LoRaWAN Gateway and Wireless Sensor Catalog Version: V1.7 Contents About SenseCAP..................................................................................................................................3 SenseCAP Gateway-LoRaWAN........................................................................................................4 SenseCAP Wireless Air Temperature and Humidity Sensor-LoRaWAN..................................5 SenseCAP Wireless Light Intensity Sensor-LoRaWAN...............................................................7 SenseCAP Wireless CO2 Sensor-LoRaWAN................................................................................8 SenseCAP Wireless Barometric Pressure Sensor-LoRaWAN...................................................9 SenseCAP Wireless Soil Moisture and Temperature Sensor-LoRaWAN..............................10 SenseCAP Wireless Soil Temperature, VWC & EC Sensor-LoRaWAN................................11 SenseCAP Wireless pH Sensor-LoRaWAN................................................................................12 SenseCAP Wireless PAR Sensor-LoRaWAN.............................................................................13 SenseCAP Portal.............................................................................................................................14 API Instructions.................................................................................................................................15 System Architecture SenseCAP Architecture Agriculture SenseCAP Server LoRa Radio Ethernet API LTE City Industry TTN Server Chirp Stack Server (Built-in) SenseCAP Sensor SenseCAP LoRaWAN Gateway LoRaWAN Network Server Application SenseCAP Sensor + Other LoRaWAN Gateway Architecture LoRa Radio SenseCAP Sensor LoRaWAN Gateway LoRaWAN Network Server Application About SenseCAP SenseCAP is an industrial wireless sensor network that integrates easy-to-deploy hardware and data API services, enabling low-power, long-distance environmental data collection. SenseCAP includes several versions, such as LoRaWAN, SensorHub-LTE, etc. SenseCAP LoRaWAN version products include LoRaWAN Gateways and Sensor Nodes. Based on LoRaWAN protocol, it can realize one-to-many, long-distance networking, and bilateral communication. The LoRaWAN gateway supports Ethernet and 4G. The sensor node is powered by a high-capacity battery that lasts up to 3 years (uploading data once per hour). It also supports hot-swap, making it easy for maintenance and upgrading. SenseCAP provides an easy-to-use portal. Users can scan the QR code with the App to bind the device with its respective account, manage the devices, and check sensor data on the portal. SenseCAP Portal provides API for users to develop based on the data on the portal further. Application Smart Agriculture Smart Cities Features of SenseCAP LoRaWAN Gateway Support LoRaWAN protocol Class A Cortex A8 processor, Linux system, stable and reliable Smart Buildings Smart Industry Environmental Monitoring Other Wireless Sensing Applications Ultra-wide-distance transmission: 10km in line of sight scene, 2 km in the urban scene SenseCAP LoRaWAN Gateway can access SenseCAP Server, The Thing Network Server and The ChirpStack open-source LoRaWAN Network Server. Support multiple ISM bands: EU868, US915, AU915, AS923 Support remote modification of Node collection frequency 4G and Ethernet connectivity, suitable for multiple scenes. SenseCAP Sensor can be used not only with the SenseCAP LoRaWAN Gateway but also with other standard LoRaWAN gateways. The Sensor is designed with a fixed LoRa channel, which can not be modified by users. The supported channels are as follows. Please refer to the user manual for how to connect this device with a LoRaWAN gateway. Provides a variety of cloud services and data API interfaces Industrial grade protection: IP66 enclosure, suitable for outdoor applications Operating temperature -40℃ to +70℃ EU868 Uplink Frequency(MHz): 868.1, 868.3, 868.5, 867.1, 867.3, 867.5, 867.7, 867.9 (SF7BW125 to SF12BW125) Downlink Multiplexing the frequency points of the 8 uplink channels. 869.525MHz -SF9BW125 (RX2 downlink only) US915 Uplink Frequency(MHz): 903.9, 904.1, 904.3, 904.5, 904.7, 904.9, 905.1, 905.3 (SF7BW125 to SF10BW125) Downlink Frequency(MHz): 923.3, 923.9, 924.5, 925.1, 925.7, 926.3, 926.9, 927.5 (SF7BW500 to SF12BW500) AU915 Features of SenseCAP LoRaWAN Sensors Support LoRaWAN protocol Class A High reliability and stability Ultra-wide-distance transmission: 10km in line of sight scene, 2 km in the urban scene Uplink Frequency(MHz): 916.8, 917.0, 917.2, 917.4, 917.6, 917.8, 918.0, 918.2(SF7BW125 to SF10BW125) Downlink Frequency(MHz): 923.3, 923.9, 924.5, 925.1, 925.7, 926.3, 926.9, 927.5 (SF7BW500 to SF12BW500) AS923 Uplink AS1 Frequency(MHz): 923.2, 923.4, 922.2, 922.4, 922.6, 922.8, 923.0, 922.0, 922.1 AS2 Frequency(MHz): 923.2, 923.4, 923.6, 923.8, 924.0, 924.2, 924.4, 924.6, 924.5 Downlink AS1: Uplink channels 1-10 (RX1) 923.2 - SF10BW125 (RX2) AS2: Uplink channels 1-10 (RX1) 923.2 - SF10BW125 (RX2) Battery life ≥ 3 years Support remote modification of Node collection frequency Support the local modification of EUI, AppKey, AppEui Rapid installation and deployment IP66 enclosure, suitable for outdoor applications * Please refer to Frequency Plans for specific parameters. 3 An Industrial Wireless Sensor Network Solution SenseCAP Gateway - LoRaWAN Introduction SenseCAP LoRaWAN Gateway(*) is based on LoRaWAN®(**) protocol, applicable for low-power, long-distance environmental data collection and monitoring in scenarios such as smart agriculture and smart city, etc. As the central device of the LoRa network, the gateway is used for collecting data from different Sensor Nodes and transmit the data to the SenseCAP Portal via 4G or Ethernet cable. Equipped with a high-performance processor and telecom-operator-level LoRa chip, this gateway ensures stable and high performance in a large-scale network. The gateway is designed with an IP66-protection-level enclosure, making it suitable for industrial applications in severe outdoor environments. Specifications Product Model Model Region LoRa-G-868-E/4G European, Africa, Asia (India etc.) LoRa-G-923-E/4G Japan, Malaysia, Singapore, Brunei, Cambodia, Hong Kong, Indonesia, Laos, Taiwan, Thailand, Vietnam, Peru etc. LoRa-G-915-E/4G USA, Canada and South America LoRa-G-AU915-E/4G Australia, etc. LoRa Parameters Protocol Based on LoRaWAN v1.0.2 protocol Channel Plan EU868/US915/AU915/AS923 Power Output 25dBm Sensitivity -139dBm (SF12BW125) General Parameters General Parameters UMTS Features Support 3GPP R8 DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA DC-HSDPA: Max 42Mbps (DL) HSUPA: Max 5.76Mbps (UL) WCDMA: Max 384Kbps (DL), Max 384Kbps (UL) LoRa Antenna 2.5dBi gain / Vertical polarization / Omnidirectional / SMA-J connector 4G Antenna 0-4 dBi gain / Linear polarization / Omnidirectional / SMA-J connector LED Indicator Indicating network condition (online/ offline) Grounding Reserved 1 screw hole for GND CPU TI AM3358 Cortex-A8 1GHz Power Consumption 3.6W System Linux Debian Power Supply DC 12V/2A RAM DDR3 512MB IP Rating IP66 Memory 8GB eMMC Ethernet 100Mbps FE (RJ-45) UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC 4G Band LTE-FDD: B1/B2/B3/B4/B5/B7/B8/ B12/B13/B18/B19/B20/B25/B26/B28 LTE-TDD: B38/B39/B40/B41 WCDMA: B1/B2/B4/B5/B6/B8/B19 GSM: 850/900/1800/1900MHz 4G Features Support non-CA Cat 4 FDD and TDD LTE-FDD: Max 150Mbps (DL), Max 50Mbps (UL) LTE-TDD: Max 130Mbps (DL), Max 30Mbps (UL) Operating Temperature -40 ℃ to +70 ℃ Operating Humidity 0 to 100 %RH (non-condensing) Installation Method Wall or pole mounting Device Weight 777g 4 SenseCAP Gateway - LoRaWAN Device Dimensions Certification 1. Ethernet Port 2. Power Connector 3. LED 4. Reserved 5. 4G Antenna Connector 6. Reserved 7. LoRa Antenna Connector ** The LoRaWAN® name and the associated logo are licensed by the LoRa Alliance. * SenseCAP LoRaWAN Gateway can access SenseCAP Server, The Thing Network Server and The ChirpStack open-source LoRaWAN Network Server. However, it can only be used with SenseCAP Sensor. © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 5 An Industrial Wireless Sensor Network Solution SenseCAP Wireless Air Temperature and Humidity Sensor - LoRaWAN Specifications Installation Air Temperature Please refer to the user manual for more details. Range -40 ℃ to +85 ℃ Accuracy ±0.3 ℃ Resolution 0.1 ℃ Drift ＜ 0.03 ℃ /year Air Humidity Range 0 to 100 %RH (non-condensing) Accuracy ±2 %RH Resolution 1 %RH Drift ＜ 0.25 %RH/year General Parameters Product Model *LoRa-S-868/915/AU915/923-TH-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 LoRa Power Output 16 dBm (EIRP) Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) Current Consumption 5 μA (sleep mode) 120 mA max(active mode) Communication Distance 2 to 10 km (depending on different antennas and environments) Battery Life ≥ 3 year (upload data once per hour) Battery Voltage 3.6V Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 (Sensor Node) IP65 (Sensor Probe) UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Certification Operating Temperature -40 ℃ to +85 ℃ Operating Humidity 0 to 100 %RH (non-condensing) Device Weight 236g * LoRa-S-868-TH-01, LoRa-S-915-TH-01,LoRa-AU915-TH-01, LoRa-AS923-TH-01. LoRa-S-915-TH-01 is US915 version. Other sensor models are similar. © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 6 An Industrial Wireless Sensor Network Solution SenseCAP Wireless Light Intensity Sensor - LoRaWAN Specifications Installation Please refer to the user manual for more details. Light Intensity Range 0 to 188000 Lux Sensitivity 0.045 Lux/LSB Resolution 0.045 Lux General Parameters Product Model LoRa-S-868/915/AU915/923-Light Intensity-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 LoRa Power Output 16 dBm (EIRP) Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) Current Consumption 5 μA (sleep mode) 120 mA max(active mode) Communication Distance 2 to 10 km (depending on different antennas and environments) Battery Life ≥ 3 year (upload data once per hour) Battery Voltage 3.6V Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Certification Operating Temperature -40 ℃ to +85 ℃ Operating Humidity 0 to 100 %RH (non-condensing) Device Weight 288g © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 7 An Industrial Wireless Sensor Network Solution SenseCAP Wireless CO2 Sensor - LoRaWAN Specifications Installation Please refer to the user manual for more details. CO2 Parameters Condition Value Range - 0 to 40000 ppm Accuracy 400 to 10000ppm ±(30 ppm + 3 %MV) Resolution - 1 ppm Temperature Stability T = 0 to 50 ℃ 400 to 10000 ppm ±2.5 ppm / ℃ General Parameters Product Model LoRa-S-868/915/AU915/923-CO2-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 LoRa Power Output 16 dBm (EIRP) Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) Current Consumption 5 μA (sleep mode) 120 mA max(active mode) Communication Distance 2 to 10 km (depending on different antennas and environments) Battery Life ≥ 3 year (upload data once per hour) Battery Voltage 3.6V Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 (Sensor Node) Indoor (Sensor Probe) * UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Certification Operating Temperature 0 ℃ to +50 ℃ Operating Humidity 0 to 95 %RH Device Weight 319g * The Sensor Probe's membrane is not waterproof ! © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 8 An Industrial Wireless Sensor Network Solution SenseCAP Wireless Barometric Pressure Sensor - LoRaWAN Specifications Installation Please refer to the user manual for more details. Barometric Pressure Parameters Condition Value Range - 300~1100 hPa Resolution - 1 Pa Relative Accuracy 700 to 900 hPa 25 to 40 ℃ ±0.12 hPa Absolute Accuracy 300 to 1100 hPa -20 to 0 ℃ ±1.7 hPa Absolute Accuracy 300 to 1100 hPa 0 to 65 ℃ ±1.0 hPa Temperature Coefficient Offset 900 hPa 25 to 40 °C 1.5 Pa/K Drift - ±1.0 hPa/year General Parameters Product Model LoRa-S-868/915/AU915/923-Baro-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 LoRa Power Output 16 dBm (EIRP) Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) Current Consumption 5 μA (sleep mode) 120 mA max(active mode) General Parameters Communication Distance 2 to 10 km (depending on different antennas and environments) Operating Temperature -40 to +85 ℃ (full accuracy: 0 to 65℃ ) Battery Life ≥ 3 year (upload data once per hour) Operating Humidity 0 to 100 %RH (non-condensing) Battery Voltage 3.6V Device Weight 237g Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 (Sensor Node) IP65 (Sensor Probe) UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Certification © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 9 An Industrial Wireless Sensor Network Solution SenseCAP Wireless Soil Moisture and Temperature Sensor - LoRaWAN Specifications Installation Soil Temperature Please refer to the user manual for more details. Range -30 ℃ to +70 ℃ Accuracy ±0.5 ℃ Resolution 0.1 ℃ Soil Moisture Range From completely dry to fully saturated (from 0% to 100% of saturation) Accuracy ±2% ( 0 to 50 %) ±3% ( 50 to 100 %) Resolution 0.03%( 0 to 50 %); 1%( 50 to 100 %) General Parameters Product Model LoRa-S-868/915/AU915/923-Soil MT-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 LoRa Power Output 16 dBm (EIRP) Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) Current Consumption 5 μA (sleep mode) 120 mA max(active mode) Communication Distance 2 to 10 km (depending on different antennas and environments) Measuring Area A cylinder area (with the probe as the center, diameter: 7cm, height: 7cm) Battery Life ≥ 3 year (upload data once per hour) Battery Voltage 3.6V Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Certification Operating Temperature -30 ℃ to +70 ℃ Operating Humidity 0 to 100 %RH (non-condensing) Device Weight 415g © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 10 An Industrial Wireless Sensor Network Solution SenseCAP Wireless Soil Temperature, VWC & EC Sensor - LoRaWAN 70 87 Specifications Installation Please refer to the user manual for more details. Soil Temperature Range -40 ℃ to +80 ℃ Accuracy ±0.5 ℃ from −40 to 0 ℃ Resolution 0.1 ℃ Soil Volumetric Water Content Range From completely dry to fully saturated (from 0% to 100% of saturation) Accuracy ±3 % (0~51%) ±5 % (51~100%) Resolution 0.1 % (0~51% ); 0.3% (51~100%) Soil Electrical Conductivity Range 0 to 23000 uS/cm Accuracy ±5% from 0~7000uS/cm ±15% from 7000~23000uS/cm Resolution 10 uS/cm (0~7000uS/cm) 50 uS/cm (7000~23000uS/cm) General Parameters Product Model LoRa-S-868/915/AU915/923-Soil Temp&VWC&EC-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 General Parameters LoRa Power Output 16 dBm (EIRP) UV Resistance Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Current Consumption 5 μA (sleep mode) 120 mA max(active mode) Communication Distance 2 to 10 km (depending on different antennas and environments) Battery Life ≥ 3 year (upload data once per hour) Battery Voltage 3.6V Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 Operating Temperature -40 ℃ to +60 ℃ Operating Humidity 0 to 100 %RH (non-condensing) Device Weight 385g Certification © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 11 An Industrial Wireless Sensor Network Solution SenseCAP Wireless pH Sensor Specifications Installation Please refer to the user manual for more details. pH Range 0~14 pH Accuracy ±0.1 pH Resolution 0.1 pH General Parameters Product Model LoRa-S-868/915/AU915/923-pH-01 Microcontroller Ultra-low-power MCU Support Protocol Based on LoRaWAN v1.0.2 protocol LoRa Channel Plan EU868 / US915 / AU915 / AS923 LoRa Power Output 16 dBm (EIRP) Sensitivity EU868: -137.5dBm(SF12, BW125KHz) US915/AU915/AS923: -136.5dBm(SF12, BW125KHz) Current Consumption 5 μA (sleep mode) 120 mA max(active mode) Communication Distance 2 to 10 km (depending on different antennas and environments) Battery Life ≥ 3 year (upload data once per hour) Battery Voltage 3.6V Battery Capacity 19Ah (Non-rechargeable) IP Rating IP66 UV Resistance anti-aging (from rain/sun exposure): UL746C F1 Enclosure Material PC Certification Operating Temperature -20 ℃ to +50 ℃ Operating Humidity 0 to 100 %RH (non-condensing) Device Weight 594g © 2008-2021 Seeed Technology Co., Ltd. All rights reserved. 12 An Industrial Wireless Sensor Network Solution SenseCAP Wireless PAR Sensor - LoRaWAN Specifications Installation Photosynthetically Active Radiation Please refer to the user manual for more details. Range 0 to 2000 μmol m-2 s-1 (410 to 655 nm) Sensitivity 0.2 mV/μmol m-2 s-1 Resolution 1 μmol m-2 s-1 Non-stability (Long-term Drift) ＜ 2% / year Measurement Repeatability
