PESD5V0U1BB-N

PESD5V0U1BB-N ESD Protection Diode »Features ■ 40Watts peak pulse power (tp = 8/20μs) ■ Bidirectional configurations ■ Solid-state silicon-avalanche technology ■ Low clamping voltage ■ Low leakage current ■ Low capacitance (Cj=2.7pF typ.) ■ Protection one data/power line ■ IEC 61000-4-2 ±10kV contact ±15kV air ■ IEC 61000-4-4 (EFT) 40A (5/50ns) ■ IEC 61000-4-5 (Lightning) 3.0A (8/20μs) »Applications »Mechanical Data ■ Cell Phone Handsets and Accessories ■ SOD523 package ■ Microprocessor based equipment ■ Molding compound flammability rating: UL 94V-0 ■ Personal Digital Assistants (PDA’s) ■ Packaging: Tape and Reel ■ Notebooks, Desktops, and Servers ■ RoHS/WEEE Compliant ■ Portable Instrumentation »Schematic & PIN Configuration SOD-523 Revision 2018 www.born-tw.com 1/4 PESD5V0U1BB-N »Absolute Maximum Rating Rating Symbol Value Units Peak Pulse Power ( tp =8/20μs ) PPP 40 Watts Peak Pulse Current ( tp =8/20μs )(note1) Ipp 3.0 A VESD 15 10 kV Lead Soldering Temperature TL 260(10seconds) ℃ Junction Temperature TJ -55 to + 125 ℃ Storage Temperature Tstg -55 to + 125 ℃ ESD per IEC 61000-4-2 (Air) ESD per IEC 61000-4-2 (Contact) »Electrical Characteristics Parameter Symbol Reverse Stand-Off Voltage Reverse Breakdown Voltage Conditions Min Typical VRWM 5.5 Max Units 5.0 V VBR IT=1mA 6.5 V Reverse Leakage Current IR VRWM=5V,T=25℃ 0.1 μA Peak Pulse Current IPP tp =8/20μs 3.0 A Clamping Voltage VC IPP=3.0A,tp=8/20μs 13 V Junction Capacitance Cj VR = 0V, f = 1MHz 3.5 pF 2.7 »Electrical Parameters (TA = 25°C unless otherwise noted) Symbol Parameter IPP Maximum Reverse Peak Pulse Current VC Clamping Voltage @ IPP VRWM IR VBR IT I IPP Working Peak Reverse Voltage Maximum Reverse Leakage Current @ V RWM VC V BR V RWM IT IR ITIR VRWM V BR V C V Breakdown Voltage @ IT Test Current IPP Note:. 8/20μs pulsewaveform. Revision 2018 www.born-tw.com 2/4 PESD5V0U1BB-N »TypicalCharacteristics Figure 2: Power Derating Curve 10 110 1 40w 8/20μs waveform 0.1 0.01 0.1 1 10 100 100 Percent of Rated Power for Ipp Ppp – Peak Pulse Power - Ppp(KW) Figure 1: Peak Pulse Power vs. Pulse Time 90 80 70 60 50 40 30 20 10 0 1,000 0 25 td – Pulse Duration - µs Figure3: Pulse Waveform Percent Ipp 80 Clamping Voltage–VC (V) 90 e-1 50 40 30 td=Ipp/2 20 100 125 150 18 Waveform Paramters tr=8µs td=20µs 100 60 75 Figure 4: Clamping Voltage vs.Ipp 110 70 50 Ambient Temperature - TA (℃) 10 16 14 12 10 8 Test Waveform Paramters tr=8µs td=20µs 6 4 2 0 0 0 5 Revision 2018 10 15 Time (µs) 20 25 30 0 1 2 3 4 5 6 Peak Pulse Current–IPP (A) www.born-tw.com 3/4 PESD5V0U1BB-N »Outline Drawing – SOD523 D -X-YE 1 DIMENSIONS 2 SYMBOL b 2x 0.08 (0.0032) X A b C D E HE L Y A C HE L MILLIMETER INCHES MIN MAX MIN MAX 0.50 0.25 0.07 1.10 0.70 1.50 0.15 0.70 0.35 0.20 1.30 0.90 1.70 0.25 0.020 0.010 0.0028 0.043 0.028 0.059 0.006 0.028 0.014 0.0079 0.051 0.035 0.067 0.010 »Marking 1 5B 2 »Ordering information Order code PESD5V0U1BB-N Revision 2018 Package SOD523 Base qty 5000 www.born-tw.com Delivery mode Tape and reel 4/4
