M7F

M1F THRU M7F Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere SURFACE MOUNT GENERAL RECTIFIER Features SMAF  The plastic package carries Underwriters Laboratory Flammability Classification 94V-0 0.106(2.70) 0.094(2.40) 0.063 (1.60) 0.051 (1.30)  Idea for printed circuit board  Glass passivated junction  Low reverse leakage  High forward surge current capability  High temperature soldering guaranteed 0.146(3.70) 0.130(3.30) 250℃/10 seconds at terminals 0.047(1.20) 0.035(0.90) Mechanical Data 0.008(0.20) 0.005(0.12) 0.047(1.20) 0.031(0.80) 0.193(4.90) 0.173(4.40) Case: JEDEC SMAF molded plastic body Terminals: Solderable per MIL-STD-750,Method 2026 Polarity: Polarity symbol marking on body Mounting Position: Any Weight : 0.00095ounce, 0.027 grams Dimensions in inches and (millimeters) Maximum Ratings And Electrical Characteristics Ratings at 25 C ambient temperature unless otherwise specified. Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%. Parameter SYMBOLS Marking Code Maximum repetitive peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage Maximum average forward rectified current at TL=125℃ Peak forward surge current 8.3ms single half sine-wave superimposed onrated load (JEDEC Method) Maximum instantaneous forward voltage at 1.0A Maximum DC reverse current at rated DC blocking voltage TA=25℃ TA=125℃ Typical junction capacitance (NOTE 1) Typical thermal resistance (NOTE 2) VRRM VRMS VDC MDD M1F MDD M2F MDD M3F MDD M4F MDD M5F MDD M6F MDD M7F UNITS 50 35 50 100 70 100 200 140 200 400 280 400 600 420 600 800 560 800 1000 700 1000 V V V I(AV) 1.0 A IFSM 30 A VF 1.10 V IR CJ RJA Operating junction and storage temperature range TJ,TSTG 5.0 50.0 15.0 μA pF 80.0 ℃/W -55 to +150 ℃ Note:1.Measured at 1MHz and applied reverse voltage of 4.0V D.C. 2.P.C.B. mounted with 2.0”x2.0”(5.0x5.0cm) copper pad areas http://www.microdiode.com Rev:2024A2 Page :1 M1F THRU M7F Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere Typical Characterisitics Fig.2 Typical Instaneous Reverse Fig.1 Forward Current Derating Curve Characteristics 1.2 Instaneous Reverse Current (μA) 100 Average Forward Current (A) 1.0 0.8 0.6 0.4 0.2 Single phase half-wave 60 Hz resistive or inductive load 0.0 25 75 50 100 125 150 TJ=150°C 10 TJ=125°C TJ=100°C 1.0 TJ=75°C 0.1 TJ=25°C 0.01 175 0 100 Junction Capacitance (pF) 1.0 25° TJ= 10 0°C C TJ = 5° 12 TJ= C 0.5 0.2 0.6 0.7 0.8 0.9 800 Fig.4 Typical Junction Capacitance Fig.3 Typical Forward Characteristic Instaneous Forward Current (A) 600 Instaneous Reverse Voltage (V) Case Temperature (°C) 0.1 400 200 1.0 1.1 TJ=25°C 10 1 0.1 1.0 10 100 Reverse Voltage (V) Instaneous Forward Voltage (V) Fig.5 Maximum Non-Repetitive Peak Forward Surage Current Peak Forward Surage Current (A) 35 30 25 20 15 10 05 00 8.3 ms Single Half Sine Wave (JEDEC Method) 1 10 100 Number of Cycles The curve above is for reference only. http://www.microdiode.com Rev:2024A2 Page :2 M1F THRU M7F Reverse Voltage - 50 to 1000 Volts Forward Current - 1.0 Ampere Packing information unit:mm P0 P1 d Item Symbol Tolerance A B C d D D1 D2 E F P P0 P1 T W W1 0.1 0.1 0.1 0.05 2.0 min 0.5 0.1 0.1 0.1 0.1 0.1 0.1 0.3 1.0 SMAF E F B A Carrier width Carrier length Carrier depth Sprocket hole 7" Reel outside diameter 7" Reel inner diameter Feed hole diameter Sprocket hole position Punch hole position Punch hole pitch Sprocket hole pitch Embossment center Overall tape thickness Tape width Reel width W P D2 T D1 C W1 D 2.80 4.75 1.42 1.50 178.00 54.40 13.00 1.75 5.05 4.00 4.00 2.00 0.30 8.00 12.30 Note:Devices are packed in accor dance with EIA standar RS-481-A and specifications listed above. Reel packing PACKAGE SMAF REEL SIZE 7" REEL (pcs) COMPONENT SPACING (m/m) BOX (pcs) INNER BOX (m/m) REEL DIA, (m/m) CARTON SIZE (m/m) CARTON (pcs) APPROX. GROSS WEIGHT (kg) 3,000 4.0 6,000 210*208*203 178 400*265*400 120,000 10.0 Suggested Pad Layout http://www.microdiode.com Symbol Unit (mm) A 1.8 0.071 B 0.063 C 1.6 3.8 0.150 D 2.2 0.087 E 5.4 0.213 Unit (inch) Rev:2024A2 Page :3
