18282-3SG-311

INSTRUCTION SHEET MICRO-CON-X SERIES CABLE TO CABLE CONNECTOR GROMMET FOR SHORT BACKSHELL 0.65 SOCKET CONTACTS 0.70 0.69 0.94 BACKSHELL (SHORT) BACKSHELL (LONG) CABLE TO CABLE CONNECTOR 0.90 PIN CONTACTS 0.95 GROMMET FOR LONG BACKSHELL 0.25 0.19 NOTES: 1. NON-REMOVABLE BACKSHELL. 2. ALL DIMENSIONS ARE FOR REFERENCE ONLY. A BZ 06-18-10 REV. INIT. DATE DRAWING CREATED PER DOR 09-1367KL DESCRIPTION CHECKED BY: APPROVED BY: RECOMMENDED STRIPPING LENGTH FILE: LAB-0009 SHEET 1 OF 1 601 E. WILDWOOD VILLA PARK, IL 60181
