Version: 1.2 Document code：SL0805 Low R date ：2015-09-02 Page: 1 of 4 Surface-Mount Device SL0805 ROHS Feature  Resettable over current and over temperature protection ● Low resistance  Small size of 0805 ● Fast time-to-trip  Small footprint ● ROHS complaint Application Part Numbering Product Dimensions in Millimeter Part Number A B C D E Max Min Min 0.4 1.0 0.20 0.10 0.5 -0.5 1.2 0.20 0.10 1.2 0.20 0.10 1.2 0.20 0.10 1.80 0.5 -0.6 1.3 0.20 0.10 1.20 -1.20 1.80 0.6 1.3 0.20 0.10 1.80 0.6 1.5 0.20 0.10 1.20 -1.20 1.80 0.6 1.5 0.20 0.10 1.80 0.6 1.5 0.20 0.10 1.20 -- 1.80 0.6 1.5 0.20 0.10 Min Max Min Max SL0805075 1.90 2.50 1.20 1.80 SL0805110 1.90 -1.90 2.50 1.20 -1.20 1.80 1.90 -1.90 2.50 1.20 -1.20 1.80 1.90 -1.90 2.50 1.90 -1.90 2.50 1.90 -- 2.50 SL0805125 SL0805150 SL0805175 SL0805200 SL0805260 SL0805300 SL0805350 SL0805380 Polymer PTC Thermistor 2.50 2.50 2.50 2.50 1.80 Min Specifications are subject to change without notice www.sealand-pptc.com Version: 1.2 Document code：SL0805 Low R date ：2015-09-02 Page: 2 of 4 Surface-Mount Device SL0805 ROHS Electrical Characteristics Part Number I(A) Vmax I max Pdtyp 25℃ -- -- -- Ttrip Rmin Rmax R1max 25℃ Time(S) (Ω) 25℃ (Ω) (Ω) Hold Trip (V) (A) (W) Current(A) SL0805075 0.75 1.5 6.0 50 1.0 8.0 0.3 0.025 0.048 0.080 SL0805110 1.10 2.2 6.0 50 1.0 8.0 0.5 0.020 0.044 0.075 SL0805125 1.25 2.5 6.0 50 1.0 8.0 1.0 0.015 0.040 0.070 SL0805150 1.50 3.0 6.0 50 1.0 8.0 5.0 0.010 0.036 0.065 SL0805175 1.75 3.5 6.0 50 1.0 8.0 5.0 0.008 0.032 0.060 SL0805200 2.00 4.0 6.0 50 1.0 8.0 5.0 0.008 0.028 0.055 SL0805260 2.60 5.2 6.0 50 1.0 12.0 5.0 0.007 0.024 0.050 SL0805300 3.00 6.0 6.0 50 1.0 12.0 5.0 0.007 0.020 0.045 SL0805350 3.50 7.0 6.0 50 1.0 12.0 5.0 0.006 0.018 0.040 SL0805380 3.80 7.6 6.0 50 1.0 12.0 5.0 0.006 0.015 0.035 IH=Hold current: maximum current at which the device will not trip at 25℃ or 60℃ still air reflow soldering of 260℃ for 20 sec. IT=Trip current: minimum current at which the device will always trip at 25℃ still air reflow soldering of 260℃ for 20 sec. Vmax=Maximum continuous voltage device can withstand without damage at rated current Imax=Maximum fault current device can withstand without damage at rated voltage. Ttrip=Maximum time to trip(s) at assigned current reflow soldering of 260℃ for 20 sec. Pdtyp=Typical power dissipation: typical amount of power dissipated by the device when in state air environment. Rmin= Minimum resistance of device in initial (un-soldered) state. Rmax= Maximum resistance of device in initial (un-soldered) state. R1max=Maximum resistance of device at 25℃ measured one hour after reflow soldering of 260℃ for 20 sec. Value specified is determined by using the PWB with 0.030 *1.5oz coppertraces. ＂ Caution: Operation beyond the specified rating may result in damage and possible arcing andflame. Environmental Specifications Test Test Conditions Resistance Change/ Criteria Recommended storage conditions 40°C max, 70% R.H. max ± 5% Passive aging: 85°C, 1000 hours ≤ R1max Moisture Resistance 85% RH,85℃,1000hrs ≤ R1max Thermal Shock Vibration MIL-STD-202 Method 107G +85ºC /-40ºC 20 times MIL-STD-883C, Method 2007.1, Condition A ≤ R1max ± 5% Solvent Resistance MIL-STD-202, Method 215 Appearance No change Moisture Level Sensitivity J-STD-020C Level 2a Polymer PTC Thermistor Specifications are subject to change without notice www.sealand-pptc.com Version: 1.2 Document code：SL0805 Low R date ：2015-09-02 Page: 3 of 4 Surface-Mount Device SL0805 Thermal Derating [ Hold Current (A) at Ambient Temperature (℃)] Part Number ROHS Maximum Ambient Operating Temperature (℃) -40 -20 0 25 40 50 60 70 SL0805075 1.1 1.0 0.8 0.75 0.7 0.6 0.5 0.4 SL0805110 1.7 1.4 1.2 1.10 1.0 0.8 0.7 0.6 SL0805125 1.9 1.6 1.4 1.25 1.1 0.9 0.8 0.7 SL0805150 2.3 2.0 1.7 1.50 1.4 1.1 1.0 0.9 SL0805175 2.6 2.3 1.9 1.75 1.6 1.2 1.1 1.0 SL0805200 3.0 2.6 2.2 2.00 1.8 1.4 1.3 1.2 SL0805260 3.9 3.4 2.9 2.60 2.3 1.8 1.7 1.6 SL0805300 4.5 3.9 3.3 3.00 2.7 2.1 2.0 1.8 SL0805350 5.3 4.6 3.9 3.50 3.2 2.5 2.3 2.1 SL0805380 5.7 4.9 4.2 3.80 3.4 2.7 2.5 2.3 Solder Reflow Recommendation Recommended reflow methods:IR,hot air oven ,nitrogen oven Polymer PTC Thermistor Specifications are subject to change without notice www.sealand-pptc.com Version: 1.2 Document code：SL0805 Low R date ：2015-09-02 Page: 4 of 4 Surface-Mount Device SL0805 ROHS Devices can be cleaned using standard industry methods and solvents. NOTE: If reflow temperatures exceed the recommended profile,devices may not meet the performance requirements. Caution: Operation beyond the rated voltage or current may result in rupture electrical arcing or flame Packaging Quantity and Marking Device Standard Quantity (pcs) SL0805075 4000 SL0805110 4000 SL0805125 4000 SL0805150 4000 SL0805175 4000 SL0805200 4000 SL0805260 4000 SL0805300 4000 SL0805350 4000 SL0805380 4000 Operation beyond the maximum ratings or improper use may result in device damage and possible electrical arcing and flame. The devices are intended for protection against occasional over-current or over temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated. Device performance can be impacted negatively if devices are handled in a manner inconsistent with recommended electronic, thermal, and mechanical procedures for electronic components. Contact information SEA & LAND ELECTRONI CORP. 13F., No.120-10, Sec. 3, Zhongshan Rd., Zhonghe Dist., New Taipei City 235, Taiwan Rev. letter Design Date Check Audit Approve Tel:886-2-82212567 Fax:886-2-22257268 Polymer PTC Thermistor Specifications are subject to change without notice www.sealand-pptc.com
