TPSP1003-01ETG

TPSP1003-01ETG 1-Line Uni-directional TVS Diode WWW.SOT23.COM.TW Features ● ● Operating voltage: 5V  Package: DFN1006-2 Complies with following standards: – IEC 61000-4-2 (ESD) immunity test Air discharge: ±30kV Contact discharge: ±30kV – IEC61000-4-4 (EFT) 40A (5/50ns)  Lead Finish: Matte Tin  UL Flammability Classification Rating 94V-0  Pb-Free, Halogen Free, RoHS/WEEE Compliant RoHS Compliant Applications l l l l l Ordering Information Reel Size 5000 7” 舟 TPSP1003-01ETG Qty per Reel 电 Part Number Cellular phones audio MP3 players Digital cameras Portable applicationss mobile telephone 子 ● Mechanical Characteristics 台 Dimensions and Pin Configuration 0.6 0.5 A 1.0 1 - 2 WWW.TECHPUBLIC.COM.TW TPSP1003-01ETG 1-Line Uni-directional TVS Diode WWW.SOT23.COM.TW Absolute Maximum Ratings (TA=25°C unless otherwise specified) Rating Symbol IEC 61000-4-2 (ESD) discharge Air Contact discharge Value Unit ±30 ±30 kV kV Total Power Dissipation on FR-5 Board (Note 1) @ TA=25℃ PD 150 mW Junction and Storage Temperature Range TJ,TSTG -55 to 150 ℃ Lead Solder Temperature – Maximum (10 Second Duration) TL 260 ℃ Parameter IPP Maximum Reverse Peak Pulse Current VC Clamping Voltage @ IPP IR VBR Working Peak Reverse Voltage Maximum Reverse Leakage Current @ VRWM Breakdown Voltage @ IT Test Current IF Forward Current VF Forward Voltage @ IF Ppk Peak Power Dissipation VC VBR VRWM Capacitance @ VR = 0 and f = 1.0 MHz TPSP1003-01ETG Uni−Directional TVS VRWM (V) IR (μA) @ VRWM Max Max Min 5.0 0.2 6.2 Device V IR VF IT IPP 台 IT C IF 舟 VRWM I 电 Symbol 子 Electrical Characteristics (TA=25°C unless otherwise specified) VBR IT IPP (V) （mA） (A) @ IT (Note 2) (Note 3) Max 1.0 8.5 VC (V) @ Max IPP (Note 3) PPK (W) (8*20 μs) C (pF) Max Typ Typ 12.3 100 75 WWW.TECHPUBLIC.COM.TW TPSP1003-01ETG 1-Line Uni-directional TVS Diode WWW.SOT23.COM.TW PROTECTION PRODUCTS Typical charateristics Fig2. ESD Pulse Waveform (according to IEC 61000-4-2) Fig1. 8/20µ s Pulse Waveform tr 100 100% TEST WAVEFORM PARAMETERS tr=8 s td=20 s Peak Value IPP 80 Percent of Peak Pulse Current % 60 40 td=t IPP/2 20 0 0 10 5 15 20 25 Power Derating Curve 110 100 Time (ns) 30ns 60ns 90 80 70 60 50 40 30 20 10 0 台 % of Rated Power 30 tr = 0.7~1ns 舟 Fig3. 10% 电 t - Time ( s) 90% 子 IPP - Peak Pulse Current - % of IPP 120 0 25 50 75 100 125 150 Ambient Temperature –TA (ºC) WWW.TECHPUBLIC.COM.TW TPSP1003-01ETG 1-Line Uni-directional TVS Diode WWW.SOT23.COM.TW Outline Drawing - DFN1006-2 A B D DIMENSIONS MILLIMETERS INCHES DIM MIN NOM MAX MIN NOM MAX E TOP VIEW A C A1 PIN 1 ID 0.40 0.50 0.55 0.00 0.03 0.05 0.45 0.50 0.55 0.90 1.00 1.10 0.50 0.60 0.70 0.65 BSC 0.20 0.25 0.30 0.05 0.10 0.15 2 0.08 0.10 电 R bxN bbb C A B .016 .020 .022 .000 .001 .002 .018 .020 .022 .035 .039 .043 .020 .024 .028 .026 BSC .008 .010 .012 .002 .004 .006 2 .003 .004 子 SEATING PLANE aaa C A A1 b D E e L R N aaa bbb 2x L e 舟 BOTTOM VIEW 台 Land Pattern - DFN1006-2 DIMENSIONS Y (C) Z G DIM C G X Y Z INCHES (.033) .012 .024 .022 .055 MILLIMETERS (0.85) 0.30 0.60 0.55 1.40 X WWW.TECHPUBLIC.COM.TW
