深圳市琦捷电子有限公司
承
认
书
SPECIFICATION
品
STYLE
规
名
电池座
NAME
格
CR1220-2
SIZE
客户名称
CUSTOMER
客户物料号
CUSTOMER TYPE
客户承认
CUSTOMER APPROVED
APPROVED
CHECKED
PREPARED
客户承认
核准
制订
刘仲训
2020.2.25
徐
亮
2020.2.25
产品规格书
PRODUCT SPECIFICATION
版 本 REVISION:
产品系列Product Series:
A/1
BATTERY JACK
修订REVISED BY:
徐亮
页码SHEET No.
审核CHECKED BY:
刘仲训
批准APPROVED BY:
刘奇
1
of
3
发布日期lssued Date:
2020-2-25
1.0 适用范围SCOPE
该规格书包含和覆盖纽扣式电池插座产品必要的机械性能、电气性能、环境性能及相关的测试方法。
This Product Specification covers the mechanical, electrical and environmental performances requirements
and test methods for BATTERY JACK series products.
2.0 说明APPLICABLE DOCUMENTS AND SPECIFICATIONS
所列入的所有文件中,如产品图和规格书有冲突的地方,请以产品图为准。如参考文件和规格书有冲突
的地方,请以规格书为准。 The following documents form a part of this specification to the extent specifed
herewith. In the event of conflict between the requirements of the specifcation and the product drawing,
the product drawing shall take precedence. In the event of confict between the requirements of the
specification and the referenced documents, this specification shall take precedence.
3.0 材质和结构尺寸MATERIAL AND CONSTRUCTION
产品的材质、结构及尺寸,请参考产品图。 Material、construction and physical dimensions refer to
product drawings.
4.0 产品性能及实验说明PERFORMANCE AND TEST DESCRIPTION
4.1 产品所必须具备的机械、电气、环境性能,请参照5.0 。Connector shall be designed to meet the
electrical, mechanical and environmental performances requirements specified in 5.0.
4.2 额定电压VOLTAGE:
12V DC
4.3 额定电流CURRENT: 0.5ADC
4.4 温度条件TEMPERATURE
工作温度Operating Temperature Range: -40℃ to +80℃
贮藏温度 Storage Temperature Range: -10℃ to +55℃
5.0 机械、电气、环境性能及测试方法Test Requirements and Procedures
NO.
DESCRIPTION
接触电阻
5.1
Contact
Resistance
绝缘电阻
5.2
Insulation
Resistance
TEST
CONDITION
REQUIREMENT
开放电压20mV以下,短路电流10mA的状态下测定。
Measure by dry circuit,20 mV MAX,10 mA.
30 mΩ MAX
相邻端子间或端子与地面间加DC500V下测定。 Apply
500V DC between adjacent terminal or ground.
100 M2 MIN
产品规格书
PRODUCT SPECIFICATION
版本REVISION:
A/1
审核CHECKED BY;
批准APPROVED BY:
刘仲训
刘奇
产 品 系 列 Product Series:
BATTERY JACK
修订REVISED BY;
徐亮
NO.
耐电压
5.3
Dielectric
Withstanding
Voltage
插入力/拔出力
5.4
5.5
5.6
TEST
DESCRIPTION
Insertion Forcel
Withdrawal
Force
寿命试验
Life Test
耐盐雾性
Salt Spray
页码SHEET No.
2 of 3
发布日期lssued Date:
2020-2-25
REQUIREMENT
CONDITION
相邻端子间或端子与地面间加AC500V(有效值)持续1
分 钟 下 测 定 。 Apply 5 0 0 V AC( ms. ) for 1 minute
between adjacent terminal or ground.
以每分钟25±3mm的速度,平行地插入、拔出。
无击穿、飞弧
No Breakdown
Insert
and withdraw connectors at a rate of 25±3mm per
5~30N
minute
以每小时100 ±20次的频率机械性插拔1500次。
Automatic cycling:1500 cycles at 100±20 cycles per
hour
使用35±2℃、5±1%的盐水喷雾24小时;试验后常温
水洗,再室温干燥。
24 hours exposure to a salt spray
from the 5±1% solution at 35±2℃
满足以下要求
satisfy the
following
接触电阻:100 m
2 MAX
5.2/5.3/5.4
外观无损坏
No Damage
接触电阻Contact
Resistance:100
m 2 MAX
5.7
塑胶基准面1.2mm以下端子部分浸入245±5℃的锡槽
中,历时2-3秒。 Soldering Time:2-3 sec.Soldering
Solder ability
Temperature:245±5℃ 1.2 mm from housing tip.
可焊性
耐焊接热
5.8
5.9
Resistance to
Soldering heat
高温试验
Heat test
塑胶基准面0.2mm以下端子部分浸入265±5℃的锡槽
中,历时10±0.5秒。 Soldering Time:10±0.5 sec
Soldering Temperature:265±5℃ 0.2 mm from
housing tip
锡沾覆面积90%以
上 90% of
immersed area
must show
无损坏、变形
No Damage
满足以下要求
satisfy the
把产品放置85℃±2℃的试验环境下,持续96小时。
following
The jack shall be subjected to temperature of 85℃±
接触电阻:50 mΩ
2℃ for a period of 96 hours.
MAX
5.215.3/5.4
产品规格书
PRODUCT SPECIFICATION
版本 REVISION:
产品系列 Product Series:
修订REVISED BY:
审核CHECKED BY:
徐亮
刘仲训
5.10
5.11
DESCRIPTION
低温试验
Cold test
高温高湿测试
Humidity test
高低温循环
5.12
3 of 3
A/1
BATTERY JACK
NO.
页码SHEET No .
批准 APPROVED BY:
发布日期lssued Date:
刘奇
TEST
CONDITION
2020-2-25
REQUIREMENT
把产品放置-25℃±2℃的试验环境下,持续96小时。
The jack shall be subjected to temperature of -25℃±
2℃ for a period of 96 hours.
满足以下要求
把产品放置在温度40℃±2℃、相对湿度90~95%以上的
satisfy the
试验环境下,持续96小时。The jack shall be subjected
following
to temperature of 40℃±2℃,90~95%RH for a
接触电阻:50 m Ω
period of 96 hours
MAX
把产品在-40~+80℃循环变化温度环境下,每临界温度持
续半小时,持续循环5次。
5.2/5.3/5.4
The Jack shall be subjected
(冷热冲击试验)
to the conditions of -40~+80℃ cyclic test, remain in
Temperature
each temperature for 0.5 hour, changing time is three
cyclic test
minute less, 5 cycles of following test.
6.0 包装要求,详见附包装图Package refer to Packing Drawings.
7.0 环保要求 Requirements of Environmental Protection
产品所有材质符合 RoHS或客户其他特殊要求 All of material used by the product must comply with
RoHS and special requirements.
