FN03B104K100PLG

信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. No.566-1, Kaoshi Rd., Yangmei, Taoyuan 32668, Taiwan (R.O.C.) Tel : 886-3-4753355 Fax : 886-3-4854959 Messrs. : Date : 一般共用 2020/11/02 APPROVAL SHEET Product Name : General Purpose Multilayer Ceramic Chip Capacitors Part No. : FN Series Description : Size 0201~2225, C0G/X7R/X5R/Y5V, UR≤50V PREPARED BY APPROVED BY 信昌電子陶瓷股份有限公司 PROSPERITY DIELECTRICS CO., LTD. 桃園市楊梅區高獅路 566-1 號 Tel : 03-4753355 ext : Contactor : http://www.pdc.com.tw Fax : 03-4854959 Mobile : DCM-003-8.1 Rev 2 信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. No.566-1, Kaoshi Rd., Yangmei, Taoyuan 32668, Taiwan (R.O.C.) Tel : 886-3-4753355 Fax : 886-3-4854959 SPECIFICATION FOR Product Name : General Purpose Multilayer Ceramic Chip Capacitors Part No. : FN Series Description : Size 0201~2225, C0G/X7R/X5R/Y5V, UR≤50V SPEC. No. : FN-000-001-17 DATE : 2020/11/02 DRAWN BY CHECEKED BY APPROVED BY Jane Hsiao Yvens Chou Joseph Ling DCM-003-8.2 Rev 2 信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. 1. INTRODUCTION POSPERITY Multilayer Ceramic Chip Capacitors supplied in bulk or tape & reel package are ideally suitable for thick-film hybrid circuits and automatic surface mounting on any printed circuit boards. The nickel-barrier terminations are consisted of a nickel barrier layer over the silver metallization and then finished by electroplated solder layer to ensure the terminations have good solderability. The nickel barrier layer in terminations prevents the dissolution of termination when extended immersion in molten solder at elevated solder temperature. 2. FEATURES 3. APPLICATIONS a. A wide selection of sizes is available (0201 to 2225). b. High capacitance in given case size. c. Capacitor with lead-free termination (pure Tin). d. RoHS & HALOGEN compliant. a. For general digital circuit. b. For power supply bypass capacitors. c. For consumer electronics. d. For telecommunication. e. DC to DC converter. 4. HOW TO ORDER FN PDC Family Table 1 21 X Size 471 K 500 Rated Voltage Table 6 Dielectric Capacitance Tolerance Table 2 Table 3 Table 4 Table 5 P X Packaging Thickness Table 7 Table 6 Table 8 G Control Code Table 9 Table 1 PDC Family Code Description Code Description Code Description Code Description FN General purpose product ≤50Vdc 4R0 4.0Vdc 100 10Vdc 250 25Vdc 6R3 6.3Vdc 160 16Vdc 500 50Vdc Table 2 General Purpose Code Description Code Description Code Description 03 15 18 0201 (0603) 0402 (1005) 0603 (1608) 31 32 42 1206 (3216) 1210 (3225) 1808 (4520) 46 52 55 1825 (4563) 2211 (5728) 2220 (5750) 21 0805 (2012) 43 1812 (4532) 56 2225 (5763) Table 3 Dielectric Material Characteristics Rated Voltage Table 7 Packaging Type Code Description Code Description B Bulk T Tray package Code Description Code Description E Tape and 7” Reel, Embossed Tape P Tape and 7” Reel, Paper Tape N C0G X X7R K Tape and 10” Reel, Embossed Tape D Tape and 10” Reel, Paper Tape B X5R F Y5V L Tape and 13” Reel, Embossed Tape G Tape and 13” Reel, Paper Tape Table 4 Capacitance Rule Code Table 8 Thickness Description Code Description Code Description Code Description Code Description Code Description R47 0R5 0.47pF 0.5pF 102 104 102=10x102=1000pF 104=10x104=100nF A B 0.60 ± 0.10 mm 1.25 ± 0.20 mm 1.15 ± 0.15 mm Q R 0.50 +0.02/-0.05 mm 0.8 + 0.15/-0.10 mm I J 100 100=10x100=10pF 106 106=10x106=10µF C 1.25 ± 0.10 mm K 0.50 ± 0.20 mm S 0.80 ± 0.07 mm D 1.40 ± 0.15 mm L 0.30 ± 0.03 mm T 0.85 ± 0.10 mm Table 5 Tolerance 3.10 ± 0.30 mm E 1.60 ± 0.20 mm M 0.95 ± 0.10 mm U 0.50 ± 0.10 mm Code Description Code Description Code Description F 2.00 ± 0.20 mm N 0.50 ± 0.05 mm V 0.20 ± 0.02 mm A ±0.05 pF I -10% ~ 0% Q ±0.03 pF G 2.50 ± 0.30 mm O 3.50 ± 0.20 mm X 0.80 ± 0.10 mm B ±0.10 pF J ±5 % Z -20% ~ +80% H 2.80 ± 0.30 mm P 1.60 +0.3/-0.10 mm Z 0.25 ± 0.03 mm C ±0.25 pF K ±10 % X +10% ~ +20% D ±0.50 pF L 0% ~ +10% Table 9 F ±1 % M ±20 % Code Description G ±2 % N -5% ~ +10% G RoHS Compliant H ±3 % P ±0.02 pF Special Control Code Specification No. : FN-000-001-17 ~1~ DCM-003-8.3 Rev 2 信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. 5. EXTERNAL DIMENSIONS Size Inch (mm) 0201(0603) 0402(1005) 0603(1608) 0805(2012) 1206(3216) 1210(3225) L (mm) W (mm) Code / T (mm) 0.60±0.03 0.30±0.03 0.60±0.05 (Cap.≥0.68μF) 0.30±0.05 (Cap.≥0.68μF) 1.00±0.10 0.50±0.10 1.00±0.20#1 0.50±0.20#1 1.60±0.15 0.80±0.15 2.00±0.20 1.25±0.20 3.20±0.20 1.60±0.20 3.20 +0.30/-0.10#2 1.60 +0.30/-0.10#2 3.20±0.30 2.50±0.30 1808(4520) 1812(4532) 1825(4563) 2220(5750) 2225(5763) 4.50±0.40 4.50±0.40 4.50±0.40 5.70±0.40 5.70±0.40 #1 MB (mm) 0.15±0.05 L 0.25 +0.05/-0.10 See No.4 Reference Table 8 2.00±0.25 3.20±0.30 6.30±0.40 5.00±0.40 6.30±0.40 0.40±0.15 0.50±0.20 T 0.60±0.20 0.75±0.35 0.75±0.35 0.75±0.35 0.75±0.35 0.85±0.35 0.85±0.35 W MB MB Fig. 5.1 The outline of MLCC #2 “ ” For 0402 size K thickness products. “ ” For 1206 size P thickness products. 6. GENERAL ELECTRICAL DATA Dielectric C0G Size Rated voltage (WVDC) Capacitance range* Capacitance tolerance** Tan δ* Operating temperature Capacitance characteristic Termination X7R X5R 0201, 0402, 0603, 0805, 0201, 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1206, 1210, 1812, 0201, 0402, 0603 1825, 2220, 2225 1825, 2220, 2225 6.3V, 10V, 16V, 4V, 6.3V, 10V, 10V, 16V, 25V, 50V 25V, 50V 16V, 25V, 50V 0R1 to 100nF 100pF to 820nF 100pF to 820nF B(±0.1pF), C(±0.25pF),D(±0.5pF), J(±5% ), K(±10%), M(±20%) F(±1%),G(±2%) J(±5% ), K(±10%) Cap.1000pF, 25°C at ambient temperature. X7R/X5R : Apply 1.0±0.2Vrms, 1.0KHz±10%, at 25°C ambient temperature. Y5V : Apply 1.0±0.2Vrms, 1.0KHz±10%, at 20°C ambient temperature. ** Preconditioning for Class II MLCC : Perform a heat treatment at 150±10°C for 1 hour, then leave in ambient condition for 24±2 hours before measurement. Y5V Note 1 : X7R/X5R Rated 50V 25V D.F.≤ ≤2.5% ≤3.5% Exception of D.F.≤ ≤3.5% 0201(50V), 0603≥0.047μF, 0805≥0.1μF, 1206≥0.47μF ≤5% 0201≥0.01uF, ≤10% 0402≥0.012μF, 0603>0.1μF Rated D.F.≤ Exception of D.F.≤ 50V ≤5% ≤7% 0603≥0.1μF, 0805≥0.47μF 35V ≤7% --- --0402≥0.047μF, 0603≥0.1μF, 0805≥0.33μF, ≤5% ≤7% ≤10% ≤12.5% ≤5% 0201≥0.01μF 0603≥0.33μF 0201≥0.1μF, 0402≥0.10μF, 0603≥0.47μF 0402≥0.47μF 0201≥0.01μF, 0402≥0.033μF, 0603≥0.15μF, 0805≥0.68μF, 25V ≤7% ≤9% 0402≥0.068μF, 0603≥0.47μF ≤9% 0402≥0.068μF, 0603≥0.68μF ≤10% ≤10% ≤15% 0201≥0.1uF(0201/X7R≥0.022μF), 0402≥0.22uF, 0603≥0.68μF, 0201≥0.012μF, 0402≥0.33μF(0402/X7R≥0.22μF), 0603≥0.33μF, 0201≥0.1μF 16V ≤3.5% 10V ≤5% 6.3V ≤10% ≤15% 0201≥0.1μF 4V ≤15% --- --- ≤5% 16V ≤7% (C1000pF, 1.0±0.2Vrms, 1KHz±10%. Exception of D.F.≤ Cap.≤10µF, 1.0±0.2Vrms, 1KHz±10%**. Cap.>10µF, 0.5±0.2Vrms, 120Hz±20%. ** Test condition : 0.5±0.2Vrms, 1KHz±10%. 10V ≤5% 6.3V 4V ≤10% ≤15% X5R : 01R5≥103, 0201≥224(6.3V,10V,16V)#1, ≤10% ≤15% ≤15% --- * Y5V Rated D.F.≤ Exception of D.F.≤ 50V ≤5% ≤7% 0603≥0.1μF, 0805≥0.47μF 35V ≤7% --- 25V ≤5% ≤9% --0402≥0.047μF, 0603≥0.1μF, 0805≥0.33μF 0402≥0.068μF, 0603≥0.47μF, ≤9% 0402≥0.068μF, 0603≥0.68μF 16V ≤7% (C0.1µF * Cap. change : (4) 150% of rated voltage for below range : Size 0201 0402 12. C0G : Within ±3.0% or ±0.3pF, whichever is larger. Dielectric Rated Voltage Capacitance X7R, X5R : Within ±12.5% for ≥10V**, within ±25% for ≤6.3V. X5R/X7R 16V/25V C≥0.1µF **10V : Within ±25% for 0603≥4.7μF, 0402≥1μF, 0201≥0.1μF. X7R 16V C≥0.022µF 50V C≥0.1µF X5R/X7R Y5V : Within ±30% for ≥10V, within +30/-40% for ≤6.3V. * Q for C0G : 10~25V C≥0.22µF Cap.>30pF, Q≥350. High Y5V 16V C≥0.47µF 10pF≤Cap.≤30pF, Q≥275+2.5C. Temperature 0603 X7R ≥50V C≥0.082µF X5R/X7R 50V C≥0.47µF Load 0805 (Endurance) * Test time : 1000 +24/-0 hrs. * Before initial measurement (Class II only) : To apply Cap.0.01µF * Measurement to be made after keeping at room temp. for 24±2 hrs (Class I) or 48±4 hrs (Class II). ** De-rating conditions : I.R. 25V : 0201≥0.1uF, 0402≥0.22µF 16V : 0201≥0.1uF, 0402≥0.22µF 10V : 0201≥47nF, 0402≥0.47µF, 0603≥0.47µF, 6.3V; 4V; Size≥1812 ≥1GΩ or RxC≥10Ω-F , whichever is smaller Specification No. : FN-000-001-17 ~ 13 ~ DCM-003-8.3 Rev 2 信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. 8. RELIABILITY TEST CONDITIONS AND REQUIREMENTS No. Item Test Condition Requirements * Capacitors mounted on a substrate. A force of 2N(0201) or 5N(0402~0603) or 10N(>0603) applied perpendicular to the place of substrate and parallel Adhesive Strength of Termination the line joining the center of terminations for 10±1 second. 13. (Robustness * No remarkable damage or removal of the terminations. of termination) * The middle part of substrate shall be pressurized by means of the pressurizing rod at a rate of about 1mm per second until the deflection becomes 1mm. * No remarkable damage. Dielectric Cap. Change C0G Within ±5.0% or ±0.5pF, whichever is larger X7R, X5R Within ±12.5% Y5V Within ±30% Resistance to Flexure of 14. Substrate (Substrate (This capacitance change means the change of capacitance under bending test) specified flexure of substrate from the capacitance measured before the test) Unit : mm * Vibration frequency : 10~55 Hz/min. * Total amplitude : 1.5mm. * Test time : 6 hrs. (Two hrs each in three mutually 15. Vibration Resistance perpendicular directions) * Before initial measurement (Class II only) : To apply de-aging at 150°C for 1hr then set for 24±2 hrs at * No remarkable damage. * Cap. change and D.F. : To meet initial spec. room temp. * Measurement to be made after keeping at room temp. for 24±2 hrs (Class I) or 48±4 hrs (Class II). Specification No. : FN-000-001-17 ~ 14 ~ DCM-003-8.3 Rev 2 信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. 9. PACKAGE DIMENSION AND QUANTITY Size 0201(0603) 0402(1005) 0603(1608) 0805(2012) 1206(3216) 1210(3225) 1808(4520) 1812(4532) 1825(4563) 2220(5750) 2225(5763) Thickness (mm) 0.30±0.03 0.30±0.05 0.30±0.09 0.50±0.05 0.50 +0.02/-0.05 0.50±0.20 0.50±0.10 0.80±0.07 0.80 +0.15/-0.10 0.50±0.10 0.60±0.10 0.80±0.10 0.85±0.10 1.25±0.10 1.25±0.20 0.80±0.10 0.85±0.10 0.95±0.10 1.15±0.15 1.25±0.10 1.60±0.20 1.60 +0.30/-0.10 0.85±0.10 0.95±0.10 1.25±0.10 1.60±0.20 2.00±0.20 2.50±0.30 1.25±0.10 1.60±0.20 2.00±0.20 1.25±0.10 1.60±0.20 2.00±0.20 2.50±0.30 2.80±0.30 1.60±0.20 2.00±0.20 2.50±0.30 2.80±0.30 1.60±0.20 2.00±0.20 2.50±0.30 2.80±0.30 1.60±0.20 2.00±0.20 2.50±0.30 2.80±0.30 Paper tape 7” reel 15k 15k 15k 10k 10k 10k 4k 4k 4k 4k 4k 4k 4k 4k 4k - Plastic tape 13” reel 70k 50k 50k 15k 15k 15k 15k 15k 15k 15k 15k - 7” reel 3k 3k 3k 3k 3k 2k 2k 3k 3k 3k 2k 1k 1k 2k 2k 1k 1k 1k 1k 0.5k 0.5k 1k 1k 0.5k 0.5k 1k 1k 0.5k 0.5k 1k 1k 0.5k 0.5k 13” reel 10k 10k 10k 10k 10k 10k 9k 10k 10k 10k 6k 6k 10k 8k 6k 5k 3k Unit : pcs Specification No. : FN-000-001-17 ~ 15 ~ DCM-003-8.3 Rev 2 信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. 9. PACKAGE DIMENSION AND QUANTITY 9.1. EMBOSSED TAPE DIMENSIONS Fig. 9.1 The dimension of paper tape Size Chip Thickness A0 B0 T K0 W P0 10xP0 P1 P2 D0 D1 E F Unit : Size Chip Thickness A0 B0 T K0 W P0 10xP0 P1 P2 D0 D1 E F Unit : 0201 0402 0.50±0.05 0.50±0.10 0.70±0.20 1.20±0.20 ≤0.80 8.00±0.10 4.00±0.10 40.00±0.10 2.00±0.05 2.00±0.05 1.55±0.05 1.75±0.05 3.50±0.05 mm 0.30±0.03 0.39±0.07 0.69±0.07 ≤0.50 8.00±0.10 4.00±0.10 40.00±0.10 2.00±0.05 2.00±0.05 1.55±0.05 1.75±0.05 3.50±0.05 mm 0.80±0.10 2.00±0.10 3.50±0.10 0.95±0.05 8.00±0.10 4.00±0.10 40.00±0.20 4.00±0.10 2.00±0.05 1.55±0.05 1.75±0.10 3.50±0.05 mm Fig. 9.2 The dimension of plastic tape 0603 0805 0.80±0.07 0.80 +0.15/-0.1 0.80±0.10 1.00 +0.05/-0.1 1.80±0.10 0.95±0.05 8.00±0.10 4.00±0.10 40.00±0.20 4.00±0.10 2.00±0.05 1.55±0.05 1.75±0.05 3.50±0.05 mm 1.02 +0.05/-0.1 1.80±0.10 0.97±0.05 8.00±0.10 4.00±0.10 40.00±0.20 4.00±0.10 2.00±0.05 1.55±0.05 1.75±0.05 3.50±0.05 mm 1.50±0.10 2.30±0.10 0.95±0.05 8.00±0.10 4.00±0.10 40.00±0.20 4.00±0.10 2.00±0.05 1.55±0.05 1.75±0.05 3.50±0.05 mm 1206 0.95±0.10 1.25±0.10
