BRCS4484SC

BRCS4484SC Rev.E Nov.-2019 DATA SHEET 描述 / Descriptions SOP-8 塑封封装 N 沟道增强型场效应管。 N-Channel Enhancement Mode Field Effect Transistor in a SOP-8 Plastic Package. 特征 / Features 采用先进的沟槽技术，提供优良的 RDS(ON)和低栅电荷。无卤产品。 Uses advanced trench technology to provide excellent RDS(ON) with low gate charge. Halogen-free Product. 用途 / Applications 适用于广泛的功率转换应用。 Suitable for use in a wide range of power conversion applications. 内部等效电路 / Equivalent Circuit 引脚排列 / Pinning 8 7 6 1 2 5 3 4 PIN1、PIN 2、PIN 3：S PIN 4：G PIN5、PIN 6、PIN 7、PIN 8：D 放大及印章代码 / hFE Classifications & Marking 见印章说明。See Marking Instructions. http://www.fsbrec.com 1/8 BRCS4484SC Rev.E Nov.-2019 极限参数 / DATA SHEET Absolute Maximum Ratings(Ta=25℃) 参数 Parameter 符号 Symbol Drain-Source Voltage VDSS Gate-Source Voltage VGS Drain Current –Continuous A TA=25℃ ID TA=70℃ Pulsed Drain Current B Avalanche Current G Repetitive avalanche energy L=0.3mH G 数值 Rating Steady 10Sec State 40 单位 Unit V ±20 V 13.5 10 A 10.8 8.0 A IDM 120 A IAR 23 A EAR 79 mJ 3.1 1.7 2.0 1.1 Power Dissipation for Single Operation A TA=25℃ Thermal Resistance, Junction-to-Ambient A t≤10S RθJA 40 ℃/ W Steady State RθJA 75 ℃/ W RθJl 24 ℃/ W Tj Tstg -55~150 ℃ PD TA=70℃ Thermal Resistance, Junction-to Lead A (Steady State) Operating and Junction Temperature Range W 电性能参数 / Electrical Characteristics(Ta=25℃) 参数 Parameter Drain-Source Breakdown Voltage Zero Gate Voltage Drain Current Gate-Body Leakage Current Forward Gate Threshold Voltage Static Drain-Source On-Resistance 符号 Symbol 测试条件 Test Conditions BVDSS VGS=0V ID=250μA VDS=40V VDS=40V TJ=55°C VGS=0V VGS=0V 1.0 μA IDSS 5.0 μA IGSS VGS=20V VDS=0V 100 nA VGS(th) VDS=VGS ID=250μA 1.4 2.0 V ID=10A ID=10A 8.2 10 RDS(on) VGS=10V VGS=10 V TJ=125°C VGS=4.5 V 12.5 16 ID=8.0A 12 15 0.72 1.0 Diode Forward Voltage VSD IS=1A VGS=0V Forward Transconductance gFS VDS=5V ID=5A http://www.fsbrec.com 最小值 典型值 最大值 单位 Min Typ Max Unit 40 1.0 V 10 mΩ V S 2/8 BRCS4484SC Rev.E Nov.-2019 DATA SHEET 电性能参数 / Electrical Characteristics(Ta=25℃) 参数 Parameter Input Capacitance 符号 Symbol Coss Reverse Transfer Capacitance Crss Total Gate Charge(4.5V) 最小值 典型值 Min Typ Ciss Output Capacitance Total Gate Charge(10V) 测试条件 Test Conditions 1500 VDS=15V f =1.0MHz VGS=0V Qgs Gate-Drain Charge Qgd Gate resistance Rg VDS=20V VGS=10V ID=10A 27.2 37 13.6 18 4.5 VGS=0V f=1MHz VDS=0V 2.0 3.5 Turn-On Rise Time tr VDS=20V RL=2Ω 17.2 Turn-Off Delay Time td(off) VGS=10V RGEN=3Ω 29.6 Ω ns 16.8 IS Qrr 5.0 6.4 tf trr nC 6.4 td(on) Continuous Drain-Source Diode Forward Current Body Diode Reverse Recovery Time Body Diode Reverse Recovery Charge pF 135 Turn-On Delay Time Turn-Off Fall Time 单位 Unit 1950 215 Qg Gate-Source Charge 最大值 Max IF=10A dI/dt=100A/μs 2.5 A 40 ns 30 19 nC Notes: A:The value of RθJA is measured with the device mounted on 1in2 FR-4 board with 2oz. Copper, in a still air environment with TA= 25°C. The value in any given application depends on the user's specific board design. B: Repetitive rating, pulse width limited by junction temperature. C. The RθJA is the sum of the thermal impedance from junction to lead RθJL and lead to ambient. D. The static characteristics in Figures 1 to 6 are obtained using t ≤ 300μs pulses, duty cycle 0.5% max. E. These tests are performed with the device mounted on 1 in2 FR-4 board with 2oz. Copper, in a still air environment with TA=25°C. The SOA curve provides a single pulse rating. F. The current rating is based on the t ≤ 10s thermal resistance rating. G. EAR and IAR ratings are based on low frequency and duty cycles to keep Tj=25℃. http://www.fsbrec.com 3/8 BRCS4484SC Rev.E Nov.-2019 DATA SHEET 电参数曲线图 / Electrical Characteristic Curve http://www.fsbrec.com 4/8 BRCS4484SC Rev.E Nov.-2019 DATA SHEET 电参数曲线图 / Electrical Characteristic Curve http://www.fsbrec.com 5/8 BRCS4484SC Rev.E Nov.-2019 DATA SHEET 外形尺寸图 / Package Dimensions http://www.fsbrec.com 6/8 BRCS4484SC Rev.E Nov.-2019 DATA SHEET 印章说明 / Marking Instructions BR 4484 **** 说明： BR： 为公司代码 4484： 为型号代码 ****： 为生产批号代码，随生产批号变化 Note: BR: Company Code. 4484: Product Type. ****: Lot No. Code, code change with Lot No. http://www.fsbrec.com 7/8 BRCS4484SC Rev.E Nov.-2019 DATA SHEET 回流焊温度曲线图(无铅) / Temperature Profile for IR Reflow Soldering(Pb-Free) 说明： Note: 1、预热温度 150～180℃，时间 60～90sec; 1.Preheating:150~180℃, Time:60~90sec. 2、峰值温度 245±5℃，时间持续为 5±0.5sec; 2.Peak Temp.:245±5℃, Duration:5±0.5sec. 3、焊接制程冷却速度为 2～10℃/sec. 3. Cooling Speed: 2~10℃/sec. 耐焊接热试验条件 / Resistance to Soldering Heat Test Conditions 温度：260±5℃ 时间：10±1 sec. Temp.:260±5℃ Time:10±1 sec 包装规格 / Packaging SPEC. 卷盘包装 / REEL Package Type 封装形式 SOP/ESOP-8 Dimension 包装尺寸 (unit：mm3) Units 包装数量 Units/Reel 只/卷盘 Reels/Inner Box 卷盘/盒 Units/Inner Box 只/盒 Inner Boxes/Outer Box 盒/箱 Units/Outer Box 只/箱 Reel Inner Box 盒 Outer Box 箱 4,000 2 8,000 6 48,000 13〞×12 360×360×50 380×335×366 使用说明 / Notices http://www.fsbrec.com 8/8
