山东晶导微电子股份有限公司
Jingdao Microelectronics co.LTD
BZT52C2V4SW~BZT52C43SW
Silicon Planar Zener Diodes
PINNING
PIN
FEATURES
• Total power dissipation: Max. 200mW.
• Wide zener reverse voltage range 2.4V to 43V.
• Ideally suited for automated assembly processes
DESCRIPTION
1
Cathode
2
Anode
2
MECHANICAL DATA
▪Case: SOD-323W
▪Terminals: Solderable per MIL-STD-750, Method 2026
▪A pprox. Weight: 5.48mg / 0.00019oz
1
Top View
Simplified outline SOD-323W and symbol
Absolute Maximum Ratings And Characteristics (Ta = 25 °C)
Value
Unit
Power Dissipation
PD
200
mW
Forward Voltage at I F = 10 mA
VF
0.9
V
RθJA
625
°C/W
T j , T stg
-55 ~ +150
°C
Typical thermal resistance juncting to ambient
Operating and Storage Temperature Range
Fig.1 Power Derating Curve
Power Dissipation P D ( W )
250
200
150
100
50
0
25
50
75
100
125
150
T a ,Case Temperature (°C)
2019.08
175
Transient Thermal Impedance( °C /W)
Symbol
Parameter
Fig.2 Typical Transient Thermal Impedance
2000
1000
100
10
0.01
0.1
1
10
100
t, Pulse Duration(sec)
SOD-323W-W-BZT52C2V4SW~BAT52C43SW-200mW
Page 1 of 3
山东晶导微电子股份有限公司
Jingdao Microelectronics co.LTD
BZT52C2V4SW~BZT52C43SW
Characteristics at Ta = 25°C
(NOTE 2)
Type
Marking
(NOTE 3)
V ZT(@ I ZT)
Min(V)
Maximum
Reverse
Current
Maximum Zener
Impedance
Zener Voltage Range
(NOTE 2)
Typical
Temperature
Coefficient
@I ZTC mV/℃
Test
Current
I ZTC
I ZT
Z ZT(@ I ZT) Z ZK(@ I ZK)
I ZK
IR
VR
(Ω)
mA
μA
V
MIN
MAX
mA
Nom(V)
Max(V)
(mA)
BZT52C2V4SW
WX
2.2
2.4
2.6
5
100
600
1
50
1
-3.5
0
5
BZT52C2V7SW
W1
2.5
2.7
2.9
5
100
600
1
20
1
-3.5
0
5
BZT52C3V0SW
W2
2.8
3
3.2
5
95
600
1
10
1
-3.5
0
5
BZT52C3V3SW
W3
3.1
3.3
3.5
5
95
600
1
5
1
-3.5
0
5
BZT52C3V6SW
W4
3.4
3.6
3.8
5
90
600
1
5
1
-3.5
0
5
BZT52C3V9SW
W5
3.7
3.9
4.1
5
90
600
1
3
1
-3.5
0
5
BZT52C4V3SW
W6
4
4.3
4.6
5
90
600
1
3
1
-3.5
0
5
BZT52C4V7SW
W7
4.4
4.7
5
5
80
500
1
3
2
-3.5
0.2
5
BZT52C5V1SW
W8
4.8
5.1
5.4
5
60
480
1
2
2
-2.7
1.2
5
BZT52C5V6SW
W9
5.2
5.6
6
5
40
400
1
1
2
-2
2.5
5
BZT52C6V2SW
WA
5.8
6.2
6.6
5
10
150
1
3
4
0.4
3.7
5
BZT52C6V8SW
WB
6.4
6.8
7.2
5
15
80
1
2
4
1.2
4.5
5
BZT52C7V5SW
WC
7
7.5
7.9
5
15
80
1
1
5
2.5
5.3
5
BZT52C8V2SW
WD
7.7
8.2
8.7
5
15
80
1
0.7
5
3.2
6.2
5
BZT52C9V1SW
WE
8.5
9.1
9.6
5
15
100
1
0.5
6
3.8
7
5
BZT52C10SW
WF
9.4
10
10.6
5
20
150
1
0.2
7
4.5
8
5
BZT52C11SW
WG
10.4
11
11.6
5
20
150
1
0.1
8
5.4
9
5
BZT52C12SW
WH
11.4
12
12.7
5
25
150
1
0.1
8
6
10
5
BZT52C13SW
WI
12.4
13
14.1
5
30
170
1
0.1
8
7
11
5
BZT52C15SW
WJ
13.8
15
15.6
5
30
200
1
0.1 10.5
9.2
13
5
BZT52C16SW
WK
15.3
16
17.1
5
40
200
1
0.1
11.2
10.4
14
5
BZT52C18SW
WL
16.8
18
19.1
5
45
225
1
0.1 12.6
12.4
16
5
BZT52C20SW
WM
18.8
20
21.2
5
55
225
1
0.1
14.4
18
5
20.8
22
23.3
5
55
250
1
0.1 15.4
16.4
20
5
250
14
BZT52C22SW
WN
BZT52C24SW
WO
22.8
24
25.6
5
70
1
0.1 16.8
18.4
22
5
BZT52C27SW
WP
25.1
27
28.9
2
80
300
0.5
0.1 18.9
21.4
25.3
2
BZT52C30SW
WQ
28
30
32
2
80
300
0.5
0.1
24.4
29.4
2
BZT52C33SW
WR
31
33
35
2
80
325
0.5
0.1 23.1
27.4
33.4
2
21
BZT52C36SW
WS
34
36
38
2
90
350
0.5
0.1 25.2
30.4
37.4
2
BZT52C39SW
WT
37
39
41
2
130
350
0.5
0.1 27.3
33.4
41.2
2
BZT52C43SW
WU
40
43
46
2
100
700
1
10
12
5
NOTE:
0.1
32
1. Device mounted on ceramic PCB: 7.6mm x 9.4mm x 0.87mm with pad areas 25mm2 .
2. Short duration test pulse used to minimize self-heating effect.
3. f = 1kHz.
2019.08
www.sdjingdao.com
Page 2 of 3
山东晶导微电子股份有限公司
BZT52C2V4SW~BZT52C43SW
Jingdao Microelectronics co.LTD
PACKAGE OUTLINE
Plastic surface mounted package; 2 leads
SOD-323W
E
E
D
b
A
C
A1
∠ALL ROUND
L1
E1
SOD-323W mechanical data
A
C
D
E
E1
b
L1
A1
max
1.1
0.15
1.4
1.8
2.75
0.4
0.45
0.2
min
0.8
0.08
1.2
1.4
2.55
0.25
0.2
max
43
5.9
55
70
108
16
16
min
32
3.1
47
63
100
9.8
7.9
UNIT
∠
mm
9°
8
mil
The recommended mounting pad size
1.4
(55)
1.2
(47)
1.2
(47)
1.2
(47)
Unit: mm
(mil)
2019.08
90829
Page 3 of 3
