NPPN101BFLD-RC

8 7 4 5 6 1 2 3 REVISIONS REV. ECO. NO E 2515 F 2829 DESCRIPTION DATE UPDATE CONTACT POINT DIST TO REF, ADD NOTE 01/16/2012 11 MATING PARTS ADD INSULATOR MATERIAL 'LCP' AND 'C' PLATING 12/10/2014 OPTIONS, UPDATE OPERATING TEMPERATURE BY LH LH/JHSU F F A±.004 [ .10] .035±.002 0.90±0.05 .079±.002 2.00±0.05 PIN 1 .205±.004 5.20±0.10 E E .079±.002 2.00±0.05 RECOMMENDED PCB LAYOUT - FOR PN: xPxNxx1BFLD-RC A±.004 [ .10] .094 2.40 .035±.002 0.90±0.05 PIN 1 D .079±.002 2.00±0.05 xPxNxx1BFLD-RC PIN 1 D PIN 1 .205±.004 5.20±0.10 .079±.002 2.00±0.05 .094 2.40 RECOMMENDED PCB LAYOUT - FOR PN: xPxNxx1BFLC-RC xPxNxx1BFLC-RC B±.014[ 0.35] C C .098 2.50 .173 4.40 .181±.010 4.60±0.25 .006[0.15] .020 0.50 .008 0.20 .079±.002 2.00±0.05 .157±.012 4.00±0.30 A±.008 [ 0.20] B B 02-20, 0.20mm MAX. 21-40, 0.30mm MAX. A NOTES: 1. INSULATOR MATERIAL: SEE PART NUMBER CODING 2. CONTACT MATERIAL: PHOSPHOR BRONZE 3. CONTACT PLATING: SEE PART NUMBER CODING 4. CURRENT RATING: 2 AMPS 5. VOLTAGE RAATING: 150 V AC/DC 6. INSULATOR RESISTANCE: 1000 MEGOHMS MIN 7. CONTACT RESISTANCE: 20 MILLIOHMS MAX 8. DIELECTRIC WITHSTANDING: 500 VAC 9. OPERATING TEMPERATURE: SEE PART NUMBER CODING 10. PROCESSING TEMP. : SEE PART NUMBER CODING 11. FOR ODD NUMBER POSITIONS, MOUNTING STYLES CAN BE EITHER 'C' OR 'D' 12. MATES WITH SULLINS .079 [2.00] CONTACT CENTER MALE HEADER SERIES (.020 [0.50] SQUARE POSTS) 8 7 6 5 Pb RoHS COMPLIANT 4 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN INCHES [MM] TOLERANCES: ANGULAR: 5 DECIMALS .X= .012 [.3] .XX= .008 [.20] .XXX= .006 [.15] DRAWN DATE NAME 01/10/2009 JH THE INFORMATION HEREIN CONTAINS PROPIETARY INFORMATION OF SULLINS ELECTRONICS AND IS NOT TO BE REPRODUCED, USED OR DISCLOSED TO OTHERS FOR ANY PURPOSE EXCEPT AS SPECIFICALLY AUTHORIZED IN WRITING BY AN OFFICER OF SULLINS ELECTRONICS. TITLE HEADER, FEMALE, 2mm CC, 1 ROW, SMT PART NUMBER SIZE C CAGE CODE 54453 SCALE: 12:1 3 2 xPxNxx1BFLx-RC DWG. NO. 10489 SHEET 1 OF 1 1 REV F FILE NAME: 10489, xPxNxx1BFLx-RC A
