Version: 1.2 Document code：SL1210 Low R Effective date ：2015-09-02 Page: 1 of 5 Surface-Mount Device Feature SL1210 ROHS  Resettable over current and over temperature protection ● Low resistance  Small size of 1210 ● Fast time-to-trip  Small footprint ● ROHS complaint Application Part Numbering Product Dimensions in Millimeter Part Number A B C D E Max Min Min 0.4 -0.4 1.0 0.25 0.10 1.0 0.25 0.10 0.4 -0.4 1.0 0.25 0.10 1.0 0.25 0.10 Min Max Min Max SL1210150 3.00 3.50 2.35 2.85 SL1210175 3.50 -- 2.35 -2.35 2.85 SL1210190 3.00 0 3.00 SL1210200 -3.00 3.50 -- 2.85 SL1210210 3.50 0.25 0.10 2.85 1.2 0.25 0.10 SL1210250 -3.00 3.50 2.35 -2.35 0.4 -0.5 1.0 SL1210230 3.00 0 3.00 2.35 -2.35 2.85 0.5 1.2 0.25 0.10 2.35 -2.35 2.85 0.5 1.2 0.25 0.10 SL1210300 3.00 0 3.00 3.50 -- 2.85 0.5 1.2 0.25 0.10 SL1210350 -3.00 3.50 -- 2.85 0.5 1.2 0.25 0.10 SL1210380 3.50 2.85 0.5 1.2 0.25 0.10 SL1210400 3.00 0 3.00 2.35 -2.35 0.5 1.2 0.25 0.10 SL1210450 3.50 2.35 -2.35 2.85 -3.00 2.85 0.5 1.2 0.25 0.10 SL1210500 3.50 -- 2.35 -2.35 2.85 0.6 -0.6 1.5 0.25 0.10 SL1210550 3.00 0 3.00 1.5 0.25 0.10 SL1210600 -3.00 3.50 -- 1.5 0.25 0.10 SL1210650 3.00 0 3.50 -0.6 0.6- SL1210260 Polymer PTC Thermistor 3.50 3.50 -- 3.50 3.50 -- 3.50 2.35 -2.35 2.85 2.85 2.85 2.85 Min 2.85 1.5 0.25 -Specifications are subject to change without notice 0.10 www.sealand-pptc.com Version: 1.2 Document code：HB-WI7.3-162-2013 Effective date ：2015-02-07 Page: 2 of 5 Surface-Mount Device SL1210 ROHS Electrical Characteristics Part Number I(A) Vmax I max Pdtyp 25℃ -- -- -- Ttrip Rmin 25℃ Rmax R1max 25℃ Hold Trip (V) (A) (W) Curren t(A) SL1210150 1.50 3.0 6.0 50 1.2 8.0 0.5 0.005 0.012 0.050 SL1210175 1.75 3.5 6.0 50 1.2 8.0 1.0 0.005 0.012 0.040 SL1210190 1.90 3.8 6.0 50 1.2 8.0 3.0 0.005 0.011 0.035 SL1210200 2.00 4.0 6.0 50 1.2 8.0 3.0 0.005 0.011 0.032 SL1210210 2.10 4.2 6.0 50 1.2 8.0 5.0 0.005 0.010 0.030 SL1210230 2.30 4.6 6.0 50 1.2 8.0 5.0 0.005 0.010 0.028 SL1210250 2.50 5.0 6.0 50 1.2 8.0 5.0 0.004 0.009 0.025 SL1210260 2.60 5.2 6.0 50 1.2 12.0 5.0 0.004 0.009 0.020 SL1210300 3.00 6.0 6.0 50 1.2 12.0 5.0 0.004 0.008 0.018 SL1210350 3.50 7.0 6.0 50 1.2 12.0 5.0 0.003 0.008 0.017 SL1210380 3.80 7.6 6.0 50 1.5 12.0 5.0 0.003 0.007 0.016 SL1210400 4.00 8.0 6.0 50 1.5 16.0 5.0 0.002 0.007 0.015 SL1210450 4.50 9.0 6.0 50 1.5 16.0 5.0 0.001 0.006 0.014 SL1210500 5.00 10.0 6.0 50 1.5 16.0 5.0 0.001 0.006 0.012 SL1210550 5.50 11.0 6.0 50 1.5 20.0 5.0 0.0008 0.005 0.010 SL1210600 6.00 12.0 6.0 50 1.5 20.0 5.0 0.0008 0.005 0.009 SL1210650 6.50 13.0 6.0 50 1.5 20.0 5.0 0.0005 0.004 0.008 Time(S) (Ω) (Ω) (Ω) IH=Hold current: maximum current at which the device will not trip at 25℃ still air reflow soldering of 260℃ for 20 sec. IT=Trip current: minimum current at which the device will always trip at 25℃ still air reflow soldering of 260℃ for 20 sec. Vmax=Maximum continuous voltage device can withstand without damage at ratedcurrent Imax=Maximum fault current device can withstand without damage at rated voltage. Ttrip=Maximum time to trip(s) at assigned current reflow soldering of 260℃ for 20 sec. Pdtyp=Typical power dissipation: typical amount of power dissipated by the device when in state air environment. Rmin= Minimum resistance of device in initial (un-soldered) state. Rmax= Maximum resistance of device in initial (un-soldered) state. R1max=Maximum resistance of device at 25℃ measured one hour after reflow soldering of 260℃ for 20 sec. Value specified is determined by using the PWB with 0.030＂*1.5oz coppertraces. Caution: Operation beyond the specified rating may result in damage and possible arcing andflame. Environmental Specifications Test Test Conditions Resistance Change/ Criteria Recommended storage conditions 40°C max, 70% R.H. max ± 5% Passive aging: 85°C, 1000 hours ≤ R1max Moisture Resistance 85% RH,85℃,1000hrs ≤ R1max Thermal Shock Vibration MIL-STD-202 Method 107G +85ºC /-40ºC 20 times MIL-STD-883C, Method 2007.1, Condition A ≤ R1max ± 5% Solvent Resistance MIL-STD-202, Method 215 Appearance No change Moisture Level Sensitivity J-STD-020C Level 2a Polymer PTC Thermistor Specifications are subject to change without notice www.sealand-pptc.com Version: 1.2 Document code：SL1210 Low R Effective date ：2015-09-02 Page: 3 of 5 Surface-Mount Device SL1210 ROHS Thermal Derating [ Hold Current (A) at Ambient Temperature (℃)] Part Number Maximum Ambient Operating Temperature (℃) -40 -20 0 25 40 50 60 70 SL1210150 2.3 2.0 1.7 1.5 1.3 1.2 1.1 0.9 SL1210175 2.6 2.3 2.0 1.75 1.5 1.3 1.2 1.1 SL1210190 2.9 2.5 2.2 1.9 1.6 1.5 1.3 1.2 SL1210200 3.0 2.7 2.3 2.0 1.7 1.5 1.4 1.2 SL1210210 3.2 2.8 2.4 2.1 1.8 1.6 1.5 1.3 SL1210230 3.5 3.1 2.7 2.3 2.0 1.8 1.6 1.4 SL1210250 3.8 3.3 2.9 2.5 2.2 1.9 1.8 1.5 SL1210260 3.9 3.5 3.0 2.6 2.2 2.0 1.9 1.6 SL1210300 4.5 4.0 3.5 3.0 2.6 2.3 2.1 1.8 SL1210350 5.3 4.7 4.1 3.5 3.0 2.7 2.5 2.1 SL1210380 5.7 5.1 4.4 3.8 3.3 2.9 2.7 2.3 SL1210400 6.0 5.3 4.6 4.0 3.4 3.1 2.8 2.4 SL1210450 6.8 6.0 5.2 4.5 3.9 3.5 3.2 2.7 SL1210500 7.5 6.7 5.8 5.0 4.3 3.9 3.5 3.1 SL1210550 8.3 7.3 6.4 5.5 4.7 4.2 3.9 3.4 SL1210600 9.0 8.0 7.0 6.0 5.2 4.6 4.2 3.7 SL1210650 9.8 8.6 7.5 6.5 5.6 5.0 4.6 4.0 Solder Reflow Recommendation Polymer PTC Thermistor Specifications are subject to change without notice www.sealand-pptc.com Version: 1.2 Document code：HB-WI7.3-162-2013 Effective date ：2015-02-07 Page: 4 of 5 Surface-Mount Device SL1210 ROHS Recommended reflow methods:IR,hot air oven ,nitrogen oven Devices can be cleaned using standard industry methods and solvents. NOTE: If reflow temperatures exceed the recommended profile,devices may not meet the performance requirements. Caution: Operation beyond the rated voltage or current may result in rupture electrical arcing or flame Packaging Quantity and Marking Polymer PTC Thermistor Device Standard Quantity (pcs) SL1210150 4000 SL1210175 4000 SL1210190 4000 SL1210200 4000 SL1210210 4000 SL1210230 4000 SL1210250 4000 SL1210260 4000 SL1210300 4000 Specifications are subject to change without notice www.sealand-pptc.com Version: 1.2 Document code：HB-WI7.3-162-2013 Effective date ：2015-02-07 Page: 5 of 5 Surface-Mount Device SMD1210 ROHS SL1210350 4000 SL1210380 4000 SL1210400 4000 SL1210450 4000 SL1210500 4000 SL1210550 4000 SL1210600 4000 SL1210650 4000 Operation beyond the maximum ratings or improper use may result in device damage and possible electrical arcing and flame. The devices are intended for protection against occasional over-current or over temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated. Device performance can be impacted negatively if devices are handled in a manner inconsistent with recommended electronic, thermal, and mechanical procedures for electronic components. Contact information SEA & LAND ELECTRONIC CORP. 13F., No.120-10, Sec. 3, Zhongshan Rd., Zhonghe Dist., New Taipei City 235, Taiwan Rev. letter Design Date Check Audit Approve Tel:886-2-82212567 Fax:886-2-22257268 Polymer PTC Thermistor Specifications are subject to change without notice www.sealand-pptc.com
