WS4508E
WS4508E
600mA, Single Li-ion Battery Charger
Http//:www.sh-willsemi.com
Descriptions
The WS4508E is a complete constant-current /
constant
voltage
linear
charger
for
single
cell
Lithium-Ion batteries. No external sense resistor is
needed, and no blocking diode is required due to the
internal MOSFET architecture. Thermal feedback
regulates
the
charge
current
to
limit
the
die
SOT-23-5L
temperature during high power operation or high
ambient temperature. The charge voltage is fixed at
4.2V, and the charge current can be programmed
CHGb 1
externally with a single resistor.
5 PROG
GND 2
The WS4508E automatically terminates the charge
cycle when the charge current drops to 1/10 the
BAT 3
programmed value after the final float voltage is
4 VCC
reached.
Pin configuration (Top view)
When the input supply (wall adapter or USB supply) is
removed, the WS4508E automatically enters a low
current state, dropping the battery drain current to less
5
than 0.5uA. The WS4508E can be put into shutdown
4
mode, reducing supply current to 45uA (Typ.).
4508
The WS4508E is available in a small package with
YYWW
SOT-23-5L. Standard product is Pb-Free.
1
Features
2
3
Programmable Charge Current Up to 600mA
4508
= Device Code
Over-Temperature Protection
YY
= Year
Under Voltage Lockout Protection
WW
= Week
Automatic Recharge Threshold 4.05V(Typ.)
Charge Status Output Pin
2.9V Trickle Charge Threshold
Soft-Start Limits Inrush Current
Applications
Wireless phone
MP3/MP4 Player
Bluetooth device
Will Semiconductor Ltd.
Order information
Device
Package
Shipping
WS4508E-5/TR
SOT-23-5L
3000/Reel&Tape
1
Jun, 2014 - Rev. 1.2
WS4508E
Typical applications
VIO
VCHG
680K
1
CHGb
1K
2
PROG
1
uP
5
2
2K
WS4508E
Li-ion
Battery
2K
WS4508E
GND
GND
3
3
PROG 5
CHGb
VCC
BAT
4
Li-ion
Battery
VCC
BAT
4
VCHG
10uF
10uF
Typical applications W/T LED indicate
Typical applications W/T microprocessor detect
Pin descriptions
Pin Number
Pin Name
1
CHGb
Function
Open-Drain Charge Status Output. When the battery is charging, the CHGb
pin is pulled low. When the charge cycle is completed or VCC is removed, the
CHGb is forced high impedance.
2
GND
Ground
3
BAT
Charge Current Output. Provides charge current to the battery and regulates
the final float voltage to 4.2V.
4
VCC
5
PROG
Power Supply
Charge current setting, charge current monitor and shutdown pin. The
charging current is given by IBAT= (1/RPROG)*1000. The chip will be shutdown
when PROG pin floating
Block Diagram
VCC
165°C
TDIE
1X
TA
1000X
5uA
BAT
MA
R1
VA
CA
SHDNb
R2
REF
1.2V
C1
1V
R3
R4
0.1V
C2
CHGb
To
BAT
2.9V
R5
3uA
Vcc
C3
PROG
GND
Will Semiconductor Ltd.
2
Jun, 2014 - Rev. 1.2
WS4508E
Absolute Maximum ratings
Parameter
Symbol
Rating
Unit
Supply Voltage
VCC
-0.3~8
V
PROG Voltage
VPROG
-0.3~VCC
V
BAT Voltage
VBAT
-0.3~8
V
CHGb Voltage
VCHGb
-0.3~VCC
V
BAT Pin Current
IBAT
600
mA
Power Dissipation – Note1
Pd
0.5
W
Power Dissipation – Note2
Pd
0.3
W
150
o
-45~85
o
-65~125
o
260
o
Junction Temperature
Operation Temperature
Storage Temperature
Tj
Top
Tsg
Lead Temperature (Soldering 10s)
C
C
C
C
Thermal resistance characteristics
Symbol
Parameter
Max.
RJA1
Thermal Resistance, Junction to Ambient – Note1
RJA2
Thermal Resistance, Junction to Ambient – Note2
Unit
125
O
C/W
415
O
C/W
Note1: Surface mounted on FR4 Board using 1 in sq pad size, 2oz Cu.
Note2: Surface mounted on FR4 board using the minimum recommended pad size, 2oz Cu.
Will Semiconductor Ltd.
3
Jun, 2014 - Rev. 1.2
WS4508E
o
Electronics Characteristics (VCC=5V, Ta=25 C, unless otherwise noted)
Symbol
Parameter
Condition
Typ.
Max.
Unit
RPROG=2kΩ
650
2000
uA
RPROG=10kΩ
240
2000
uA
ISPLYCHRG
Charge Mode Supply Current
IBATCHRG
Charge Mode Battery Current
VPROGCHRG
PROG Pin Voltage
ISPLYSTBY
Standby Mode Supply Current
Charge Terminated
IBATSTBY
Standby Mode Battery Current
Charge Terminated
ISPLYASD
Shutdown Mode Supply Current
VCC
