0.4 mm Pitch, Space-saving Interface Connectors
GX Series
Small size
5
2.4
Receptacle
(18 conductors)
Receptacle
* Overmold
GX60-18P
* Shown for reference only - not supplied
Fig.1
Overview
Developed as input/output connectors for use in
portable devices requiring reliable high durability
connection.
*Overmold
Features
1. Small size
With a width of 5 mm and 2.4 mm height above the
mounting surface the connectors may be used in
applications where board and volume space is
restricted.(Fig.1)
2. Strong construction
Locks
Single piece shell increases the board retention and
resists rotational forces encountered in demanding
consumer environment
Plug
GX40-18S
* Shown for reference only - not supplied.
3. High durability
Unique lock latches will maintain high retention force
(plug with corresponding receptacle) up to 10,000
cycles, confir ming fully mated condition with a
distinctive tactile “click” sensation.(Fig.2)
Fig.2
ESD protection
4. ESD protection
Increased distance from the edge of the metal shell to
the front of the contacts offers circuit protection from
electrostatic discharge.(Fig.3)
5. RoHS compliant
Despite its miniature size the long
distance from the metal shell edge to
the front of the contacts provides
protection from electrostatic discharge.
All materials and substances used to produce this
product comply with RoHS standards.
Receptacle
Applications
DSC, PDA, notebook computers, mobile phones and
other por table devices requiring high durability
interface connectors.
1.4mm
Dec.1.2021 Copyright 2021 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Plug
Front of the contacts
Edge of the metal shell
Fig.3
In cases where the application will demand a high level of reliability, such as automotive,
please contact a company representative for further information.
2014.8
1
GX Series●0.4 mm Pitch, Space-saving Interface Connectors
Specifications
Current rating
Voltage rating
Ratings
Item
1. Contact resistance
2. Insulation resistance
3. Withstanding voltage
4. Durability
5. Shock
Dec.1.2021 Copyright 2021 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
6. Vibration
0.5 A (1 A / contact, each contact at the end, 2 contacts only) Operating temperature range -30ç to +80ç
30 V AC
Storage temperature range -40ç to +85ç
Specification
60 mø max.
100 Mø min.
No flashover or insulation breakdown
Contact resistance: 100 mø max.
No damage cracks or parts dislocation.
No electrical discontinuity of 1 µs or longer.
No damage, cracks or parts dislocation.
No electrical discontinuity of 1 µs or longer.
No damage, cracks or parts dislocation.
7. Temperature cycle
Contact resistance: 100 mø max.
No damage, cracks or parts dislocation.
8. Humidity
Insulation resistance: 100 mø min.
Insulation resistance: 10 Mø min.
9. Heat resistance
10. Cold resistance
Contact resistance: 100 mø max.
Contact resistance: 100 mø max.
11. Salt spray test
Contact resistance: 100 mø max.
Conditions
100 mA DC
100 V DC
100 V AC / 1 minute
10,000 cycles
2
Acceleration of 490m/s , 11 ms duration, sine halfwave, 3 cycles, 3 axis
Frequency: 10 to 55 Hz, single amplitude of 0.75 mm,
3 directions for 2 hours
Temperature:-55°C➝+15ç to 35ç➝+85ç➝+15ç to 35ç
Time : 30min.➝2min. to 3min.➝30min.➝2min. to 3 min.
5 cycles
96 hours at a 40 ±3ç, RH of 90 to 95%,
then leave for 1 to 2 hours at normal temperature and
humidity
96 ±4 hours at +85 ±2ç
96 ±4 hours at -40 ±3ç
48 hours at a concentration of 5% ±1%, and humidity of
85 ±3ç
Materials
●Receptacle
Part
Material
Finish
Remarks
Insulator
Synthetic resin
Color: Black
UL94V-0
Contacts
Copper alloy
Gold plated
-------------------
Shell
Stainless steel
Selective gold plated
-------------------
●Plug
Part
Material
Finish
Remarks
Insulator
Synthetic resin
Color: Black
UL94V-0
Contacts
Copper alloy
Gold plated
-------------------
Shells
Stainless steel
Nickel plated
-------------------
Lock
Stainless steel
-------------------
-------------------
Ordering information
●Receptacle
GX60 - 18 P
q
w
e
●Plug
GX40 - 18 S
q
2
w
e
q Series name: GX60 (Receptacles)
GX40 (Plugs)
w Number of contacts : 18
e Contacts type
P: Male
S: Female
GX Series●0.4 mm Pitch, Space-saving Interface Connectors
Receptacle
Part No.
HRS No.
Packaging
GX60-18P
247-0001-3
1,500 pcs/reel
RoHS
6.8
(0.6)
5
0.4
0.15
(13.4)
12.5
No.1
(3.5)
2.4
(0.78)
0.55
0.75
No.18
0.25
(0.6)
12.25
0.9
2.35
4.5
0.5
9
.8
Ø0
All dimensions: mm
Recommended PCB mounting pattern
(H
ol
1(Land)
0.7
0.5
e)
12.25
9
6.8
0.4
0.23 No.18
1.2(Land)
0.6(Through hole)
2.35 1
3.8
Ø1
1.4
No.1
3(Land)
6(Land)
12.5
No conductive traces
1.3(Through hole)
1.9(Land)
3.3(Land)
Dec.1.2021 Copyright 2021 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Note : Order by number of reels.
PCB edge
All dimensions: mm
3
GX Series●0.4 mm Pitch, Space-saving Interface Connectors
Plug
Part No.
HRS No.
Packaging
GX40-18S
247-0002-6
1
RoHS
10.7
11.5
22.6
No.1
(5.6)
6
5
3
6.6
14.5
(6.9)
(7.7)
No.18
14.7
All dimensions: mm
●Assembly (insulator/ contact/lock)
6
4
9.7
14
A
3.3
6.8
Recommended PCB mounting
pattern (Thickness=0.6mm)
P=0.4
A
A-A
(0.3)
1.5
0.4
1.5
PCB installed
6.8
Contact Number
Identification
1.5
02 05 08 11 14 17
5.9(MAX)
0.8
All dimensions: mm
03 06 09 12 15 18
P=0.4(Hole pitch)
0.4
1.5
Dec.1.2021 Copyright 2021 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
●Assembled components - Supplied non-terminated, without overmold
18-Ø0.55(MIN)
01 04 07 10 13 16
PCB (Thickness=0.6mm)
Shown for reference only - not supplied
10.5(MAX)
All dimensions: mm
4
GX Series●0.4 mm Pitch, Space-saving Interface Connectors
Packaging Specifications
●Embossed carrier tape dimensions
Unreeling direction
12
2
Note : Tape and reel packaging (1,500 pcs/reel).
Order by number of reels.
●Reel Dimensions
26
2
Ø1
3
Ø380
Unreeling direction
Recommended Solder Reflow Profile
250
220
Temperature(ç)
Dec.1.2021 Copyright 2021 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
24
11.5
.5
Ø1
1.75
4
The temperature profiles are based on
the above conditions.
In individual applications the actual
temperature may vary, depending on
solder paste type, volume / thickness
and board size / thickness.
Consult your solder paste and
equipment manufacturer for specific
recommendations.
240ç
230ç min.
190
160
Time(Seconds)
150~180ç
60s
230ç min.
30s
5
