山东晶导微电子股份有限公司
SSL54C THRU SSL510C
Jingdao Microelectronics co.LTD
Surface Mount Schottky Barrier Rectifier
Reverse Voltage - 40 to 100V
Forward Current - 5.0A
PINNING
PIN
FEATURES
• Metal silicon junction, majority carrier conduction
• For surface mounted applications
• Low power loss, high efficiency
• High forward surge current capability
• For use in low voltage, high frequency inverters,
free wheeling, and polarity protection applications
DESCRIPTION
1
Cathode
2
Anode
2
1
Top View
Marking Code: SSL54~SSL510
Simplified outline SMC and symbol
MECHANICAL DATA
• Case: SMC
• Terminals: Solderable per MIL-STD-750, Method 2026
• A pprox. Weight: 217mg / 0.0077oz
Absolute Maximum Ratings and Electrical characteristics
Ratings at 25 °C ambient temperature unless otherwise specified.Single phase, half wave, 60Hz resistive or inductive load,
for capacitive load, derate by 20 %
Symbols
Parameter
SSL54C
SSL545C
SSL55C
SSL56C
SSL510C
Units
Maximum Repetitive Peak Reverse Voltage
V RRM
40
45
50
60
100
V
Maximum RMS voltage
V RMS
28
32
35
42
70
V
Maximum DC Blocking Voltage
V DC
40
45
50
60
100
V
Maximum Average Forward Rectified Current
I F(AV)
5.0
A
Peak Forward Surge Current,8.3ms
Single Half Sine-wave Superimposed
on Rated Load (JEDEC method)
I FSM
150
A
Max Instantaneous Forward Voltage at 5 A
Maximum DC Reverse Current
T a = 25°C
at Rated DC Reverse Voltage
T a =100°C
Typical Junction Capacitance
（1）
Typical Thermal Resistance
（2）
Operating Junction Temperature Range
Storage Temperature Range
VF
0.45
0.5
50
IR
Cj
0.50
500
0.60
V
mA
300
pF
RθJA
60
°C/W
Tj
-55 ~ +125
°C
T stg
-55 ~ +150
°C
（1）Measured at 1 MHz and applied reverse voltage of 4 V D.C
（2）P.C.B. mounted with 2.0" X 2.0" (5 X 5 cm) copper pad areas.
2018.09
SMC-S-SSL54C~SSL510C-5A100V
Page 1 of 3
山东晶导微电子股份有限公司
SSL54C THRU SSL510C
Jingdao Microelectronics co.LTD
Fig.2 Typical Reverse Characteristics
Average Forward Current (A)
6.0
5.0
4.0
3.0
2.0
1.0
0.0
25
50
75
100
125
150
Instaneous Reverse Current ( μA)
Fig.1 Forward Current Derating Curve
10 4
T J =100°C
10 3
10 1
T J =25°C
10 0
0
Case Temperature (°C)
60
80
100
Fig.4 Typical Junction Capacitance
T J =25°C
Junction Capacitance ( pF)
20
10
1
SSL54C/SSL55C
SSL56C
SSL510C
0.1
0
0.5
1.0
1.5
100
SSL54C
20
SSL545C-SSL510C
10
0.1
1
10
100
Reverse Voltage (V)
Fig.5 Maximum Non-Repetitive Peak
Forward Surage Current
Fig.6- Typical Transient Thermal Impedance
140
120
100
80
60
40
8.3 ms Single Half Sine Wave
(JEDEC Method)
00
1
500
Instaneous Forward Voltage (V)
160
20
1000
2.0
10
100
Transient Thermal Impedance（ °C /W）
Instaneous Forward Current (A)
Peak Forward Surage Current (A)
40
20
Percent of Rated Peak Reverse Voltage（%）
Fig.3 Typical Forward Characteristic
100
10
Number of Cycles at 60Hz
2018.09
T J =75°C
10 2
1
0.01
0.1
1
10
100
t, Pulse Duration（sec）
www.sdjingdao.com
Page 2 of 3
山东晶导微电子股份有限公司
SSL54C THRU SSL510C
Jingdao Microelectronics co.LTD
PACKAGE OUTLINE
SMC
Plastic surface mounted package; 2 leads
E
A
A1
A
C
b
D
L
E1
VM
A
SMC mechanical data
A
E
D
E1
A1
C
L
b
max
2.62
7.0
6.2
8.0
0.21
0.31
1.6
3.25
min
2.00
6.5
5.6
7.6
0.05
0.15
0.9
2.75
max
103
276
244
315
8.3
12
63
128
min
79
256
220
299
2.0
5.9
35
108
UNIT
mm
mil
Marking
The recommended mounting pad size
Type number
3.8
(150)
4.1
(160)
4.3
(170)
4.1
(160)
Marking code
SSL54C
SSL54
SSL545C
SSL545
SSL55C
SSL55
SSL56C
SSL56
SSL510C
SSL510
mm
Unit ：
(mil)
2018.09
80915A
Page 3 of 3
