RB521CS-30DB
Schottky Barrier Rectifiers
DFN1x0.6-2L
Features
Small surface mounting type
C
High reliability
Low reverse current and low forward voltage
&DWKRGH
$QRGH
Marking Code :C
Absolute Maximum Ratings (TA=25℃)
Parameter
Symbols
Value
Unit
DC Reverse Voltage
VR
30
V
Mean Rectifying Current
IO
200
mA
Non-repetitive Peak Forward Surge Current at t=8.3ms
IFSM
0.5
A
Power dissipation
PD
200
mW
RθJA
500
°C/W
TJ
125
°C
TSTG
-40 to +125
°C
Symbols
Max.
Unit
VF
0.35
V
Thermal Resistance Junction to Ambient
Operating Junction Temperature
Storage Temperature Range
Electrical Characteristics (TA=25℃)
Parameter
Forward Voltage
at IF = 10mA
at IF = 20mA
Reverse Current
at VR = 10 V
www.pingjingsemi.com
Revision:1.0 Dec-2021
0.40
IR
30
µA
1/3
RB521CS-30DB
Schottky Barrier Rectifiers
Typical Characteristic Curves
1000
1000
100
o
Ta=100 C
Reverse Current IR (μA)
=1
00
o
C
10
o
C
a
T
1
T=
a 2
5
Forward Current IF (mA)
100
10
o
Ta=25 C
1
0.1
0.01
0
100
200
300
400
500
0.1
600
0
5
10
Forward Voltage VF (V)
15
20
25
30
Reverse Voltage VR (V)
100
220
Ta=25℃
200
30
Power Dissipation PD (mW)
Capacitance Between Terminals CT (pF)
f=1MHz
10
160
120
80
3
40
1
0
5
10
Reverse Voltage VR (V)
www.pingjingsemi.com
Revision:1.0 Dec-2021
15
20
0
0
25
50
75
100
125
Ambient Temperature TA (℃)
2/3
RB521CS-30DB
Schottky Barrier Rectifiers
Package Outline
DFN1x0.6-2L-0011
Dimensions in mm
0.6±0.05
0.5±0.05
0.5±0.03
0.25±0.03
1±0.05
0.65 BSC
0.25±0.03
0~0.03
TOP VIEW
SIDE VIEW
BOTTOM VIEW
Ordering Information
Device
Package
Shipping
RB521CS-30DB
DFN1x0.6-2L
10,000PCS/Reel&7inches
www.pingjingsemi.com
Revision:1.0 Dec-2021
3/3
