MM3Z Series
SOD-323 Plastic-Encapsulate Zener Diode
SOD-323
特征 Features
齐纳击穿阻抗低; Low Zener Impedance
最大功率耗散 200mW; Power Dissipation of 200mW
高稳定性和可靠性。High Stability and High Reliability
机械数据 Mechanical Data
封装: SOD-323 封装 SOD-323 Small Outline Plastic Package
极性: 色环端为负极 Polarity: Color band denotes cathode end
安装位置: 任意 Mounting Position: Any
极限值和温度特性(TA = 25℃ 除非另有规定)
Maximum Ratings & Thermal Characteristics (Ratings at 25℃ ambient temperature unless otherwise specified.)
参数 Parameters
符号 Symbol
数值 Value
单位 Unit
Pd
200
mW
功率消耗 Power Dissipation
1)
Vf
0.9 2)
V
正向压降 Forward Voltage @IF=10mA
Ts
-65-+150
存储温度 Storage temperature range
℃
Device mounted on ceramic PCB: 7.6mm x 9.4mm x 0.87mm with pad areas 25mm²
Short duration test pulse used to minimize self-heating effect
f=1KHz
电特性 (TA = 25℃ 除非另有规定)
1)
2)
3)
Electrical Characteristics (Ratings at 25℃ ambient temperature unless otherwise specified).
Zener Voltage Range
Device
Marking
Vz@Izt
Izt
Nom(V)
Min(V)
Max(V)
mA
Maximum Zener
3)
Impedance
Zzt
Zzk
Izk
@Izt
@Izk
mA
Ω
Maximum
Reverse Current
IR
VR
uA
V
Typical
Temperature
coefficent @
IZTC=mV/℃
Min
Max
Test
Current
IZTC
mA
MM3Z2V0
WY
2.0
1.80
2.15
5
150
600
1.0
100
1.0
-3.5
0
5
MM3Z2V4
WX
2.4
2.2
2.6
5
100
600
1.0
50
1.0
-3.5
0
5
MM3Z2V7
W1
2.7
2.5
2.9
5
100
600
1.0
20
1.0
-3.5
0
5
MM3Z3V0
W2
3.0
2.8
3.2
5
95
600
1.0
10
1.0
-3.5
0
5
MM3Z3V3
W3
3.3
3.1
3.5
5
95
600
1.0
5
1.0
-3.5
0
5
MM3Z3V6
W4
3.6
3.4
3.8
5
90
600
1.0
5
1.0
-3.5
0
5
MM3Z3V9
W5
3.9
3.7
4.1
5
90
600
1.0
3
1.0
-3.5
0
5
MM3Z4V3
W6
4.3
4.0
4.6
5
90
600
1.0
3
1.0
-3.5
0
5
MM3Z4V7
W7
4.7
4.4
5.0
5
80
500
1.0
3
2.0
-3.5
0.2
5
MM3Z5V1
W8
5.1
4.8
5.4
5
60
480
1.0
2
2.0
-2.7
1.2
5
MM3Z5V6
W9
5.6
5.2
6.0
5
40
400
1.0
1
2.0
-2.0
2.5
5
MM3Z6V2
WA
6.2
5.8
6.6
5
10
150
1.0
3
4.0
0.4
3.7
5
MM3Z6V8
WB
6.8
6.4
7.2
5
15
80
1.0
2
4.0
1.2
4.5
5
MM3Z7V5
WC
7.5
7.0
7.9
5
15
80
1.0
1
5.0
2.5
5.3
5
MM3Z8V2
WD
8.2
7.7
8.7
5
15
80
1.0
0.7
5.0
3.2
6.2
5
MM3Z9V1
WE
9.1
8.5
9.6
5
15
100
1.0
0.5
6.0
3.8
7.0
5
MM3Z10
WF
10
9.4
10.6
5
20
150
1.0
0.2
7.0
4.5
8.0
5
MM3Z11
WG
11
10.4
11.6
5
20
150
1.0
0.1
8.0
5.4
9.0
5
MM3Z12
WH
12
11.4
12.7
5
25
150
1.0
0.1
8.0
6.0
10.0
5
MM3Z13
WI
13
12.4
14.1
5
30
170
1.0
0.1
8.0
7.0
11.0
5
www.yongyutai.com
PAGE 1
MM3Z Series
Zener Voltage Range
Device
Marking
Vz@Izt
Izt
Maximum Zener
Impedance
Zzt
Zzk
Izk
@Izt
@Izk
mA
Ω
Maximum
Reverse Current
IR
VR
Typical
Temperature
coefficent @
IZTC=mV/℃
Min
Max
Test
Current
IZTC
Nom(V)
Min(V)
Max(V)
mA
uA
V
MM3Z15
WJ
15
13.8
15.6
5
30
200
1.0
0.1
10.5
9.2
13.0
mA
5
MM3Z16
WK
16
15.3
17.1
5
40
200
1.0
0.1
11.2
10.4
14.0
5
MM3Z18
WL
18
16.8
19.1
5
45
225
1.0
0.1
12.6
12.4
16.0
5
MM3Z20
WM
20
18.8
21.2
5
55
225
1.0
0.1
14.0
14.4
18.0
5
MM3Z22
WN
22
20.8
23.3
5
55
250
1.0
0.1
15.4
16.4
20.0
5
MM3Z24
WO
24
22.8
25.6
5
70
250
1.0
0.1
16.8
18.4
22.0
5
MM3Z27
WP
27
25.1
28.9
2
80
300
0.5
0.1
18.9
21.4
25.3
2
MM3Z30
WQ
30
28.0
32.0
2
80
300
0.5
0.1
21.0
24.4
29.4
2
MM3Z33
WR
33
31.0
35.0
2
80
325
0.5
0.1
23.1
27.4
33.4
2
MM3Z36
WS
36
34.0
38.0
2
90
350
0.5
0.1
25.2
30.4
37.4
2
MM3Z39
WT
39
37.0
41.0
2
130
350
0.5
0.1
27.3
33.4
41.2
2
MM3Z43
WU
43
40.0
46.0
2
100
700
1.0
0.1
32.0
10.0
12.0
5
MM3Z47
WV
47
44.0
50.0
2
100
750
1.0
0.1
35.0
10.0
12.0
5
MM3Z51
WW
51
48.0
54.0
2
100
750
1.0
0.1
38.0
10.0
12.0
5
MM3Z56
XW
56
52.0
60.0
2
135
700
1.0
0.1
39.0
10.0
12.0
5
MM3Z62
6E
62
58.0
66.0
2
200
1000
1.0
0.2
47.0
10.0
12.0
5
MM3Z68
6F
68
64.0
72.0
2
250
1000
1.0
0.2
52.0
10.0
12.0
5
MM3Z75
6H
75
70.0
79.0
2
300
1000
1.0
0.2
57
10.0
12.0
5
Breakdown characteristics
at Tj=constant (pulsed)
Forward characteristics
www.yongyutai.com
Admissible power dissipation versus ambient temperature
PAGE 2
MM3Z Series
Pulse thermal resistance versus pulse duration
Dynamic resistance versus Zener current
Capacitance versus Zener voltage
Dynamic resistance versus Zener current
Dynamic resistance versus Zener current
Thermal differential resistance versus Zener voltage
www.yongyutai.com
PAGE 3
MM3Z Series
Dynamic resistance versus Zener voltage
Temperature dependence of Zener voltage versus Zener
voltage
Temperature dependence of Zener voltage versus Zener
Change of Zener voltage versus junction temperature
voltage
Change of Zener voltage versus junction temperature
Change of Zener voltge from turn-on up to the point of thermal
equilibrium versus Zener voltage
www.yongyutai.com
PAGE 4
MM3Z Series
SOD-323 PACKAGE OUTLINE Plastic surface mounted package
SOD-323
Symbol
Min.(mm)
1.000
A
A1
0.000
0.100
A2
0.800
0.900
b
0.250
0.350
c
0.080
0.150
D
1.200
1.400
E
1.600
1.800
E1
2.500
2.700
0.475REF
L
www.yongyutai.com
Max.(mm)
L1
0.250
0.400
θ
0º
8º
PAGE 5
