MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS NZE Series •105℃ 2,000Hrs assured. •Non-solvent proof. •Downsized, High Ripple. •For SMPS, IP-Board, Adaptor. •RoHS compliant. •Halogen-free capacitors are also available. NFD NZE (KMF) Downsized SPECIFICATIONS ltem Characteristics Rated Voltage Range 160 ~ 400 VDC Operating Temperature Range 420 ~ 500 VDC -40 ~+ 105℃ -25 ~ +105℃ Capacitance Tolerance ±20%(M) Time c·v Leakage Current After 1 minute (at 20℃, 120Hz) After 5 minutes ≦ 1000 I=0.1CV+40 I=0.03CV+15 ＞ 1000 I=0.04CV+100 I=0.02CV+25 Where, I:Max. Leakage current(㎂) C:Nominal capacitance(㎌) V:Rated voltage(VDC) Dissipation Factor(Tan δ) Temperature Characteristics (Max. Impedance ratio) Rated Voltage(VDC) 160~250 350~500 Tanδ(Max.) 0.20 0.24 Rated Voltage(VDC) 160~250 350~400 420~500 Z(–25℃)/Z(+20℃) 3 5 6 Z(–40℃)/Z(+20℃) 6 6 (at 20℃) (at 20℃, 120Hz) (at 120Hz) The following specifications shall be satisfied when the capacitors are restored to 20℃ after the rated voltage with the rated ripple current is applied (the peak voltage shall not exceed the rated voltage)for 2,000 hours at 105℃. Load Life Capacitance change Tan δ Leakage current ≦ ±20% of the initial value ≦ 200% of the initial specified value ≦ The initial specified value The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 1,000 hours at 105℃ without voltage applied. The rated voltage shall be applied to the capacitors for a minimum of 30 minutes, at least 24 hours and not more than 48 hours before the measurements. Shelf Life Capacitance change Tan δ Leakage current Others DIMENSIONS OF NZE Series ≦ ±20% of the initial value ≦ 200% of the initial specified value ≦ 500% of the initial specified value Satisfied characteristics KS C IEC 60384-4 Unit(mm) Marking : DARK BROWN SLEEVE, SILVER INK ØD 6.3 8 10 12.5 16 18 20 22 Ød 0.5 0.6 0.6 0.6 0.8 0.8 0.8 0.8 F 2.5 3.5 5.0 5.0 7.5 7.5 7.5 10.0 ØD′ ØD+0.5 max. L′ L+1.5max. L+2.0 max. 144 MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS RATINGS OF NZE Series V DC ltems ㎌ 3.3 4.7 6.8 10 22 33 47 68 82 100 120 ØD×L(mm) ØD×L(mm) 200 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 45 64 77 94 160 260 338 413 494 589 660 8×11.5 8×11.5 8×15 10×20 10×25 12.5×20 12.5×30 16×25 16×25 16×25 72 86 108 211 284 343 488 546 603 660 16×25 738 16×31.5 796 16×35.5 18×31.5 16×40 18×35.5 891 901 1,016 1,030 18×40 1,158 18×45 1,267 211 260 338 413 494 589 615 710 738 180 16×25 809 16×31.5 872 220 16×31.5 964 16×31.5 964 270 16×35.5 1,091 330 18×31.5 1,221 390 18×35.5 1,371 16×35.5 18×31.5 16×40 18×35.5 18×40 1,091 1,104 1,245 1,261 1,393 V DC ltems ØD×L(mm) 350 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 4.7 6.8 8.2 10×16 118 15 22 33 39 47 56 10×20 10×25 12.5×25 10×40 16×25 16×25 16×31.5 18×25 16×35.5 18×31.5 169 228 304 374 400 437 510 502 582 590 100 18×31.5 632 120 18×35.5 716 68 82 6.3×15 8×11 8×15 8×15 8×20 8×20 10×16 10×20 10×25 12.5×25 12.5×30 16×25 16×25 16×31.5 510 16×35.5 18×31.5 16×40 18×35.5 582 590 645 786 18×40 801 18×40 872 ØD×L(mm) 420 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 10×20 129 12.5×16 12.5×20 16×20 161 207 265 16×25 16×31.5 18×25 18×31.5 374 440 492 520 18×31.5 640 16×45 18×35.5 16×45 18×40 18×45 20×40 750 780 819 840 845 Series 150 ØD×L(mm) 400 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 55 101 102 105 110 115 118 169 228 304 355 400 437 NZE 10 ØD×L(mm) 250 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 6.3×11 8×11.5 8×11.5 8×11.5 8×20 10×20 10×25 12.5×25 12.5×25 12.5×30 16×25 10×20 10×20 10×25 12.5×20 12.5×25 12.5×30 16×20 12.5×35 16×25 150 ㎌ 160 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 145 MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS RATINGS OF NZE Series V DC ㎌ ltems ØD×L(mm) 450 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 80 108 129 173 232 292 306 330 39 8×20 10×16 10×20 12.5×20 12.5×25 12.5×30 16×25 10×45 47 16×25 374 53 10×50 424 56 16×31.5 440 16×35.5 18×31.5 12.5×50 16×40 18×31.5 12.5×60 16×45 18×35.5 16×50 18×40 18×45 20×40 514 520 670 640 640 790 750 750 819 819 840 845 4.7 8.2 10 15 22 33 60 68 82 100 120 150 ØD×L(mm) 500 Rated Ripple Current ( m A r m s / 1 0 5 ℃ , 1 2 0 HZ ) 12.5×30 238 12.5×45 327 12.5×50 16×35.5 18×31.5 376 385 389 16×40 12.5×60 12.5×60 16×45 18×35.5 16×50 452 473 494 567 546 599 18×40 588 18×45 20×40 700 18×50 22×45 800 900 22×50 950 1k 1.25 10k 1.50 RATED RIPPLE CURRENT MULTIPLIERS Frequency Multipliers Freq.(Hz) Factor 146 120 1.00 50k 1.60 100k 1.75
