SY6282
6.5V, 3A Low Loss Power Distribution Switch
Preliminary Specification
Features
General Description
•
•
•
•
•
•
•
Input voltage: 2.4V to 6.5V
3A load current capability
Programmable current limit
Over temperature protection
Reverse blocking (no body diode)
OUT can be forced higher than IN at shutdown
Compact TSOT23-5 package minimizes the board
space
• RoHS Compliant and Halogen Free
SY6282 is ultra-low RDS(ON) switch with programmable
current limit to protect the power source from over
current and short circuit conditions. They incorporate
over temperature protection and reverse blocking
function.
Ordering Information
SY6282 □(□□
□□)□
□□ □
Tempera ture Code
Packa ge Code
Optiona l Spec Code
Ordering Number
SY6282ACC
Package type
TSOT23-5
Applications
•
•
•
•
•
Note
USB 3G Datacard
USB Dongle
MiniPCI Accessories
USB Charger
Public Place Multi-USB Charger
Typical Applications
VIN
6
IN
OUT
VOUT
1
SY6282
CIN
10µF
4
COUT
10µF
3
EN
ISET
GND
RSET
6.8kΩ
2
Figure 1. Schematic Diagram
SY6282 Rev. 0.1
Silergy Corp. Confidential- Prepared for Customer Use Only
殷先生:13380368939 QQ:719307610
1
SY6282
Pinout (top view)
(TSOT23-5)
Top mark: Lnxyz for SY6282ACC (Device code: Ln x=year code, y=week code, z= lot number code)
4
5
r
EN
IN
Pin Description
Output pin, decoupled with a 10µF capacitor to GND.
Ground pin.
Current limit programming pin. Connect a resistor RSET from this pin
to ground to program the current limit: ILIM (A)=6800/RSET (Ω)
ON/OFF control. Pull high to enable IC. Do not leave it floating.
Input pin, decoupled with a 10µF capacitor to GND.
fo
Pin number
1
2
3
re
pa
re
d
Pin Name
OUT
GND
ISET
l-P
Absolute Maximum Ratings (Note 1)
.C
on
fid
en
tia
All pins------------------------------------------------------------------------------------------------------------------- -0.3V to 7V
Power Dissipation, PD @ TA = 25°C TSOT23-5, ------------------------------------------------------------------------- 1.46W
Package Thermal Resistance (Note 2)
θ JA --------------------------------------------------------------------------------------------------------------- 68.5°C/W
θ JC --------------------------------------------------------------------------------------------------------------- 10.9°C/W
Junction Temperature--------------------------------------------------------------------------------------------------------- 150°C
Lead Temperature (Soldering, 10 sec.) ------------------------------------------------------------------------------------ 260°C
Storage Temperature Range ------------------------------------------------------------------------------------- -65°C to 150°C
Recommended Operating Conditions (Note 3)
Si
le
rg
y
Co
rp
IN------------------------------------------------------------------------------------------------------------------------ 2.4V to 6.5V
All other pins ------------------------------------------------------------------------------------------------------------- 0V to 6.5V
Junction Temperature Range ------------------------------------------------------------------------------------- -40°C to 125°C
Ambient Temperature Range -------------------------------------------------------------------------------------- -40°C to 85°C
SY6282 Rev. 0.1
Silergy Corp. Confidential- Prepared for Customer Use Only
殷先生:13380368939 QQ:719307610
2
SY6282
Electrical Characteristics
(VIN = 5V, COUT=10µF, TA = 25°C unless otherwise specified)
Test Conditions
Min
2.4
Open load, IC Disabled.
Open load, IC Enabled.
Typ
0.2
38
50
Max
6.5
1
2
0.8
1
2.3
VEN=5.0V
0.75
0.4
fo
RL=10Ω, COUT=1µF
RL=10Ω, COUT=1µF
r
RSET=6.8kΩ
d
Symbol
VIN
ISHDN
IQ
RDS(ON)
VEN(H)
VEN(L)
IEN
VIN_UVLO
VIN_HYS
ILIM
IRANGE
TON
TOFF
TSD
TSD_HYS
0.1
1
130
20
150
20
1.25
3.5
Unit
V
µA
µA
mΩ
V
V
µA
V
V
A
A
µs
µs
℃
℃
re
Parameter
Input Voltage Range
Shutdown Input Current
Quiescent Supply Current
FET RON
EN Rising Threshold
EN Falling Threshold
EN Leakage Current
IN UVLO Threshold
IN UVLO Hysteresis
Over Current Limit
Programmable current limit range
Turn-on Time
Turn-off Time
Thermal Shutdown Temperature
Thermal Shutdown Hysteresis
l-P
re
pa
Note 1: Stresses beyond the “Absolute Maximum Ratings” may cause permanent damage to the device. These are
stress ratings only. Functional operation of the device at these or any other conditions beyond those indicated in the
operational sections of the specification is not implied. Exposure to absolute maximum rating conditions for
extended periods may affect device reliability.
en
tia
Note 2: θ JA is measured in the natural convection at TA = 25°C on a Silergy test board. Pin 2 of TSOT23-5 package
is the case position for θ JC measurement.
fid
Note 3: The device is not guaranteed to function outside its operating conditions.
Si
le
rg
y
Co
rp
.C
on
Block Diagram
SY6282 Rev. 0.1
Silergy Corp. Confidential- Prepared for Customer Use Only
3
SY6282
TSOT23-5 Package outline & PCB layout design
0.55
1.50 - 1.70
d
fo
0.80
r
2.70 - 3.00
2.40
2.80 - 3.10
0.30 - 0.50
re
0.95 TYP
0.01 - 0.1
1.00 (max)
fid
en
0.25 REF
tia
l-P
0.1 - 0.20
re
pa
Recommended Pad Layout
0.95 TYP
1.90 TYP
Co
rp
.C
on
0.3 - 0.6
Si
le
rg
y
Notes: All dimensions are in millimeters.
All dimensions don’t include mold flash & metal burr.
SY6282 Rev. 0.1
Silergy Corp. Confidential- Prepared for Customer Use Only
4
SY6282
Taping & Reel Specification
1. Taping orientation
TSOT23-5
3.9/4.1
fo
r
7.7/8.3
1.45/1.55
re
d
Feeding direction
re
pa
2. Carrier Tape & Reel specification for packages
fid
en
tia
l-P
Reel
Width
rg
y
Co
rp
.C
on
Reel
Size
Tape
width
(mm)
Pocket
pitch(mm)
Reel size
(Inch)
Reel
width(mm)
Trailer
length(mm)
Leader length
(mm)
Qty per
reel
8
4
7"
8.4
280
160
3000
Si
le
Package
types
TSOT23-5
3. Others: NA
SY6282 Rev. 0.1
Silergy Corp. Confidential- Prepared for Customer Use Only
5
