7L26072002

TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com SPECIFICATION FOR APPROVAL CUSTOMER : PRODUCT TYPE : SMD TCXO 2.5 * 2.0 NOMINAL FREQ. : 26 MHz TXC P/N : 7L26072002 REVISION : S1 CUSTOMER P/N : PM / SALES : DATE : CUSTOMER SIGNATURE & DATE : (1) TXC requires one copy returned with signature and title of authorized individual that signifies acceptance of the attached specifications. (2) Orders received and accepted by TXC after return of signed copy of specification will be produced per these specifications. (3) Any changes to these specifications must be agreed upon by both parties and new revision of the Product Specification Sheet will be issued. (4) Any issuance of purchase order prior to consigning back the Approval page of "Specification Sheets" from customers will be regarded as the agreement on the contents of these specifications. Attachment(s): V 1. Product Specification Sheet 2. Testing Report(Electrical & Temperature) 3. Reliability Report RoHS Compliant FMT-DOC024 Issue date: 12.15 '08 VER.E TXC CORPORATION 4F, NO. 16, Sec. 2 Chung Yang S Rd., Peitou, Taipei, Taiwan. TEL : 886-2-2894-1202 , 886-2-2895-2201 FAX : 886-2-2894-1206 , 886-2-2895-6207 www.txccorp.com PRODUCT SPECIFICATION SHEET CUSTOMER : PRODUCT TYPE : SMD TCXO 2.5 * 2.0 NOMINAL FREQ. : 26 MHz TXC P/N : 7L26072002 REVISION : S1 PE/RD QA MFG 2012/11/20 NOTE: (1) Lead Free Products are " Directive 2002 / 95 / EC of The European Parliament of 27 January 2003 on the restriction of the use of certain hazardous substances (RoHS) in electrical and electronic equipment" Compliant (Attachment: SGS Test Report). (2) Revision "Sx" is for engineering samples only. PE/RD's approval required. (3) Revision "Ax" is production ready. PE, QA and MFG's approval required. RoHS Compliant FMT-DOC024 Issue date: 12.15 '08 VER.E PAGE : 1 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 Rev Revise page S1 N/A FMT-DOC024 Revise contents Initial released P/N : 7L26072002 REVISION : S1 Date Ref.No. Reviser 2012/11/20 N/A Su-Chen Chiang Issue date: 12.15 '08 VER.E PAGE : 2 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 ■ ELECTRICAL SPECIFICATIONS Condition Item Parameters 1 Nominal Frequency 2 Operating Temperature Range 3 Supply Voltage 4 Current Drain 5 Output Level(Vp-p) 6 Output Type 7 8 9 10 11 12 13 V 1.5 mA V 0.8 Resistance 9 10 11 kΩ Capacitance 9 10 11 pF 3 vs. Load ± 10% output load ±0.2 ppm vs. Supply Voltage Vcc: 1.8 V ±0.1 V ±0.2 ppm Vcont = 1.5 V +9 +15 ppm Vcont = 0.3 V -15 -9 ppm kΩ 500 -40 vs. Frequency Within ± 1 ppm vs. Output Level To 90% of Vp-p 45 50 ±20 % +85 ℃ 2.0 ms 2.0 ms 55 % ±1.0 ppm/year -5 dBc 23 @ 1 kHz offset -130 dBc/Hz 24 @ 10 kHz offset -140 dBc/Hz @ 100 kHz offset -150 dBc/Hz -152 dBc/Hz 25 Phase Noise 26 1 Temp: -30 ~ +85 ℃ AFC Linearity Harmonics 1.90 vs. Temperature Storage Temperature 22 1.80 2 17 Aging ℃ ppm 16 21 +85 ppm Input Impedance for AFC pin Duty Cycle MHz -30 1.70 Note ±2.5 15 20 26.000000 UNITS ±1.5 Auto-Frequency-Control(AFC) Range (Ref : Vcon=0.9 V) 19 MAX After 2 times reflow Frequency Tolerance Start-up Time TYP Clipped Sinewave 14 18 MIN With standard output load Output Load Frequency Stability Electrical Specifications @ 1 MHz offset Note 1 Decoupling capacitor is required in external circuit Note 2 Refer to nominal frequency Note 3 Refer to frequency at 25±2℃ FMT-DOC024 Issue date: 12.15 '08 VER.E PAGE : 3 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 ■ TESTING CIRCUIT External Components VCC Output VCC C1 10 nF OUT TCXO AFC AFC C2 1000 pF RL CL Name Function C1 AC Noise Bypass for VCC C2 DC Block for Output GND RL Load Resistance CL Load Capacitance Note: Bypass capacitor (C1) and DC blocking capacitor (C2) should be placed. ■ DIMENSIONS Pin Connection 2.50 ± 0.15 2.00 ± 0.15 Pin 4 Name Function Pin 1 AFC Pin 2 GND Pin 3 OUTPUT Pin 4 VCC Pin 3 Top View Pin 1 Pin 2 Pin 1 Pin 4 Pin 3 Pin 1 Pin 2 0.825 0.8 Max. Recommended Land Pattern 0.825 0.70 0.650 Pin 2 0.70 0.60 Bottom View 0.50 Pin 3 Pin 4 0.35 FMT-DOC024 1.80 1.80 0.50 Unit: mm 0.35 Issue date: 12.15 '08 VER.E PAGE : 4 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 ■ SUGGESTED REFLOW PROFILE Note : Total Time: 200 sec. Max., Solder Melting Point: 220°C ■ MARKING TCXO Date Code TCXO Lot Code T XXX Company Name ■ * Frequency Divider Index (optional) XXXXX X'tal Lot Code Pin1 Index X'tal Date Code X'tal Frequency Code, ex:38.4 MHz=38 DATE CODE MONTH YEAR JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC 2005 2009 2013 2017 A B C D E F G H J K L M 2006 2010 2014 2018 N P Q R S T U V W X Y Z 2007 2011 2015 2019 a b c d e f g h j k l m 2008 2012 2016 2020 n q p * This date code will be cycled every four years. r s t u v w x y z Note: If TCXO frequency is X'tal frequency divided by 2, then frequency divider index appears. If TCXO frequency is the same as X'tal frequency, then no frequency divider index appears. FMT-DOC024 Issue date: 12.15 '08 VER.E PAGE : 5 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 ■ PACKING : (EIA-481-2) G1.5 B E H 1.75 4.0 F INDEX MARK A C Trailer D Feeding Empty Sealed Parts Leader 160mm(Min) 160mm(Min) 230mm(Min) User direction of feed W W1 2.0 L L1 Unit: mm A DIMENSIONS (mm) 1.15 B C D E F G H L L1 W W1 2.70 2.25 4.00 8.00 4.00 1.55 1.75 178 13.0 11.6 8.4 Standard Reel Quantity is 3,000 pcs per reel ■ WEIGHT 0.0135 g / piece(TYP), 40 ± 2 g /3 kpcs( regardless of tape weight ) FMT-DOC024 Issue date: 12.15 '08 VER.E PAGE : 6 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 ■ STRUCTURE ILLUSTRATION Crystal Enclosure Seal: Seam Welding 6 4 1 2 5 7 3 8 9 No. COMPONENTS 1 Cap 2 Base MATERIALS Metal(Fe + Co + Ni) Ceramic 3 Pad Au 4 5 6 7 8 9 Crystal Blank Conductive Adhesive Electrode Underfill Bump IC SiO2 Ag Noble Metal Organic Au Si FMT-DOC024 FINISH/SPECIFICATIONS Color Black Tungsten Metalize + Ni Plating + Au Plating Silicone Resin Color Black Issue date: 12.15 '08 VER.E PAGE : 7 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 ■ RELIABILITY SPECIFICATIONS 1. Mechanical Endurance No. Test Item 1.1 Drop Test 1.2 Mechanical Shock 1.3 Vibration 1.4 Gross Leak Criteria Test Methods Hegiht : 100 cm height Direction : X,Y,Z 6 directions Test cycles : 3 cycles Fall freely on to concrete floor Mounting on test fixture (total weight=100 g) Acceleration : 1000 g Duration : 0.5 ms Test cycles : 3 times for all 3 directions Frequency range : 10 ~ 2000 Hz Amplitude : 1.52 mm (10 ~ 80 Hz) Acceleration : 20 g (80 ~ 2000 Hz) Sweep speed : 20 minutes/cycle Test Pressure : 2 kg/cm +/- 2.0 ppm +/- 2.0 ppm Direction : X,Y,Z 3 directions Duration : 4 hours/each direction Standard sample for automatic gross leak detector. 2 +/- 2.0 ppm < 1.5 × 10-5 Pa m3 / sec 1.5 Fine Leak Helium bomging 4.5 kgf/cm2 for 2 hours < 1.0 × 10-9 Pa m3 / sec 1.6 Solderability Preheate temperature : 125℃ ± 5℃ Preheate time : 120 sec Solding temperature : 245℃ ± 5 ℃ Duration : 5 ± 1 sec Method : Solder bath method 90% Coated [Note] Criteria mean the maximum frequency change after reliability test, frequency shell be measured at 25℃. FMT-DOC024 Issue date: 12.15 '08 VER.E PAGE : 8 / 8 TXC CORPORATION PRODUCT TYPE : SMD TCXO 2.5 * 2.0 P/N : 7L26072002 REVISION : S1 2. Environmental Endurance No. Test Item 2.1 High Temp. Storage 2.2 Low Temp. Storage Test Methods Temperature : +125℃ ± 3℃ Duration : 168 hours Temperature : -40℃ ± 3℃ Duration : 500 hours Criteria +/- 2.0 ppm +/- 2.0 ppm Total 100 cycles of the following temperature cycle : 2.3 Thermal Shock (Air to Air) Temperature : 85℃ ± 3℃ 2.4 High Temp＆Humidity Humidity: RH 85% Duration : 168 hours Temperature : 85℃ ± 3℃ 2.5 Aging Duration : 500 hours Voltage input by specification +/- 2.0 ppm +/- 2.0 ppm +/- 2.0 ppm [Note] Criteria mean the maximum frequency change after reliability test, frequency shell be measured after 2 hours at 25℃ leaving. FMT-DOC024 Issue date: 12.15 '08 VER.E
