WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
Description
Mechanical Characteristics
The :3(;;&7%/ is a bi-directional TVS diode array,
utilizing leading monolithic silicon technology to provide
fast re-sponse time and low ESD clamping voltage,
making this device an ideal solution for protecting
sensitive semicon-ductor components from damage.
The :3(;;&7%/ com-plies with the IEC 61000-4-2
(ESD) with ±30kV air and ±30kV contact discharge. It is
assembled into a lead-free SOT-23 package.
It is
designed to protect components which are connected to
Package: SOT-23
Lead Finish: Matte Tin
Case Material: “Green” Molding Compound.
Moisture Sensitivity: Level 3 per J-STD-020
Terminal Connections: See Diagram Below
Marking Information: See Below
data and transmission lines from voltage surges.
Cellular Handsets and Accessories
Notebooks and Handhelds
Portable Instrumentation
Set Top Box
Industrial Controls
Server and Desktop PC
Features
300W peak pulse power (8/20μs)
Protects two bi-directional lines
Ultra low leakage: nA level
Operating voltage: 3.3V,5V, 12V, 15V, 24V, 32V,
Applications
Marking Information
36V
Low clamping voltage
Complies with following standards:
– IEC 61000-4-2 (ESD) immunity test
Air discharge: ±30kV
Contact discharge: ±30kV
XXC = Device Marking
3
XXC
RoHS Compliant
1
Dimensions and Pin Configuration
2
Ordering Information
Part Number
Packaging
Reel Size
WPEXXCT23BL
3000/Tape & Reel
7 inch
Circuit and Pin Schematic
Rev.B_Aug,2017
-1-
www.wpmtek.com
WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
Absolute Maximum Ratings (TA=25°C unless otherwise specified)
Parameter
Peak Pulse Power (8/20µs)
ESD per IEC 61000−4−2 (Air)
Symbol
Value
Unit
Ppk
300
W
±30
VESD
ESD per IEC 61000−4−2 (Contact)
Operating Temperature Range
Storage Temperature Range
kV
±30
TJ
−55 to +125
°C
Tstg
−55 to +150
°C
Electrical Characteristics (TA=25°C unless otherwise specified)
WPE03CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
Typ
VRWM
VBR
Max
Unit
3.3
V
3.8
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
1.0
μA
VRWM = 3.3V
Clamping Voltage
VC
6
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
12
V
IPP = 25A (8 x 20µs pulse)
Peak Pulse Current
IPP
25
A
tp = 8/20μs
Junction Capacitance
CJ
100
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Max
Unit
5
V
WPE05CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
Typ
VRWM
VBR
6
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
1.0
μA
VRWM = 5V
Clamping Voltage
VC
8
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
15
V
IPP = 20A (8 x 20µs pulse)
Peak Pulse Current
IPP
20
A
tp = 8/20μs
Junction Capacitance
CJ
80
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Rev.B_Aug,2017
-2-
www.wpmtek.com
WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
WPE12CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
Typ
VRWM
VBR
Max
Unit
12
V
13.3
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
0.5
μA
VRWM = 12V
Clamping Voltage
VC
18
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
25
V
IPP = 12A (8 x 20µs pulse)
Peak Pulse Current
IPP
12
A
tp = 8/20μs
Junction Capacitance
CJ
50
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Max
Unit
15
V
WPE15CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
Typ
VRWM
VBR
16.7
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
0.5
μA
VRWM = 15V
Clamping Voltage
VC
20
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
37.5
V
IPP = 8A (8 x 20µs pulse)
Peak Pulse Current
IPP
8
A
tp = 8/20μs
Junction Capacitance
CJ
40
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Rev.B_Aug,2017
-3-
www.wpmtek.com
WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
WPE24CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
Typ
VRWM
VBR
Max
Unit
24
V
27
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
0.2
μA
VRWM = 24V
Clamping Voltage
VC
40
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
60
V
IPP = 5A (8 x 20µs pulse)
Peak Pulse Current
IPP
5
A
tp = 8/20μs
Junction Capacitance
CJ
15
30
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Typ
Max
Unit
32
V
WPE32CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
VRWM
VBR
35.6
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
0.2
μA
VRWM = 36V
Clamping Voltage
VC
45
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
67
V
IPP = 4.5A (8 x 20µs pulse)
Peak Pulse Current
IPP
4
A
tp = 8/20μs
Junction Capacitance
CJ
15
25
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Typ
Max
Unit
36
V
WPE36CT23BL
Parameter
Reverse Working Voltage
Breakdown Voltage
Symbol
Min
VRWM
VBR
38
Test Condition
V
IT = 1mA
Reverse Leakage Current
IR
0.2
μA
VRWM = 36V
Clamping Voltage
VC
50
V
IPP = 1A (8 x 20µs pulse)
Clamping Voltage
VC
75
V
IPP = 4A (8 x 20µs pulse)
Peak Pulse Current
IPP
4
A
tp = 8/20μs
Junction Capacitance
CJ
20
pF
VR = 0V, f = 1MHz, Pin 1 to Pin 3
or Pin 2 to Pin 3
Rev.B_Aug,2017
12
-4-
www.wpmtek.com
WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
Typical Performance Characteristics (TA=25°C unless otherwise Specified)
Power Derating Curve
Peak Pulse Power vs. Pulse Time
8 X 20μs Pulse Waveform
Rev.B_Aug,2017
-5-
www.wpmtek.com
WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
SOT-23 Package Outline Drawing
DIMENSIONS
SYM
MIN
MILLIMETERS
NOM
A
0.90
--
1.15
0.035
--
0.045
A1
0.00
--
0.10
0.000
--
0.004
A2
0.90
--
1.05
0.035
--
0.041
b
0.30
--
0.50
0.012
--
0.020
c
0.08
--
0.15
0.003
--
0.006
D
2.80
--
3.00
0.110
--
0.118
E
1.20
--
1.40
0.047
--
0.055
E1
2.25
--
2.25
0.089
e
e1
MAX
MIN
INCHES
NOM
MAX
0.95TYP
1.80
L
--
0.100
0.037TYP
2.00
0.071
0.55REF
--
0.079
0.022REF
L1
0.30
--
0.50
0.012
--
0.020
Θ
0°
--
8°
0°
--
8°
Rev.B_Aug,2017
-6-
www.wpmtek.com
WPEXXCT23BL
Integrated in
OVP&OCP products
provider
/LQH%LGLUHFWLRQDO796'LRGH$UUD\
Suggested Land Pattern
SYM
DIMENSIONS
INCHES
MILLIMETERS
C
.087
2.20
E
.037
0.95
E1
.075
1.90
G
.031
0.80
X
.039
1.00
Y
.055
1.40
Z
.141
3.60
Contact information
WPMTEK Incorporated Limited
Room 206-207,2nd Floor,Block 3,Minxing lndustry Park,Minzhi
Longhua New District,Shenzhen
TEL:86755-29308003
FAX:86755-23739900
wpmtek Incorporated Limited (WPM) reserves the right to make changes to the product specification and data in this document without notice. WPM
makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does WPM assume any liability
arising from the application or use of any products or circuits, and specifically dis- claims any and all liability, including without limitation special,
consequential or incidental damages.
Rev.B_Aug,2017
-7-
www.wpmtek.com
