1 2 3 4 5 6 7 REV. RoHS ECN. NO. APPD. CAD GENERATED DRAWING. DON'T CHANGE BY HAND. A A 2 1 2 1 CIRCUIT DIAGRAM B B E D C C C B A D D PCB.WELDING DRAWING Specification Rate voltage.current Contact resistance 50mA DC12V ≤100mΩ E Operating force 180±50gf Travel 0.35±0.15mm Insulated resistance ≥100MΩ Dielectric strength Life cycle ≥250VAC/1min ≥100000次 1 Silica gel Button ITEM Black Cover Stainless steel Cleaning Shrapnel Stainless steel Silver Housing PPA Black Cards Brass Silver PART NAME 2 Q'TY MATERIAL 3 X. 0.50 X.° 2° .X 0.30 .X° 1° .XX 0.10 .XX° .XXX 0.05 SHENZHEN YIYUAN TECHNOLOGY CO.,LTD 0.5° MAT'L FINISH Q'TY PART 5 NO. APPD: ROGER CHKD: ROC DR: FINSH/COLOR 4 深圳市怡远科技有限公司 UNITS TITLE: DWG NO.: BILLY WANG 2020/08/21 6 7 SCALE SHEET 1/1 1/1 REV. A1 E
