SDXXC
Integrated in
OVP&OCP products
3.3V~36V Ultra Low Capacitance
Bi-directional TVS Diode
provider
Description
Mechanical Characteristics
The SDXXC is designed to replace multilayer varistors
(MLVs) in portable applications such as cell phones,
n
Package: SOD-323
notebook computers and PDA’s, using monolithic silicon
n
technology to provide fast response time and ultra low
Lead Finish: Matte Tin
n
Case Material: “Green” Molding Compound.
n
UL Flammability Classification Rating 94V-0
components from damage. The SDXXC complies with the
n
Moisture Sensitivity: Level 3 per J-STD-020
IEC 61000- 4-2 (ESD) standard with ±30kV air and ±30kV
n
Terminal Connections: See Diagram Below
contact discharge. The SDXXC is assembled into a lead-
n
Marking Information: See Below
ESD clamping voltage, making this device an ideal
solution for protecting sensitive semiconductor
free SOD- 323 package and will protect one unidirectional
Applications
line. These devices will fit on the same PCB pad area as
an 0805 MLV device.
Features
n
350W peak pulse power (8/20us)
n
Protects one data or power line
n
Ultra low leakage: nA level
n
Stand−off Voltage: 3.3 V ~ 36 V
n
Ultra low clamping voltage
n
Complies with following standards:
n
Cellular Handsets and Accessories
n
Personal Digital Assistants
n
Notebooks and Handhelds
n
Portable Instrumentation
n
Peripherals
n
Pagers Peripherals
n
Desktop and Servers
Marking information
– IEC 61000-4-2 (ESD) immunity test
Air discharge: ±15kV
Contact discharge: ±8kV
n
IEC61000-4-4 (EFT) 40A (5/50ns)
n
RoHS Compliant
Details marking code reference customer approval list
Dimensions & Symbol(Unit: mm Max)
Ordering Information
Part Number
SD03C
SD05C
SD08C
SD12C
SD15C
SD18C
SD24C
SD36C
Rev.C_29, Mar,2019
-1-
Packaging
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
Reel Size
7 inch
7 inch
7 inch
7 inch
7 inch
7 inch
7 inch
7 inch
www.wpmtek.com
SDXXC
Integrated in
OVP&OCP products
3.3V~36V Ultra Low Capacitance
Bi-directional TVS Diode
provider
Absolute Maximum Ratings (TA=25°C unless otherwise specified)
PARAMETER
SYMBOL
VALUE
UNITS
Peak Pulse Power (t p= 8/20µs)
PPP
350
Watts
Operating Temperature
TJ
-55°C to 125°C
°C
TSTG
-55°C to 150°C
°C
Storage Temperature
Electrical Characteristics (TA = 25 °C unless otherwise noted)
VRWM
VB
IT
VC@1A
VC
IR
CT
(V)
(V)
(mA)
(V)
(V)
(µA)
(pF)
(max.)
(min.)
SD03C
3.3
4.0
SD05C
5.0
SD08C
PART
NUMBER
(max.)
(max.)
(@A)
(max.)
(max.)
1
7.5
16.0
20
40
450
6.0
1
9.8
18.0
17
10
200
8.0
8.5
1
13.4
24.0
15
2
120
SD12C
12.0
13.3
1
19.0
32.0
11
1
75
SD15C
15.0
16.7
1
24.0
38.0
10
1
68
SD18C
18.0
20.0
1
29.0
45.0
9
1
57
SD20C
20.0
22.3
1
35.0
50.0
8
1
52
SD24C
24.0
26.7
1
43.0
52.0
7
1
50
SD36C
36.0
40.0
1
60.0
75.0
4.5
1
35
!"#$!&/1 * Mar*/0'1
-2-
www.wpmtek.com
SDXXC
Integrated in
OVP&OCP products
3.3V~36V Ultra Low Capacitance
Bi-directional TVS Diode
provider
Typical Performance Characteristics (TA=25°C unless otherwise Specified)
!"#$!&/1 * Mar*/0'1
-3-
www.wpmtek.com
SDXXC
Integrated in
OVP&OCP products
3.3V~36V Ultra Low Capacitance
Bi-directional TVS Diode
provider
Soldering parameters
Pb-Free assembly
(see FIG.2)
Reflow Condition
Pre Heat
-Temperature Min (Ts(min))
+150℃
-Temperature Max(Ts(max))
+200℃
-Time (Min to Max) (ts)
60-180 secs.
Average ramp up rate (Liquid us Temp (TL) to peak)
3℃/sec. Max
Ts(max) to TL - Ramp-up Rate
3℃/sec. Max
Reflow
-Temperature(TL) (Liquid us)
+217℃
-Temperature(tL)
60-150 secs.
Peak Temp (Tp)
+260(+0/-5)℃
Time within 5℃ of actual Peak Temp (tp)
30 secs. Max
Ramp-down Rate
6℃/sec. Max
Time 25℃ to Peak Temp (TP)
8 min. Max
Do not exceed
+260℃
!"#$!&/1 *Mar*/0'1
-4-
www.wpmtek.com
SDXXC
Integrated in
OVP&OCP products
3.3V~36V Ultra Low Capacitance
Bi-directional TVS Diode
provider
Package mechanical data (mm/inch)
Suggested Land Pattern
Contact information
WPMTEK Incorporated Limited
Room 206-207,2nd Floor,Block 3,Minxing lndustry Park,Minzhi
Longhua New District,Shenzhen
TEL:86755-29308003
FAX:86755-23739900
WPMtek Incorporated Limited (WPM) reserves the right to make changes to the product specification and data in this document without notice. WPM
makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does WPM assume any liability
arising from the application or use of any products or circuits, and specifically dis- claims any and all liability, including without limitation special,
consequential or incidental damages.
!"#$!&/1 * Mar*/0'1
-5-
www.wpmtek.com
