LVF303015-2R2M-N

Cautions and Warnings Please be noted that this spec is only for reference if you have projects designed with the product number listed in. If you are looking for new project design-in, please find BWVF Series specification/datasheet on Chilisin website. Or you may find our sales contact for more information on old part number at your convenience. Appreciated your attention and understanding. Note: Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. Sealed Power Inductors – LVF Series LVF Series LVF series, an automatic assembly constructed power inductor, is shielded with magnetic resin and suitable for portable DC-DC converter applications. Features Applications            RoHS, Halogen Free and REACH Compliance Shielded with magnetic resin Various package size and wide inductance range Optimize electrical characteristics by using different ferrite core figures Smartphones, tablets and wearable devices DSC, camcorders AP Routers STBs LCD TVs, monitors and panels Game consoles DC/DC converters Product Identification Shape and Dimensions Figure 1 Figure 2 Recommended Pattern Dimensions in mm TYPE FIG A B C D H I J LVF201B12 1 2.0±0.25 1.6±0.25 1.2±0.05 0.6 1.8 0.8 0.8 LVF252A10 1 2.5±0.25 2.0±0.25 1.02 Max 0.8 2.2 0.85 0.8 LVF252A12 1 2.5±0.25 2.0±0.25 1.2±0.05 0.8 2.2 0.85 0.8 LVF303010 2 3.0±0.20 3.0±0.20 1.02 Max 1.0 3.2 1.1 1.0 LVF303012 2 3.0±0.20 3.0±0.20 1.2 Max 1.0 3.2 1.1 1.0 LVF303015 2 3.0±0.20 3.0±0.20 1.5 Max 1.0 3.2 1.1 1.0 LVF404012 2 4.0±0.20 4.0±0.20 1.2±0.1 1.5 4.2 1.5 1.2 Sealed Power Inductors – LVF Series Shape and Dimensions Recommended Pattern Figure 3 Dimensions in mm TYPE FIG A B C D H I J LVF404015 3 4.0±0.25 4.0±0.25 1.5±0.2 1.3 3.7 1.5 1.2 LVF404018 3 4.0±0.20 4.0±0.20 1.9 Max 1.3 3.7 1.5 1.2 LVF404026 3 4.0±0.20 4.0±0.25 2.6±0.2 1.4 3.7 1.6 1.2 Shapes and Dimensions Recommended Pattern Figure 4 Dimensions in mm TYPE FIG A B C D H I J LVF505020 4 5.0±0.20 5.0±0.20 2.0±0.2 1.8±0.3 4.2 1.6 2.0 LVF606020 4 6.0±0.20 6.0±0.20 2.0±0.2 1.7±0.3 5.7 1.7 2.8 LVF606028 4 6.0±0.20 6.0±0.20 2.8±0.2 1.9±0.3 5.7 1.8 2.6 8.0±0.20 4.0+0.2-0.30 2.3±0.3 7.5 2.5 3.4 LVF808040 4 8.0±0.20 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF201B12-R47□-N 0.47 20, 30 1 0.051 2.70(2.43) 2.30(2.07) A LVF201B12-R68□-N 0.68 20, 30 1 0.074 2.20(1.98) 2.00(1.80) L LVF201B12-1R5□-N 1.5 20, 30 1 0.130 1.60(1.44) 1.45(1.30) D LVF201B12-6R8□-N 6.8 20, 30 1 0.465 0.82(0.73) 0.78(0.70) H Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4287A+Agilent HP16197A, 1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 10 80 1R5 70 6R8 R68 R47 8 6R8 6 △ T(℃ ) L(uH) 60 4 40 30 20 1R5 2 50 R68 10 R47 0 0 0 0.5 1 1.5 2 2.5 DC Current(A) 3 3.5 4 0 0.5 1 1.5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 2 2.5 3 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF252A10-R47□-N 0.47 20, 30 1 0.045 2.80(2.52) 2.30(2.07) A LVF252A10-1R0□-N 1.0 20, 30 1 0.066 1.98(1.78) 2.05(1.84) B LVF252A10-1R5□-N 1.5 20, 30 1 0.095 1.70(1.53) 1.85(1.66) C LVF252A10-4R7□-N 4.7 20, 30 1 0.285 0.92(0.82) 0.95(0.85) F LVF252A10-100□-N 10 20, 30 1 0.535 0.60(0.54) 0.70(0.63) H LVF252A10-150□-N 15 20, 30 1 0.810 0.50(0.45) 0.55(0.49) I LVF252A10-220□-N 22 20, 30 1 1.200 0.40(0.36) 0.44(0.39) J Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4287A+Agilent HP16197A, 1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Tem perature Change vs. DC Current Inductance vs. DC Current 80 22.0 20.0 70 220 16.0 △ T( ℃ ) L(uH) 150 10.0 100 8.0 6.0 R47 40 30 10 1R5 2.0 50 20 4R7 4.0 1R5 1R0 60 14.0 12.0 4R7 220 150 100 18.0 1R0 R47 0 0.0 0 0.5 1 1.5 2 2.5 DC Current(A) 3 3.5 4 0 0.5 1 1.5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 2 2.5 3 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF252A12-R50□-N 0.50 20, 30 1 0.028 3.50(3.15) 3.00(2.70) B LVF252A12-1R0□-N 1.0 20, 30 1 0.050 2.50(2.25) 2.40(2.16) C LVF252A12-1R2□-N 1.2 20, 30 1 0.053 2.10(1.89) 2.35(2.11) D LVF252A12-1R5□-N 1.5 20, 30 1 0.068 1.95(1.75) 2.30(2.07) E LVF252A12-2R2□-N 2.2 20, 30 1 0.080 1.80(1.62) 1.80(1.62) F LVF252A12-3R3□-N 3.3 20, 30 1 0.130 1.45(1.30) 1.50(1.35) G LVF252A12-4R7□-N 4.7 20, 30 1 0.190 1.10(0.99) 1.10(0.99) H LVF252A12-5R6□-N 5.6 20, 30 1 0.210 1.05(0.94) 1.00(0.90) I LVF252A12-6R8□-N 6.8 20, 30 1 0.300 0.95(0.85) 0.80(0.72) J LVF252A12-100□-N 10 20, 30 1 0.385 0.88(0.79) 0.70(0.63) K LVF252A12-150□-N 15 20, 30 1 0.570 0.68(0.61) 0.62(0.55) L LVF252A12-220□-N 22 20, 30 1 0.810 0.55(0.49) 0.53(0.47) M Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4287A+Agilent HP16197A, 1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 70 5R6 150 20 3R3 60 220 △ T(℃ ) L(uH) 220 50 15 150 10 100 R50 1R5 4R7 6R8 1R0 2R2 40 30 100 20 6R8 5 5R6 4R7 3R3 2R2 10 1R5 1R0 R50 0 0 0 0.5 1 1.5 2 2.5 DC Current(A) 3 3.5 4 0 0.5 1 1.5 2 2.5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3 3.5 4 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF303010-1R5□-N 1.5 20, 30 1 0.085 1.80(1.62) 1.70(1.53) 1R5 LVF303010-2R2□-N 2.2 20, 30 1 0.100 1.50(1.35) 1.40(1.26) 2R2 LVF303010-4R7□-N 4.7 20, 30 1 0.205 1.00(0.90) 0.95(0.85) 4R7 LVF303010-6R8□-N 6.8 20, 30 1 0.310 0.87(0.78) 0.85(0.76) 6R8 LVF303010-100□-N 10 20, 30 1 0.430 0.64(0.57) 0.63(0.56) 100 LVF303010-150□-N 15 20, 30 1 0.625 0.56(0.50) 0.55(0.49) 150 LVF303010-220□-N 22 20, 30 1 0.870 0.47(0.42) 0.46(0.41) 220 LVF303010-470□-N 47 20, 30 1 1.750 0.29(0.26) 0.28(0.25) 470 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4287A+Agilent HP16197A, 1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 25 70 60 20 220 220 150 100 1R5 6R8 2R2 4R7 50 △ T(℃ ) L(uH) 15 150 10 40 30 100 20 6R8 5 4R7 10 2R2 1R5 0 0 0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 DC Current(A) 1.8 2 2.2 2.4 2.6 0 0.2 0.4 0.6 0.8 1 1.2 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 1.4 1.6 1.8 2 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF303012-2R2□-N 2.2 20, 30 1 0.092 2.10(1.89) 2.00(1.80) 2R2 LVF303012-3R3□-N 3.3 20, 30 1 0.13 1.84(1.65) 1.80(1.62) 3R3 LVF303012-4R7□-N 4.7 20, 30 1 0.18 1.56(1.40) 1.52(1.36) 4R7 LVF303012-6R8□-N 6.8 20, 30 1 0.25 1.32(1.18) 1.30(1.17) 6R8 LVF303012-100□-N 10 20, 30 1 0.42 1.06(0.95) 1.00(0.90) 100 LVF303012-150□-N 15 20, 30 1 0.56 0.82(0.73) 0.80(0.72) 150 LVF303012-220□-N 22 20, 30 1 0.86 0.64(0.57) 0.62(0.55) 220 LVF303012-470□-N 47 20, 30 1 1.82 0.49(0.44) 0.43(0.38) 470 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4287A+Agilent HP16197A, 1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 50 80 220 45 70 470 40 6R8 30 △ T(℃ ) L(uH) 150 60 35 25 20 220 15 150 10 6R8 4R7 3R3 0.2 0.4 0.6 0.8 1 1.2 2R2 4R7 50 3R3 40 30 10 2R2 0 0 100 20 100 5 470 1.4 1.6 1.8 DC Current(A) 2 2.2 2.4 2.6 2.8 0 0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 1.8 2 2.2 2.4 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF303015-R47□-N 0.47 20, 30 1 0.036 4.7(4.23) 4.0(3.60) R47 LVF303015-1R0□-N 1.0 20, 30 1 0.054 3.4(3.06) 3.0(2.70) 1R0 LVF303015-1R5□-N 1.5 20, 30 1 0.063 3.0(2.70) 2.6(2.34) 1R5 LVF303015-2R2□-N 2.2 20, 30 1 0.090 2.3(2.07) 2.0(1.80) 2R2 LVF303015-3R3□-N 3.3 20, 30 1 0.125 1.9(1.71) 1.80(1.62) 3R3 LVF303015-4R7□-N 4.7 20, 30 1 0.170 1.58(1.42) 1.52(1.36) 4R7 LVF303015-6R8□-N 6.8 20, 30 1 0.235 1.34(1.20) 1.30(1.17) 6R8 LVF303015-100□-N 10 20, 30 1 0.360 1.06(0.95) 1.00(0.90) 100 LVF303015-150□-N 15 20, 30 1 0.550 0.90(0.81) 0.80(0.72) 150 LVF303015-220□-N 22 20, 30 1 0.770 0.76(0.68) 0.65(0.58) 220 LVF303015-330□-N 33 20, 30 1 0.930 0.65(0.58) 0.60(0.54) 330 LVF303015-470□-N 47 20, 30 1 1.500 0.52(0.46) 0.42(0.37) 470 LVF303015-101□-N 100 20, 30 1 2.700 0.36(0.32) 0.3(0.27) 101 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4287A+Agilent HP16197A, 1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 25 80 220 70 20 220 150 100 15 △ T(℃ ) L(uH) 60 150 10 100 6R8 5 3R3 2R2 1R5 0 1 1.5 R47 1R0 3R3 40 30 10 1R0 R47 0.5 4R7 50 1R5 2R2 20 4R7 0 6R8 2 2.5 DC Current(A) 3 3.5 4 0 4.5 0 0.5 1 1.5 2 2.5 3 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3.5 4 4.5 5 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF404012-3R3□-N 3.3 20, 30 1 0.072 1.52(1.36) 2.10(1.89) 3R3 LVF404012-100□-N 10 20, 30 1 0.190 0.90(0.81) 1.20(1.08) 100 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4284A+Agilent HP42841A.1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 12 70 10 60 3R3 100 50 △ T(℃ ) L(uH) 8 100 6 4 40 30 20 2 10 3R3 0 0 0 0.5 1 1.5 DC Current(A) 2 2.5 3 0 0.5 1 1.5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 2 2.5 3 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (MHz) LVF404015-R47□-N 0.47 20, 30 1 0.019 4.00(3.60) 4.20(3.78) R47 LVF404015-1R5□-N 1.5 20, 30 1 0.041 3.00(2.70) 3.2(2.88) 1R5 LVF404015-2R2□-N 2.2 20, 30 1 0.054 2.30(2.07) 2.60(2.34) 2R2 LVF404015-4R7□-N 4.7 20, 30 1 0.100 1.60(1.44) 1.80(1.62) 4R7 LVF404015-6R8□-N 6.8 20, 30 1 0.138 1.40(1.26) 1.60(1.44) 6R8 LVF404015-100□-N 10 20, 30 1 0.200 1.00(0.90) 1.20(1.08) 100 LVF404015-150□-N 15 20, 30 1 0.300 0.92(0.82) 1.05(0.94) 150 LVF404015-220□-N 22 20, 30 1 0.400 0.72(0.64) 0.85(0.76) 220 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4284A+Agilent HP42841A.1MHz 200mV RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 25 90 80 220 20 220 150 100 6R8 4R7 70 2R2 1R5 R47 △ T(℃ ) L(uH) 60 15 150 10 20 6R8 4R7 2R2 10 1R5 R47 0 0 0 0.5 1 1.5 40 30 100 5 50 2 2.5 3 3.5 DC Current(A) 4 4.5 5 5.5 6 0 0.5 1 1.5 2 2.5 3 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3.5 4 4.5 5 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (kHz) LVF404018-1R0□-N 1.0 20, 30 100 0.0265 4.2(3.78) 3.8(3.42) 1R0 LVF404018-1R5□-N 1.5 20, 30 100 0.0370 3.5(3.15) 3.2(2.88) 1R5 LVF404018-2R2□-N 2.2 20, 30 100 0.0470 3.0(2.70) 2.7(2.43) 2R2 LVF404018-3R3□-N 3.3 20, 30 100 0.0625 2.3(2.07) 2.1(1.89) 3R3 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment： L：Agilent HP4284A+Agilent HP42841A, 100kHz 1V RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 5 70 4.5 60 4 3R3 1R5 1R0 50 3.5 3 △ T(℃ ) L(uH) 2R2 3R3 2.5 2 2R2 1.5 40 30 20 1R5 1 1R0 10 0.5 0 0 0 0.5 1 1.5 2 2.5 3 3.5 DC Current(A) 4 4.5 5 5.5 6 0 0.5 1 1.5 2 2.5 3 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3.5 4 4.5 5 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (kHz) LVF404026-1R0□-N 1.0 20, 30 100 0.030 5.00(4.50) 4.00(3.60) 1R0 LVF404026-1R5□-N 1.5 20, 30 100 0.035 4.20(3.78) 3.70(3.33) 1R5 LVF404026-2R2□-N 2.2 20, 30 100 0.045 3.80(3.42) 3.50(3.15) 2R2 LVF404026-3R3□-N 3.3 20, 30 100 0.067 3.00(2.70) 2.50(2.25) 3R3 LVF404026-4R7□-N 4.7 20, 30 100 0.092 2.60(2.34) 2.00(1.80) 4R7 LVF404026-5R6□-N 5.6 20, 30 100 0.110 2.30(2.07) 1.90(1.71) 5R6 LVF404026-6R8□-N 6.8 20, 30 100 0.130 2.00(1.80) 1.70(1.53) 6R8 LVF404026-100□-N 10 20, 30 100 0.188 1.90(1.71) 1.40(1.26) 100 LVF404026-150□-N 15 20, 30 100 0.240 1.45(1.30) 1.20(1.08) 150 LVF404026-220□-N 22 20, 30 100 0.330 1.22(1.09) 1.00(0.90) 220 LVF404026-330□-N 33 20, 30 100 0.480 1.00(0.90) 0.82(0.73) 330 LVF404026-470□-N 47 20, 30 100 0.735 0.88(0.79) 0.64(0.57) 470 LVF404026-101□-N 100 20, 30 100 1.380 0.58(0.52) 0.50(0.45) 101 LVF404026-331□-N 330 20, 30 100 4.600 0.31(0.27) 0.25(0.22) 331 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment：  L：Agilent HP4284A+Agilent HP42841A, 100kHz 1V RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 35 70 330 30 60 25 50 330 220150100 6R8 4R7 2R2 1R5 3R3 1R0 △ T(℃ ) L(uH) 220 20 150 15 100 40 30 20 10 6R8 5 4R7 3R3 10 2R2 1R5 1R0 0 0 1 2 3 4 5 DC Current(A) 6 7 0 8 0 0.5 1 1.5 2 2.5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3 3.5 4 4.5 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (kHz) LVF505020-1R0□-N 1.0 20, 30 100 0.018 6.0(5.40) 4.1(3.69) 1R0 LVF505020-1R5□-N 1.5 20, 30 100 0.023 4.9(4.41) 3.5(3.15) 1R5 LVF505020-1R8□-N 1.8 20, 30 100 0.026 4.1(3.60) 3.4(3.00) 1R8 LVF505020-2R2□-N 2.2 20, 30 100 0.030 4.0(3.60) 3.3(2.97) 2R2 LVF505020-3R6□-N 3.6 20, 30 100 0.050 3.1(2.70) 2.7(2.40) 3R6 LVF505020-3R9□-N 3.9 20, 30 100 0.053 2.9(2.61) 2.6(2.34) 3R9 LVF505020-4R7□-N 4.7 20, 30 100 0.060 2.7(2.43) 2.2(1.98) 4R7 LVF505020-6R8□-N 6.8 20, 30 100 0.093 2.2(1.98) 1.8(1.62) 6R8 LVF505020-100□-N 10 20, 30 100 0.125 1.8(1.62) 1.6(1.44) 100 LVF505020-150□-N 15 20, 30 100 0.195 1.4(1.26) 1.2(1.08) 150 LVF505020-220□-N 22 20, 30 100 0.265 1.2(1.08) 1.0(0.90) 220 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment：  L：Agilent HP4284A+Agilent HP42841A, 100kHz 1V RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current 70 21 60 18 150 9 100 6 3 100 6R8 4R7 3R9 2R2 1R5 1R0 50 15 12 150 220 220 △ T(℃ ) L(uH) Tem perature Change vs. DC Current 24 40 30 20 6R8 4R7 3R9 2R2 10 1R5 1R0 0 0 0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9 DC Current(A) 0 0.5 1 1.5 2 2.5 3 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3.5 4 4.5 5 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (kHz) LVF606020-4R7□-N 4.7 20, 30 100 0.058 3.0(2.70) 2.3(2.07) 4R7 LVF606020-100□-N 10 20, 30 100 0.130 2.1(1.89) 1.6(1.44) 100 LVF606020-150□-N 15 20, 30 100 0.195 1.6(1.44) 1.3(1.17) 150 LVF606020-220□-N 22 20, 30 100 0.260 1.3(1.17) 1.1(0.99) 220 LVF606020-470□-N 47 20, 30 100 0.510 0.9(0.80) 0.8(0.72) 470 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment：  L：Agilent HP4284A+Agilent HP42841A, 100kHz 1V RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 80 50 45 40 △ T(℃ ) 30 25 20 150 220 15 150 50 40 30 20 100 10 4R7 100 470 60 470 35 L(uH) 220 70 4R7 5 10 0 0 0 0.5 1 1.5 2 2.5 3 DC Current(A) 3.5 4 4.5 5 0 0.5 1 1.5 2 2.5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 3 3.5 4 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (kHz) LVF606028-1R0□-N 1.0 20, 30 100 0.012 7.9(7.11) 6.3(5.67) 1R0 LVF606028-1R5□-N 1.5 20, 30 100 0.015 7.0(6.30) 5.5(4.95) 1R5 LVF606028-2R2□-N 2.2 20, 30 100 0.020 6.0(5.40) 5.0(4.50) 2R2 LVF606028-4R7□-N 4.7 20, 30 100 0.036 4.0(3.60) 3.4(3.06) 4R7 LVF606028-6R8□-N 6.8 20, 30 100 0.048 3.2(2.88) 3.0(2.70) 6R8 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment：  L：Agilent HP4284A+Agilent HP42841A, 100kHz 1V RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Inductance vs. DC Current Tem perature Change vs. DC Current 10 70 6R8 60 4R7 2R2 1R5 8 1R0 6 △ T(℃ ) L(uH) 50 6R8 4 40 30 4R7 20 2R2 2 10 1R5 1R0 0 0 0 1 2 3 4 5 6 7 8 DC Current(A) 9 10 11 12 13 14 0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 5.5 6 6.5 7 7.5 8 Sealed Power Inductors – LVF Series – LVS252012 Series Electrical Characteristics Test Inductance Tolerance Part Number RDC Isat (A) Irms (A) (Ω) ±30% Typ. (Max) Typ. (Max) Frequency (uH) Marking (±%) (kHz) LVF808040-4R7□-N 4.7 20, 30 100 0.020 6.8(6.12) 5.5(4.95) 4R7 LVF808040-100□-N 10 20, 30 100 0.038 5.0(4.50) 3.8(3.42) 100 LVF808040-150□-N 15 20, 30 100 0.057 4.0(3.60) 3.2(2.88) 150 LVF808040-220□-N 22 20, 30 100 0.082 3.4(3.06) 2.7(2.43) 220 Note: When ordering, please specify tolerance code. Tolerance: M=±20% , T =±30%  Operating temperature range－55℃～125℃(Including self - temperature rise)  Isat for Inductance drop 30% from its value without current  Irms for a 40℃ temperature rise from 25℃ ambient with current  Measure Equipment：  L：Agilent HP4284A+Agilent HP42841A, 100kHz 1V RDC：DIGITAL MILLINHM METER CHROMA 16502, or equivalent Isat & Irms：Agilent HP4284A Test Instruments：HP4284A Material/Impedance Analyzer Tem perature Change vs. DC Current 80 70 220 150 100 4R7 60 △ T( ℃ ) L(uH) Inductance vs. DC Current 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 0 220 150 100 50 40 30 20 4R7 10 0 0 1 2 3 4 5 6 DC Current(A) 7 8 9 10 0 1 2 3 4 5 6 DC Current(A) Please be sure to request approval specifications that provide further details of the products. Kindly note that the content of these specifications are subject to change or may be discontinued without prior notice. This product may not be designed/used in medical or high risk applications without Chilisin approval. Please contact our sales department before ordering. 7 8 9 10 Sealed Power Inductors – LVF Series Packaging Specifications Tape Dimensions Tape Dimensions Figure 1 Figure 2 Reel Dimensions Reel Dimensions Figure 1 Figure 2 Dimensions in mm Tape Dimensions TYPE Reel Dimensions Quantity Fig A0 B0 K0 D E F W P P0 P2 A B C D E PCS / Reel LVF201B12 1 1.90 2.20 1.30 1.55 1.75 3.5 8.1 4 4 2 180 60 13 14.4 8.4 2000 LVF252A10 1 2.40 2.70 1.15 1.55 1.75 3.5 8.1 4 4 2 180 60 13 14.4 8.4 2000 LVF252A12 1 2.40 2.70 1.35 1.55 1.75 3.5 8.1 4 4 2 180 60 13 14.4 8.4 2000 LVF303010 1 3.20 3.20 1.40 1.55 1.75 3.5 8.1 4 4 2 180 60 13 14.4 8.4 2000 LVF303012 1 3.20 3.20 1.40 1.55 1.75 3.5 8.1 4 4 2 180 60 13 14.4 8.4 2000 LVF303015 1 3.15 3.15 1.60 1.55 1.75 3.5 8.1 4 4 2 180 60 13 14.4 8.4 2000 LVF404012 2 4.25 4.25 1.30 1.55 1.75 5.5 12 8 4 2 178 60 13 13.2 - 1000 LVF404015 2 4.25 4.25 1.70 1.55 1.75 5.5 12 8 4 2 178 60 13 13.2 - 1000 LVF404018 2 4.25 4.25 2.10 1.55 1.75 5.5 12 8 4 2 178 60 13 13.2 - 800 LVF404026 2 4.25 4.25 3.00 1.55 1.75 5.5 12 8 4 2 178 60 13 13.2 - 500 LVF505020 2 5.25 5.25 2.20 1.55 1.75 5.5 12 8 4 2 330 100 13 13.4 - 2000 LVF606020 2 6.25 6.25 2.20 1.55 1.75 7.5 16 12 4 2 330 100 13 16.0 - 2000 LVF606028 2 6.25 6.25 3.00 1.55 1.75 7.5 16 12 4 2 330 100 13 16.0 - 1500 LVF808040 2 8.25 8.25 4.15 1.55 1.75 7.5 16 12 4 2 330 100 13 16.0 - 1000
