ESD3Z5V0

ESD3Z5V0 Transient Voltage Suppressors for ESD Protection Applications z z z z z 2 1 Top View Simplified outline SOD-323 and symbol Cellular phones Portable devices Digital cameras Power supplies S- Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable. Features z z z Small Body Outline Dimensions 300 Watts peak pulse power (tp = 8/20μs) Transient protection for data lines to IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC 61000-4-4 (EFT) 40A (5/50ns) IEC 61000-4-5 (Lightning) 24A (8/20μs) z z Small package for use in portable electronics Suitable replacement for MLV’s in ESD protection applications z z z z z z z Protects one I/O or power line Low clamping voltage Working voltages: 5V and 36V Low leakage current Solid-state silicon-avalanche technology We declare that the material of product compliance with RoHS requirements. S- Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable. Absolute Ratings (Tamb=25°C ) Symbol Parameter Value Units PPP Peak Pulse Power (tp = 8/20μs) 300 W TL Maximum lead temperature for soldering during 10s 260 °C Tstg Storage Temperature Range -55 to +155 °C Top Operating Temperature Range -40 to +125 °C Tj Maximum junction temperature 150 °C ±15 ±8 KV 40 A 16 KV IEC61000-4-2 (ESD) air discharge contact discharge IEC61000-4-4 (EFT) ESD Voltage www.tw-gmc.com Per Human Body Model 1 ESD3Z5V0 Transient Voltage Suppressors for ESD Protection Electrical Parameter Symbol Parameter IPP Maximum Reverse Peak Pulse Current VC Clamping Voltage @ IPP VRWM IR IT VBR Working Peak Reverse Voltage Maximum Reverse Leakage Current @ VRWM Test Current Breakdown Voltage @ IT Electrical Characteristics Ratings at 25°C ambient temperature unless otherwise specified.VF = 0.9V at IF = 10mA Device ESD3Z5V0 Device Marking 3M IR(uA) VBR (V)@ IT VC (V) VC (V) VRWM (V) @ VRWM (Note 1) Max Max Min mA Typ Max 5.0 1.0 5.6 1.0 11.6 18.6 IT @ IPP=5 A* @ Max IPP* (A)* *Surge current waveform per Figure 1. 1. VBR is measured with a pluse test current IT at an ambient temperature of 25℃． Fig1. Pulse Waveform www.tw-gmc.com 1 2 IPP PPK C (W)* (pF) Max Max Typ 9.4 174 35 ESD3Z5V0 Transient Voltage Suppressors for ESD Protection 100 90 % of Rated Power 80 70 60 50 Peak Pluse Power 8/20µs 40 30 20 10 0 0 25 50 75 100 125 150 Lead Temperature- TL(℃) Fig2.Power Derating SOD-323 NOTES: 1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994. 2. CONTROLLING DIMENSION: MILLIMETERS. 3. MAXIMUM LEAD THICKNESS INCLUDES LEAD FINISH. MINIMUM LEAD THICKNESS IS THE MINIMUM THICKNESS OF BASE MATERIAL. 4. DIMENSIONS D AND E DO NOT INCLUDE MOLD FLASH, PROTRUSIONS, OR GATE BURRS. MILLIMETERS DIM A MIN 0.8 0.9 1 A1 0 0.05 0.1 A3 SOLDERING FOOTPRINT www.tw-gmc.com 1 3 NOM MAX INCHES MIN NOM MAX 0.031 0.035 0.04 0.002 0.004 0 0.15REF 0.006REF b 0.25 0.32 C 0.089 0.12 D 1.6 1.7 1.8 0.062 0.066 E 1.15 1.25 1.35 0.045 0.049 0.053 L HE 0.08 2.3 0.4 0.01 0.012 0.016 0.177 0.003 0.005 0.007 0.07 0.003 2.5 2.7 0.09 0.098 0.105
