PDTB114EQAZ

PDTB113/123/143/114EQA series 50 V, 500 mA PNP resistor-equipped transistors Rev. 1 — 30 March 2016 Product data sheet 1. Product profile 1.1 General description PNP Resistor-Equipped Transistor (RET) family in a leadless ultra small DFN1010D-3 (SOT1215) Surface-Mounted Device (SMD) plastic package with visible and solderable side pads. Table 1. Product overview Type number R1 R2 Package Nexperia NPN complement PDTB113EQA 1 k 1 k PDTB123EQA 2.2 k 2.2 k DFN1010D-3 (SOT1215) PDTD113EQA PDTD123EQA PDTB143EQA 4.7 k 4.7 k PDTD143EQA PDTB114EQA 10 k 10 k PDTD114EQA 1.2 Features and benefits  500 mA output current capability  Built-in bias resistors   10% resistor ratio tolerance  Simplifies circuit design  Reduces component count  Reduced pick and place costs  Low package height of 0.37 mm  Suitable for Automatic Optical Inspection (AOI) of solder joint  AEC-Q101 qualified 1.3 Applications  Digital applications  Cost saving alternative for BC807/BC817 series in digital applications  Controlling IC inputs  Switching loads 1.4 Quick reference data Table 2. Quick reference data Symbol Parameter Conditions Min Typ Max Unit VCEO collector-emitter voltage open base - - 50 V IO output current - - 500 mA PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 2. Pinning information Table 3. Pinning Pin Symbol Description 1 I input (base) 2 GND GND (emitter) Simplified outline Graphic symbol O 1 3 O output (collector) 4 O output (collector) R1 I 4 3 R2 GND 2 aaa-019606 Transparent top view 3. Ordering information Table 4. Ordering information Type number PDTB113EQA PDTB123EQA PDTB143EQA Package Name Description Version DFN1010D-3 plastic thermal enhanced ultra thin small outline package; no leads; 3 terminals; body: 1.1  1.0  0.37 mm SOT1215 PDTB114EQA PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 2 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 4. Marking Table 5. Marking codes Type number Marking code PDTB113EQA 00 00 01 PDTB123EQA 01 01 01 PDTB143EQA 01 01 11 PDTB114EQA 01 10 11 4.1 Binary marking code description READING DIRECTION MARKING CODE (EXAMPLE) YEAR DATE CODE VENDOR CODE PIN 1 INDICATION MARK MARK-FREE AREA READING EXAMPLE: 11 01 10 aaa-008041 Fig 1. SOT1215 binary marking code description 5. Limiting values Table 6. Limiting values In accordance with the Absolute Maximum Rating System (IEC 60134). PDTB113_123_143_114EQA_SER Product data sheet Symbol Parameter Conditions Min Max Unit VCBO collector-base voltage open emitter - 50 V VCEO collector-emitter voltage open base - 50 V VEBO emitter-base voltage open collector - 10 V All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 3 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors Table 6. Limiting values …continued In accordance with the Absolute Maximum Rating System (IEC 60134). Symbol Parameter Conditions Min Max Unit VI input voltage PDTB113EQA 10 +10 V PDTB123EQA 12 +10 V PDTB143EQA 30 +10 V PDTB114EQA 50 +10 V - 500 mA [1] - 325 mW [2] - 575 mW [3] - 525 mW [4] - 940 mW output current IO total power dissipation Ptot Tamb  25 C Tj junction temperature - 150 C Tamb ambient temperature 55 +150 C Tstg storage temperature 65 +150 C [1] Device mounted on an FR4 Printed-Circuit Board (PCB), single-sided copper, tin-plated and standard footprint. [2] Device mounted on an FR4 PCB, single-sided copper, tin-plated; mounting pad for collector 1 cm2. [3] Device mounted on an FR4 PCB, 4-layer copper, tin-plated and standard footprint. [4] Device mounted on an FR4 PCB, 4-layer copper, tin-plated; mounting pad for collector 1 cm2. aaa-020277 1 (1) Ptot (W) 0.8 0.6 (2) (3) 0.4 (4) 0.2 0 -75 -25 25 75 125 175 Tamb (ºC) (1) FR4 PCB, 4-layer copper, 1 cm2 (2) FR4 PCB, single-sided copper, 1 cm2 (3) FR4 PCB, 4-layer copper, standard footprint (4) FR4 PCB, single sided copper, standard footprint Fig 2. PDTB113_123_143_114EQA_SER Product data sheet Power derating curves All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 4 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 6. Thermal characteristics Table 7. Thermal characteristics Symbol Parameter Conditions thermal resistance from junction to ambient Rth(j-a) in free air Min Typ Max Unit [1] - - 385 K/W [2] - - 218 K/W [3] - - 239 K/W [4] - - 133 K/W - - 40 K/W thermal resistance from junction to solder point Rth(j-sp) [1] Device mounted on an FR4 Printed-Circuit Board (PCB), single-sided copper, tin-plated and standard footprint. [2] Device mounted on an FR4 PCB, single-sided copper, tin-plated; mounting pad for collector 1 cm2. [3] Device mounted on an FR4 PCB, 4-layer copper, tin-plated and standard footprint. [4] Device mounted on an FR4 PCB, 4-layer copper, tin-plated; mounting pad for collector 1 cm2. aaa-020278 103 duty cycle = 1 Zth(j-a) (K/W) 0.75 0.5 0.33 102 0.2 0.1 0.05 10 0.02 0.01 0 1 10-5 10-4 10-3 10-2 10-1 1 10 102 103 tp (s) FR4 PCB, single-sided copper, tin-plated and standard footprint. Fig 3. Transient thermal impedance from junction to ambient as a function of pulse duration; typical values PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 5 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020279 103 Zth(j-a) (K/W) duty cycle = 1 0.75 102 0.5 0.33 0.2 0.1 0.05 10 0.02 0.01 0 1 10-5 10-4 10-3 10-2 10-1 1 10 102 103 tp (s) FR4 PCB, single-sided copper, tin-plated, mounting pad for collector 1 cm2. Fig 4. Transient thermal impedance from junction to ambient as a function of pulse duration; typical values aaa-020281 103 Zth(j-a) (K/W) duty cycle = 1 0.75 102 0.5 0.33 0.2 0.1 0.05 10 0.02 0.01 0 1 10-5 10-4 10-3 10-2 10-1 1 10 102 103 tp (s) FR4 PCB, 4-layer copper, tin-plated and standard footprint. Fig 5. Transient thermal impedance from junction to ambient as a function of pulse duration; typical values PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 6 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020280 103 Zth(j-a) (K/W) duty cycle = 1 102 0.75 0.5 0.33 0.2 0.1 10 0.05 0.02 0.01 0 1 10-5 10-4 10-3 10-2 10-1 1 10 102 103 tp (s) FR4 PCB, 4-layer copper, tin-plated; mounting pad for collector 1 cm2 Fig 6. Transient thermal impedance from junction to ambient as a function of pulse duration; typical values PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 7 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 7. Characteristics Table 8. Characteristics Tamb = 25 C unless otherwise specified. Symbol Parameter Conditions Min Typ Max Unit ICBO collector-base cut-off current VCB = 50 V; IE = 0 A - - 100 nA ICEO collector-emitter cut-off VCE = 50 V; IB = 0 A current - - 0.5 A IEBO emitter-base cut-off current - - 4 mA PDTB123EQA - - 2 mA PDTB143EQA - - 0.9 mA PDTB114EQA - - 0.4 mA 33 - - PDTB123EQA 40 - - PDTB143EQA 60 - - PDTB113EQA VEB = 5 V; IC = 0 A DC current gain hFE PDTB113EQA VCE = 5 V; IC = 50 mA PDTB114EQA VCEsat collector-emitter saturation voltage VI(off) off-state input voltage - - - - 100 mV VCE = 5 V; IC = 100 A 0.6 1.05 1.5 V PDTB123EQA 0.6 1.05 1.8 V PDTB143EQA 0.6 1.05 1.5 V PDTB114EQA 0.6 1.05 1.5 V 1 1.45 1.8 V PDTB123EQA 1 1.5 2 V PDTB143EQA 1 1.7 2.2 V 1 2.2 3 V PDTB113EQA 0.7 1 1.3 k PDTB123EQA 1.54 2.2 2.86 k PDTB143EQA 3.3 4.7 6.1 k k PDTB113EQA VI(on) 70 IC = 50 mA; IB = 2.5 mA on-state input voltage PDTB113EQA VCE = 0.3 V; IC = 20 mA PDTB114EQA R1 [1] bias resistor 1 (input) PDTB114EQA R2/R1 bias resistor ratio Cc collector capacitance VCB = 10 V; IE = ie = 0 A; f = 1 MHz fT transition frequency VCE = 5 V; IC = 50 mA; f = 100 MHz [1] See section test information for resistor calculation and test conditions. [2] Characteristics of built-in transistor. PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 7 10 13 [1] 0.9 1 1.1 - 7 - pF [2] - 150 - MHz © Nexperia B.V. 2017. All rights reserved 8 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020282 103 (2) -0.4 (3) 102 IB (mA) = -3.6 IC (A) (1) hFE aaa-020283 -0.5 -3.24 -2.88 -2.52 -0.3 -2.16 10 -1.8 -0.2 -1.44 1 -0.1 10-1 -10-1 -1 -10 -102 -1.08 -0.72 0 -103 0 -1 -2 -3 -4 IC (mA) -5 VCE (V) VCE = 5 V Tamb = 25 C (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 7. PDTB113EQA: DC current gain as a function of collector current; typical values aaa-020285 -10 VI(on) (V) Fig 8. PDTB113EQA: Collector current as a function of collector-emitter voltage; typical values aaa-020286 -10 VI(off) (V) (1) -1 -1 (1) (2) (2) (3) (3) -10-1 -10-1 -1 -10 -102 -103 -10-1 -10-1 IC (mA) VCE = 0.3 V VCE = 5 V (1) Tamb = 40 C (2) Tamb = 25 C (2) Tamb = 25 C (3) Tamb = 100 C (3) Tamb = 100 C PDTB113EQA: On-state input voltage as a function of collector current; typical values PDTB113_123_143_114EQA_SER Product data sheet -10 IC (mA) (1) Tamb = 40 C Fig 9. -1 Fig 10. PDTB113EQA: Off-state input voltage as a function of collector current; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 9 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020284 -10-1 aaa-020287 35 30 Cc (pF) 25 VCEsat (V) (1) (2) 20 (3) 15 10 5 -10-2 -10 -102 -103 0 -0 -10 -20 -30 -40 -50 VCB (V) IC (mA) f = 1 MHz; Tamb = 25 C IC/IB = 20 (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 11. PDTB113EQA: Collector-emitter saturation voltage as a function of collector current; typical values PDTB113_123_143_114EQA_SER Product data sheet Fig 12. PDTB113EQA: Collector capacitance as a function of collector-base voltage; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 10 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020288 103 (1) hFE IB (mA) = -3.47 IC (A) (2) -3.14 -2.81 -0.4 (3) 102 aaa-020289 -0.5 -2.48 -2.15 -0.3 -1.82 10 -1.49 -0.2 -1.16 1 -0.83 -0.1 -0.5 10-1 -10-1 -1 -10 -102 -103 0 0 -1 -2 -3 -4 IC (mA) -5 VCE (V) VCE = 5 V Tamb = 25 C (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 13. PDTB123EQA: DC current gain as a function of collector current; typical values aaa-020291 -10 VI(on) (V) Fig 14. PDTB123EQA: Collector current as a function of collector-emitter voltage; typical values aaa-020292 -10 VI(off) (V) (1) -1 -1 (1) (2) (3) -10-1 -10-1 -1 -10 -102 (2) (3) -103 -10-1 -10-1 IC (mA) VCE = 0.3 V VCE = 5 V (1) Tamb = 40 C (2) Tamb = 25 C (2) Tamb = 25 C (3) Tamb = 100 C (3) Tamb = 100 C Fig 15. PDTB123EQA: On-state input voltage as a function of collector current; typical values Product data sheet -10 IC (mA) (1) Tamb = 40 C PDTB113_123_143_114EQA_SER -1 Fig 16. PDTB123EQA: Off-state input voltage as a function of collector current; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 11 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020290 -10-1 aaa-020293 30 Cc (pF) 25 VCEsat (V) 20 (1) (2) (3) 15 10 5 -10-2 -10 -102 -103 0 -0 -10 -20 -30 -40 -50 VCB (V) IC (mA) f = 1 MHz; Tamb = 25 C IC/IB = 20 (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 17. PDTB123EQA: Collector-emitter saturation voltage as a function of collector current; typical values PDTB113_123_143_114EQA_SER Product data sheet Fig 18. PDTB123EQA: Collector capacitance as a function of collector-base voltage; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 12 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020294 103 aaa-020295 -0.5 IB (mA) = -2.8 IC (A) hFE -0.4 -2.52 -2.24 -1.96 102 (1) (2) (3) -1.68 -0.3 -1.4 -1.12 -0.2 10 -0.84 -0.1 -0.56 -0.28 1 -10-1 -1 -102 -10 -103 0 0 -1 -2 -3 -4 IC (mA) -5 VCE (V) VCE = 5 V Tamb = 25 C (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 19. PDTB143EQA: DC current gain as a function of collector current; typical values aaa-020298 -102 VI(on) (V) Fig 20. PDTB143EQA: Collector current as a function of collector-emitter voltage; typical values aaa-020296 -10 VI(off) (V) -10 (1) -1 (2) (3) (1) (2) (3) -1 -10-1 -10-1 -1 -10 -102 -103 -104 IC (mA) VCE = 0.3 V -10-1 -10-1 VCE = 5 V (1) Tamb = 40 C (2) Tamb = 25 C (2) Tamb = 25 C (3) Tamb = 100 C (3) Tamb = 100 C Fig 21. PDTB143EQA: On-state input voltage as a function of collector current; typical values Product data sheet -10 IC (mA) (1) Tamb = 40 C PDTB113_123_143_114EQA_SER -1 Fig 22. PDTB143EQA: Off-state input voltage as a function of collector current; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 13 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020297 -10-1 aaa-020299 20 Cc (pF) 16 VCEsat (V) 12 (1) (2) 8 (3) 4 -10-2 -1 -10 -102 -103 0 0 -10 -20 -30 -40 -50 VCB (V) IC (mA) f = 1 MHz; Tamb = 25 C IC/IB = 20 (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 23. PDTB143EQA: Collector-emitter saturation voltage as a function of collector current; typical values PDTB113_123_143_114EQA_SER Product data sheet Fig 24. PDTB143EQA: Collector capacitance as a function of collector-base voltage; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 14 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020300 103 aaa-020301 -0.5 IB (mA) = -3.4 IC (A) hFE -3.05 -2.7 -0.4 -2.35 102 -2 -0.3 (1) (2) (3) -1.65 -1.3 -0.2 -0.95 10 -0.6 -0.1 -0.25 1 -10-1 -1 -10 -102 -103 0 0 -1 -2 -3 -4 IC (mA) -5 VCE (V) VCE = 5 V Tamb = 25 C (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 25. PDTB114EQA: DC current gain as a function of collector current; typical values aaa-020302 -102 VI(on) (V) Fig 26. PDTB114EQA: Collector current as a function of collector-emitter voltage; typical values aaa-020303 -10 VI(off) (V) -10 (1) -1 (2) (3) -1 (1) (2) (3) -10-1 -10-1 -1 -10 -102 -103 -10-1 -10-1 IC (mA) VCE = 0.3 V VCE = 5 V (1) Tamb = 40 C (2) Tamb = 25 C (2) Tamb = 25 C (3) Tamb = 100 C (3) Tamb = 100 C Fig 27. PDTB114EQA: On-state input voltage as a function of collector current; typical values Product data sheet -10 IC (mA) (1) Tamb = 40 C PDTB113_123_143_114EQA_SER -1 Fig 28. PDTB114EQA: Off-state input voltage as a function of collector current; typical values All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 15 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors aaa-020304 -10-1 aaa-020305 10 Cc (pF) 8 VCEsat (V) 6 (1) 4 (2) (3) 2 -10-2 -1 -10 -102 0 -103 -0 -10 -20 -30 -40 -50 VCB (V) IC (mA) f = 1 MHz; Tamb = 25 C IC/IB = 20 (1) Tamb = 100 C (2) Tamb = 25 C (3) Tamb = 40 C Fig 29. PDTB114EQA: Collector-emitter saturation voltage as a function of collector current; typical values Fig 30. PDTB114EQA: Collector capacitance as a function of collector-base voltage; typical values aaa-020306 103 fT (MHz) 102 10 -10-1 -1 -10 -102 -103 IC (mA) VCE = 5 V; f = 100 MHz; Tamb = 25 °C Fig 31. Transition frequency as a function of collector current; typical values of built-in transistor PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 16 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 8. Test information 8.1 Quality information This product has been qualified in accordance with the Automotive Electronics Council (AEC) standard Q101 - Stress test qualification for discrete semiconductors, and is suitable for use in automotive applications. 8.2 Resistor calculation • Calculation of bias resistor 1 (R1): V  I I2  – V  I I1  R1 = ----------------------------------I I2 – I I1 • Calculation method A of bias resistor ratio (R2/R1): R2 = V  I I3  – 1 -----------------------R1 R1  I 13 • Calculation method B of bias resistor ratio (R2/R1): V  I I4  – V  I I3  R2 -–1 ------- = ----------------------------------R1 R1   I I4 – I 13  n.c. II1; II2 R1 II3; II4 R2 GND aaa-020083 Fig 32. Resistor test circuit PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 17 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 8.3 Resistor test conditions Table 9. Resistor test conditions Type number R1 R2 Test conditions k k II1 II2 II3 II4 PDTB113EQA [1] 1 1 1.5 mA 1.9 mA 2.20 mA - PDTB123EQA [1] 2.2 2.2 0.7 mA 0.8 mA 0.75 mA - PDTB143EQA [2] 4.7 4.7 1.3 mA 1.5 mA 1.05 mA 1.25 mA PDTB114EQA [2] 10 10 0.7 mA 0.8 mA 0.45 mA 0.55 mA [1] Uses calculation method A of bias resistor ratio R2/R1 [2] Uses calculation method B of bias resistor ratio R2/R1 9. Package outline 0.87 0.95 0.75 1 0.95 1.05 2 0.34 0.40 Dimensions in mm 0.17 0.25 0.16 0.24 0.1 3 0.04 max 0.22 0.30 0.245 0.325 0.195 0.275 1.05 1.15 13-03-05 Fig 33. Package outline DFN1010D-3 (SOT1215) PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 18 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 10. Soldering Footprint information for reflow soldering of DFN1010D-3 package SOT1215 1.2 0.45 (2x) 0.3 1.1 0.35 (2x) 0.4 0.25 (2x) 0.75 0.3 0.5 1.5 1.4 0.4 0.5 0.4 0.3 0.5 1.3 0.4 0.3 0.4 0.5 1.3 solder land solder land plus solder paste occupied area solder resist Dimensions in mm Issue date 12-11-23 13-03-06 sot1215_fr Fig 34. Reflow soldering footprint DFN1010D-3 (SOT1215) PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 19 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 11. Revision history Table 10. Revision history Document ID Release date Data sheet status Change notice Supersedes PDTB113_123_143_114EQA_SER v.1 20160330 Product data sheet - PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 - © Nexperia B.V. 2017. All rights reserved 20 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors 12. Legal information 12.1 Data sheet status Document status[1][2] Product status[3] Definition Objective [short] data sheet Development This document contains data from the objective specification for product development. Preliminary [short] data sheet Qualification This document contains data from the preliminary specification. Product [short] data sheet Production This document contains the product specification. [1] Please consult the most recently issued document before initiating or completing a design. [2] The term ‘short data sheet’ is explained in section “Definitions”. [3] The product status of device(s) described in this document may have changed since this document was published and may differ in case of multiple devices. The latest product status information is available on the Internet at URL http://www.nexperia.com. 12.2 Definitions Draft — The document is a draft version only. The content is still under internal review and subject to formal approval, which may result in modifications or additions. Nexperia does not give any representations or warranties as to the accuracy or completeness of information included herein and shall have no liability for the consequences of use of such information. Short data sheet — A short data sheet is an extract from a full data sheet with the same product type number(s) and title. A short data sheet is intended for quick reference only and should not be relied upon to contain detailed and full information. For detailed and full information see the relevant full data sheet, which is available on request via the local Nexperia sales office. In case of any inconsistency or conflict with the short data sheet, the full data sheet shall prevail. Product specification — The information and data provided in a Product data sheet shall define the specification of the product as agreed between Nexperia and its customer, unless Nexperia and customer have explicitly agreed otherwise in writing. In no event however, shall an agreement be valid in which the Nexperia product is deemed to offer functions and qualities beyond those described in the Product data sheet. 12.3 Disclaimers Limited warranty and liability — Information in this document is believed to be accurate and reliable. However, Nexperia does not give any representations or warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the consequences of use of such information. Nexperia takes no responsibility for the content in this document if provided by an information source outside of Nexperia. In no event shall Nexperia be liable for any indirect, incidental, punitive, special or consequential damages (including - without limitation - lost profits, lost savings, business interruption, costs related to the removal or replacement of any products or rework charges) whether or not such damages are based on tort (including negligence), warranty, breach of contract or any other legal theory. Notwithstanding any damages that customer might incur for any reason whatsoever, Nexperia's aggregate and cumulative liability towards customer for the products described herein shall be limited in accordance with the Terms and conditions of commercial sale of Nexperia. Right to make changes — Nexperia reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. This document supersedes and replaces all information supplied prior to the publication hereof. PDTB113_123_143_114EQA_SER Product data sheet Suitability for use in automotive applications — This Nexperia product has been qualified for use in automotive applications. Unless otherwise agreed in writing, the product is not designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical systems or equipment, nor in applications where failure or malfunction of an Nexperia product can reasonably be expected to result in personal injury, death or severe property or environmental damage. Nexperia and its suppliers accept no liability for inclusion and/or use of Nexperia products in such equipment or applications and therefore such inclusion and/or use is at the customer's own risk. Applications — Applications that are described herein for any of these products are for illustrative purposes only. Nexperia makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification. Customers are responsible for the design and operation of their applications and products using Nexperia products, and Nexperia accepts no liability for any assistance with applications or customer product design. It is customer’s sole responsibility to determine whether the Nexperia product is suitable and fit for the customer’s applications and products planned, as well as for the planned application and use of customer’s third party customer(s). Customers should provide appropriate design and operating safeguards to minimize the risks associated with their applications and products. Nexperia does not accept any liability related to any default, damage, costs or problem which is based on any weakness or default in the customer’s applications or products, or the application or use by customer’s third party customer(s). Customer is responsible for doing all necessary testing for the customer’s applications and products using Nexperia products in order to avoid a default of the applications and the products or of the application or use by customer’s third party customer(s). Nexperia does not accept any liability in this respect. Limiting values — Stress above one or more limiting values (as defined in the Absolute Maximum Ratings System of IEC 60134) will cause permanent damage to the device. Limiting values are stress ratings only and (proper) operation of the device at these or any other conditions above those given in the Recommended operating conditions section (if present) or the Characteristics sections of this document is not warranted. Constant or repeated exposure to limiting values will permanently and irreversibly affect the quality and reliability of the device. Terms and conditions of commercial sale — Nexperia products are sold subject to the general terms and conditions of commercial sale, as published at http://www.nexperia.com/profile/terms, unless otherwise agreed in a valid written individual agreement. In case an individual agreement is concluded only the terms and conditions of the respective agreement shall apply. Nexperia hereby expressly objects to applying the customer’s general terms and conditions with regard to the purchase of Nexperia products by customer. All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 21 of 23 PDTB113/123/143/114EQA Nexperia 50 V, 500 mA PNP resistor-equipped transistors No offer to sell or license — Nothing in this document may be interpreted or construed as an offer to sell products that is open for acceptance or the grant, conveyance or implication of any license under any copyrights, patents or other industrial or intellectual property rights. Translations — A non-English (translated) version of a document is for reference only. The English version shall prevail in case of any discrepancy between the translated and English versions. Export control — This document as well as the item(s) described herein may be subject to export control regulations. Export might require a prior authorization from competent authorities. 12.4 Trademarks Quick reference data — The Quick reference data is an extract of the product data given in the Limiting values and Characteristics sections of this document, and as such is not complete, exhaustive or legally binding. Notice: All referenced brands, product names, service names and trademarks are the property of their respective owners. 13. Contact information For more information, please visit: http://www.nexperia.com For sales office addresses, please send an email to: salesaddresses@nexperia.com PDTB113_123_143_114EQA_SER Product data sheet All information provided in this document is subject to legal disclaimers. Rev. 1 — 30 March 2016 © Nexperia B.V. 2017. All rights reserved 22 of 23 Nexperia PDTB113/123/143/114EQA 50 V, 500 mA PNP resistor-equipped transistors 14. Contents 1 1.1 1.2 1.3 1.4 2 3 4 4.1 5 6 7 8 8.1 8.2 8.3 9 10 11 12 12.1 12.2 12.3 12.4 13 14 © Product profile . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General description . . . . . . . . . . . . . . . . . . . . . 1 Features and benefits . . . . . . . . . . . . . . . . . . . . 1 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Quick reference data . . . . . . . . . . . . . . . . . . . . 1 Pinning information . . . . . . . . . . . . . . . . . . . . . . 2 Ordering information . . . . . . . . . . . . . . . . . . . . . 2 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Binary marking code description. . . . . . . . . . . . 3 Limiting values. . . . . . . . . . . . . . . . . . . . . . . . . . 3 Thermal characteristics . . . . . . . . . . . . . . . . . . 5 Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Test information . . . . . . . . . . . . . . . . . . . . . . . . 16 Quality information . . . . . . . . . . . . . . . . . . . . . 16 Resistor calculation . . . . . . . . . . . . . . . . . . . . 16 Resistor test conditions . . . . . . . . . . . . . . . . . 16 Package outline . . . . . . . . . . . . . . . . . . . . . . . . 16 Soldering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Revision history . . . . . . . . . . . . . . . . . . . . . . . . 18 Legal information. . . . . . . . . . . . . . . . . . . . . . . 19 Data sheet status . . . . . . . . . . . . . . . . . . . . . . 19 Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Disclaimers . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Contact information. . . . . . . . . . . . . . . . . . . . . 20 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Nexperia B.V. 2017. All rights reserved For more information, please visit: http://www.nexperia.com For sales office addresses, please send an email to: salesaddresses@nexperia.com Date of release: 30 March 2016
