SUB-DBAF-107A-092

1 3 2 5 Dim D Dim C± 0.38 Dim B± 0.25 Dim A± 0.13 4 7 6 C MATERIAL AND FINISH Insulator:PBT+30%G.F(UL94V-0) Contact:Copper Alloy Nickel Undercoated Selective Gold Plated Finish:Metal Iron With Tin Plated Dim E D SPECIFICATIONS: Current rating:3.0A AC/DC Voltage rating:250V AC/DC Contact resistance:30m ohm MAX Insulation resistance:5000M ohm MIN Withstanding voltage:1000V AC for one minute Operating temperature range:-40° C~+85° C E 1# 2.84 XX# 10° ±1 ° 3.2 0.9 11.0 15.3± 0.3 6.0 2.77 E D C Ordering Information X RoHS Number of contacts Code Definition Blank Non-RoHS R B SUB Code Definition RoHS A 9 PIN B 15 PIN C 25 PIN E Housing Type Code Definition DBXX Mounting Options Contacts Material Definition Code 1 M Male 2 F Female 3 37 PIN 4 1 TYPE 2 TYPE 3 TYPE X0 XX RIVETED W/ SHIELD ONLY Code Definition RIVETED W/ FRONT RIVET RIVETED W/ REAR RIVET RIVETED W/ FRONT RIVET REAR RIVET XX0 Contact Plated Code Contact Area Insulator material Insulator color Code Definition Code Definition 2 Brass A Gold 1u"/Light Tin 0 PBT 0 Black 7 Phosphor bronze B Gold 3u"/Light Tin 2 NYLON 6 Blue C Gold 5u"/Light Tin 9 White E Gold 15u"/Light Tin B 4 TYPE 深圳市君灏精密工业有限公司 ShenZhen JunHao Exactitude Industry CO.,LTD A RIVETED W/ SHIELD ONLY RIVETED W/ FRONT RIVET RIVETED W/ REAR RIVET RIVETED W/ FRONT RIVET REAR RIVET Mounting Options PART. NAME: D型XX芯焊线式PCB焊接插座（针） TITLE: PART. NO.: SUB-DBAF-107A-092 DWG NAME: APPROVED BY CHECkED BY Jonnson Jeff 1 2 3 4 5 DESIGNED BY DRAWN BY A CUSTOM NO.: UNITS: mm SCALE: REVISION: allan 6 7 Toleance x. ± 0.50 x.x ± 0.30 x.xx ± 0.10 xx° ± 1°
