. 5. If it’s with lead treatment, but with 1 special requirement, only remark 17th code, latter three codes is blank. 6. If it’s with lead treatment, but with 1 special requirement, and it is different from former data, the 17th is 0, the 18th code is characteristic. SJ series Information 1. Maximum ripple current 1.1 Maximum RMS ripple current at +105°C , 120Hz. 1.2 When capacitors are operated at temperatures other than +105°C, and frequency other than 120Hz, the maximum RMS ripple currents must be multiplied by the factors shown in below table. Multiplier for Ripple Current vs. Frequency: CAP (uF) \ Frequency(Hz) 50(60) 120 400 1K 10K 50～100K CAP≦10 0.8 1.0 1.30 1.45 1.65 1.70 10 315V 〔Criteria〕 Capacitance change Tan δ Leakage current Appearance : +15 to +35℃ : 1000±10Ω : Charge period is 30s, followed by a discharge period of 5.5 min. : 1000 cycles. :Surge voltage shall be 1.15 times the rated voltage :Surge voltage shall be 1.1 times the rated voltage : Within ±15% of initial value. : Not more than the specified value : Not more than the specified value : No leakage and damaged. 1-12.High Temperature Storage 〔Conditions〕 The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 1000 hours at 105±2℃ without an applied voltage. Before the measurements, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4. 〔Criteria〕 Capacitance change : Within ±20% of initial value. Tan δ : Not more than 200% of the specified value Leakage current : Not more than the specified value Appearance : No leakage and damaged. 1-13.High and Low Temperature characteristics 〔Conditions〕 Temperature [℃] Step +20±2 1 -40±3 2 +20±2 3 +105±2 4 +20±2 5 Time / 2h 15±2 min. 2h 15±2 min. CapXon-Ver. 5.7 SJ series 〔Criteria〕 Step 2：Impedance ratio shall not exceed the values shown in Table attached. [120Hz] Rated Voltage(V) 6.3 10 16 25 35 50 63 Z-25℃/Z+20℃ 4 3 2 2 2 2 2 Z-40℃/Z+20℃ 8 6 4 4 3 3 3 For capacitance value > 1000μF: 1). add 0.5 per another 1000μF for -25℃/+20℃ 2). add 1.0 per another 1000 μF for -40℃/+20℃ Step 4. Capacitance change Tan δ Leakage current : Within ±30% of initial value. : Not more than the specified value. : Shall not more than 800% of initial specified value. 2. Reference standard SJ series is applicable to general-purpose grade capacitors of JIS-C-5101-1(2010) The other test conditions shall comply with JIS-C-5101-4(2010). 3. Marking The following items shall be marked on each capacitor. All marking shall be legible and permanent. (Example) CapXon (1) CapXon： Manufacturer: trademark Front side: (2) 16V：Rated voltage 100uF 16V (3) 100μF：Nominal capacitance (4) ：(-)Polarity (Cathode indicate) (5) 105℃：Maximum operating temperature. SJ 105℃ Back side: (6) SJ：Series P1018 (7) P1018：Production date code VENT （P：PET Sleeve; 10：year 2010 18：the 18 week） (8) VENT：Safety vent (≧6.3X11mm、8X7mm have mark of vent ) CapXon-Ver. 5.7 6. Diagram of Dimension ( Unit = mm) P.ET Sleeve ±0.02 Dψ 4 5 6.3 8 F 1.5 2.0 2.5 3.5 dψ 0.45 0.5 6-6HULHV &DVH6L]H φ'[/PP :9 &DSμ)    6L]H  5LSSOH 6L]H  5LSSOH         [  [ [ [ [     [  [  :9 &DSμ)                   [ [   [  [ [   [ [ [      6L]H 5LSSOH [ [   [ [ [ [     [ [ [ [      6L]H 5LSSOH [  [ [ [ [ [ [ [ [ [ [           6L]H [ [ [ [ [ [ [ [ 5LSSOH         [ [   [   6L]H [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ 5LSSOH                 6L]H [ [ [ [ [ [ [ [ [ [ [ [ [ 5LSSOH              [ [   [ [   [  5LSSOH&XUUHQWP$UPVDW℃+]
