PMEG4020EP

PMEG4020EP 2 A low VF MEGA Schottky barrier rectifier SOD-123FL Features 0．８±0.2 2.8±0.1 0.10-0.30 • • • • 1.8± 0.1 • Metal to silicon rectifier, majority carrier conduction. For use in low voltage, high frequency inverters free wheeling, and polarity protection applications. Low power loss, high efficiency. High current capability, low VF. High surge capacity. Glass passivated 1.3± 0.15 • Cathode Band Top View 0.6±0.25 3.7±0.2 Dimensions in millimeters Schottky Rectifiers Absolute Maximum Ratings* TA = 25°C unless otherwise noted CHARACTERISTICS SYMBOL PMEG4020EP UNIT Maximum Recurrent Peak Reverse Voltage VRRM 40 V Maximum RMS Voltage VRMS 28 V VDC 40 V Maximum DC Blocking Voltage Maximum Average Forward Rectified Current Peak Forward Surage Current @TL=100 ℃ 8.3ms Single Half Sine-Wave Super Imposed On Rated Load (JEDEC Method) Maximum Forward Voltage at 2.0A DC Maximum DC Reverse Current @TJ=25℃ at Rated DC Blocking Voltage @TJ=100℃ Typical Junction Capacitance (Note1) Typical Thermal Resistance (Note2) Operating Temperature Range Storage Temperature Range www.slkormicro.com I(AV) 2.0 A IFSM 60 A VF 0. 45 0.5 0.55 0.7 0.85 1.0 IR 20 0.92 . 0.95 V mA CJ 200 pF RθJL 15 ℃/W TJ -55 to +150 ℃ TSTG -55 to + 150 ℃ 1 PMEG4020EP FIG.2 -- TYPICAL FORWARD CHARACTERISTICS T L =100℃ 8.3ms Single Half Sine-Wave (JED E C M ethod) 40 30 20 10 0 1 10 10 0 10 1 SS 25 A~ SS SS 26 A 28 A~ SS 22 0A 50 100 SS 22A ~S S2 4A INSTANTANEOUS FORWARD CURRENT,AMPERES PEAK FORWARD SURGE CURRENT,AMPERES FIG.1-- PEAK FORWARD SURGE CURRENT 0.1 0.01 Tj=25oC Pulse Width=300 s 1% Duty Cycle .2 .3 .4 .5 .6 .7 .8 .9 NUMBER OF CYCLES AT 60Hz INSTANTANEOUS FORWARD VOLTAGE,VOLTS INSTANTANEOUS REVERSE CURRENT,MICRO AMPERES FIG.3 -- TYPICAL REVERSE CHARACTERISTICS 10 1.0 SS28-SS210 0.1 0.01 0.001 0.001 0 TJ=125℃ SS22-SS26 SS28-SS210 T J=25℃ SS22-SS26 20 40 60 80 1 00 PERCENT OF RATED PEAK REVERSE VOLTAGE, www.slkormicro.com 2
