SS14

UMW R UMW SS12 THRU SS120 20V-200V 1A FEATURES Schottky barrier rectifier Guardring protection Low forward voltage Reverse energy tested High current capability Extremely low thermal resistance Mechanical Data Case: SMA molded plastic body 1111 Polarity: Color band denotes cathode end Mounting position: ANY Weight: 0.002 ounces, 0.064 gram MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Ratings at 25 C ambient temperature unless otherwise specified. Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%. SYMBOLS SS12 SS13 SS14 SS15 SS16 Maximum repetitive peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage Maximum average forward rectified current at TL(see fig.1) Peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC Method) Maximum instantaneous forward voltage at 1.0A Maximum DC reverse current TA=25 C TA=100 C at rated DC blocking voltage Typical junction capacitance (NOTE 1) Typical thermal resistance (NOTE 2) Operating junction temperature range Storage temperature range VRRM VRMS VDC 20 14 20 30 21 30 40 28 40 50 35 50 60 42 60 SS18 SS110 SS115 80 56 80 100 70 100 150 105 150 SS120 UNITS 200 140 200 VOLTS VOLTS VOLTS I(AV) 1.0 Amp IFSM 30.0 Amps VF 0.70 0.55 0.45 0.5 10.0 IR 88.0 -50 to +125 -50 to +150 -50 to +150 0.95 0.2 2.0 5.0 90 110 CJ RθJA TJ, TSTG 0.85 Volts mA pF C/W C C Note:1.Measured at 1MHz and applied reverse voltage of 4.0V D.C. 2.P.C.B. mounted with 0.2x0.2”(5.0x5.0mm) copper pad areas www.umw-ic.com 1 友台半导体有限公司 UMW R UMW SS12 THRU SS120 20V-200V 1A 1.0 FIG.2-- PEAK FORWARD SURGE CURRENT PEAK FORWARD SURGE CURRENT,AMPERES CURRENT,AMPERES FIG.1 -- FORWARD DERATING CURVE Resistive or inductive Load 0.5 0 50 60 70 80 90 100 110 120 130 140 150 160 170 LEAD TEMPERATURE INSTANTANEOUS REVERSE CURRENT,MICRO AMPERES INSTANTANEOUS FORWARD CURRENT,AMPERES SS12-SS14 10 SS18-SS110 0 .0 1 0 Pulse Width=300 1%DUTY CYCLE S SS15-SS16 0 .2 0 .4 0 .6 0 .8 1 .0 1 .2 1 .4 1 .6 INSTANTANEOUS FORWARD VOLTAGE,VOLTS www.umw-ic.com 20 0 1 10 10 0 FIG.4 -- TYPICAL REVERSE CHARACTERISTICS 50 0 .1 O TL=100 C 8 .3 m s S in g le H a lf S in e -W a v e (J E D E C M e th o d ) NUMBER OF CYCLES AT 60Hz FIG.3 -- TYPICAL FORWARD CHARACTERISTICS 1 40 100 SS15-SS110 10 TJ=125℃ 1 SS12-SS14 SS18-SS110 0.1 T J=25℃ SS12-SS16 0.01 0.001 0 20 40 60 80 1 00 PERCENT OF RATED PEAK REVERSE VOLTAGE, 2 友台半导体有限公司 UMW R UMW SS12 THRU SS120 20V-200V 1A ORDERING INFORMATION Order Code Package Baseqty Deliverymode UMW SS12 SMA 2000 Tape and reel UMW SS13 SMA 2000 Tape and reel UMW SS14 SMA 2000 Tape and reel UMW SS15 SMA 2000 Tape and reel UMW SS16 SMA 2000 Tape and reel UMW SS18 SMA 2000 Tape and reel UMW SS110 SMA 2000 Tape and reel UMW SS115 SMA 2000 Tape and reel UMW SS120 SMA 2000 Tape and reel www.umw-ic.com 3 友台半导体有限公司
