PRT-09922

Page 1 / Mating receptical to be assembled as a set 6 1 2...6 1 2...6 Connector A Supplier: 4UConn Part #: 01951 (2,3,4,5, SCALE 1.500 1 &6 poles) Connector B Supplier: 4UConn Part #: 01931 (2,3,4,5, Crimp pin part #: 01993 Wire Entry View SCALE 1.500 &6 poles) Tolerances, Unless noted0.0 +/0.00 +/0.000 +/- Connector A Pin 1 2 3 4 5 6 Connector B Pin 1 2 3 4 5 6 5 sets of cables with male and female connectors (sets of 2, 3, 4, 5, 6 wires in width) Use the denoted wire colors up to given width Wire Type Braided 24 AWG - Black Braided 24 AWG - Red Braided 24 AWG - Orange Braided 24 AWG - Yellow Braided 24 AWG - Green Braided 24 AWG - Blue MOLEX_TO_MOLEX_13_II_07 Units Inches 19 Apr 10 Tolerance +/- .0625 Drawn by Spark Fun Electronics for Price Quote Drafter Scale 1.5
