ELECTRONICS
Positive
Thermal
Coefficent
RL06 Series
Circuit Protection
System
Specifications are subject to change without notice.
Positive Thermal Coefficent - RL06 Series
Features
1. I(hold): 075~300mA
2. 6V Operating voltages
3. Radial leaded devices.
4. Very high voltage surge capabilities.
5. Available in lead-free version.
6. Fast time–to–trip
7. RoHS compliant, Lead- Free and Halogen-Free
Applications
1. Overcurrent and overtemperature protection of automotive electronics
2. Hard disk drives
3. PC motherboards
4. PC peripherals
5. Point-of-sale (POS) equipment
6. PCMCIA cards
7. USB port protection - USB 2.0, 3.0 & OTG
8. HDMI 1.4 Source protection
9. Computers&peripherals
Product Name
R
L
0
LOGO
Circuit Protection
System
6
Vmax:6V
-
0
7
5
Ihold:0.75A
Specifications are subject to change without notice.
Page:1
Positive Thermal Coefficent - RL06 Series
Dimension
E
D
E
E
D
Fig.1
Fig.2
Package Dimensions
(mm)
Ihold
Vmax
Itrip
Imax
Rmax
Rmin
Pdtyp
A
V
A
A
Ω
Ω
W
A
B
C
D
E
0.75
6
1.3
40
0.5
E0.2
0.3
7.4
12.5
5.1
3
0.8
Type Number
RL06-075
D
Circuit
Figure
Fig.1
RL06-090
0.9 E
6
1.8
40
0.3
0.1
0.6
7.4
13.5
5.1
3
0.8
Fig.1
RL06-110
1.1
6
2.2
40
0.27
0.1
0.7
7.8
13
5.1
0.8
Fig.2
RL06-120
1.2
6
2.4
40
22
0.12
0.6
7.4
13.5
D 5.1
3
3
0.8
Fig.1
RL06-135
1.35
6
2.7
40
0.18
0.07
0.8
7.4
13.5
5.1
3
0.8
Fig.1
RL06-155
1.55
6
3.1
40
0.16
0.06
0.8
7.4
13.5
5.1
3
0.8
Fig.1
RL06-160
1.6
6
3.2
40
0.16
0.05
0.9
7.8
16
5.1
3
0.8
Fig.2
RL06-185
1.85
6
3.7
40
0.13
0.04
1
7.8
16
5.1
3
0.8
Fig.2
RL06-200
2.0
6
4
40
0.155
0.18
1
8.8
16
5.1
3
0.8
Fig.2
RL06-250
2.5
6
5
40
0.08
0.02
1.2
10
16
5.1
3
0.8
Fig.2
RL06-300
3
6
6
40
0.07
0.02
E
1.2
10
16.5
5.1
3
0.8
Fig.2
E
I hold = Hold current: maximum
current device will pass without tripping in 20°C still air.
V max = Maximum operating voltage device can withstand without damage at rated current (Imax).
R min/max = Minimum/Maximum device resistance prior to tripping at 25°C.
I max = Maximum fault current device can withstand without damage at rated voltage (V max).
I trip = Trip current: minimum current at which the device will trip in 20°C still air.
D state.
R typ = Typical resistance of device in initial (un-soldered)
E
E
D
Circuit Protection
System
Specifications are subject to change without notice.
Page:2
Positive Thermal Coefficent - RL06 Series
0.75A
1.20A
1.55A
0.90A
1.10A
1.35A
1.60A
1.85A
2.50A
Average Time Current Curves
Temperature Rerating Curve
USBR
100
Percentage of Rated Current
170%
Time in Seconds
10
1
0.1
150% B
130%
A
110%
90%
Line/Part Number:
70%
A
06-075
06-120
50%
30%
0.01
B
06-160
06-185
06-250
A
B
10%
-40
0.001
06-090
06-110
06-135
1
10
100
Current in Amperes
-30 -20
-10
0
10
20 30
40 50
Temperature (°C)
60
70
80 85
1000
Soldering Parameters
Soldering
Temperature (°C)
260
Cooling
220
190
160
Pre-Heating
Zone
Soldering Zone
Preheating
0
60 min.
Cooling Zone
5 max.
Time(s)
Physical Specifications
Refer to the condition recommended by the flux
manufacturer.Max.remping rate should not
exceed 4°C/Sec.
Max.solder temperature should not exceed
260°C
Cooling by natural convection in air.
Environmental Specifications
Operating/Storage
Temperature
-40°Cto+85°C
Maximum Device Surface
Temperature in Tripped State
125°C
Passive Aging
+85°C, 1000 hours
-/+5% typical resistance change
Lead Material
90-2.50A:Tin-plated Copper clad steel
75A:Tin-plated Copper
Humidity Aging
+85°C, 85% R.H, 1000 hours
-/+5% typical resistance change
Soldering
Characteristics
Solderability per MIL-STD-202,Method 208E
Thermal Shock
+85°C to -40°C R.H, 10 times
-/+5% typical resistance change
Insulating Material
Cured,flame retardant epoxy polymer meets UL
94V-0 requirements.
Solvent Resistance
Device Labeling
Marked with 'LF',voitage,current rating,and date
code.
Moisture Sensivitivy Level
Circuit Protection
System
MIL-STD-202, Method 215F
Level 1, J-STD-020C
Specifications are subject to change without notice.
Page:3
Positive Thermal Coefficent - RL06 Series
THERMAL DERATING CHART - IH(A)
Type Number
-40°C
-20°C
0°C
23°C
30°C
40°C
50°C
60°C
70°C
85°C
RL06-075
1.05
0.98
0.86
0.75
0.68
0.62
0.58
0.51
0.46
0.39
RL06-090
1.31
1.17
1.04
0.90
0.82
0.75
0.69
0.61
0.55
0.47
RL06-110
1.60
1.43
0.27
1.10
1.00
0.91
0.85
0.75
0.67
0.57
RL06-120
1.69
1.56
1.38
1.20
1.09
1.00
0.92
0.82
0.73
0.62
RL06-135
1.96
1.76
1.55
1.35
1.23
1.12
1.04
0.92
0.82
0.70
RL06-155
2.17
2.02
1.78
1.55
1.41
1.29
1.19
1.05
0.95
0.81
RL06-160
2.32
2.08
1.84
1.60
1.46
1.33
1.23
1.09
0.98
0.83
RL06-185
2.68
2.41
2.13
1.85
1.68
1.54
1.42
1.26
1.13
0.96
RL06-200
2.90
2.60
2.30
2.00
1.82
1.66
1.54
1.36
1.22
1.04
RL06-250
3.63
3.25
2.88
2.50
2.87
2.08
1.93
1.70
1.53
1.30
RL06-300
4.25
3.90
3.45
3.00
2.73
2.49
2.31
2.04
1.83
1.56
Warehouse Storage Conditions of Products
· Storage Conditions:
1. Storage Temperature: -10°C~+40°C
2. Relative Humidity:≤75%RH
3. Keep away from corrosive atmosphere and sunlight.
· Period of Storage: 1 year
Circuit Protection
System
Specifications are subject to change without notice.
Page:4
RuiLongYuan Electronics Co., Ltd.
· Reproducing and modifying information of the document is prohibited without permission from
Ruilongyuan International Inc.
· Ruilongyuan International Inc. reserves the rights to make changes of the content herein the document anytime
without notification. Please refer to our website for the latest document.
· Ruilongyuan International Inc. disclaims any and all liability arising out of the application or use of any product
including damages incidentally and consequentially occurred.
· Ruilongyuan International Inc. does not assume any and all implied warranties, including warranties of fitness
for particular purpose, non-infringement and merchantability.
· Applications shown on the herein document are examples of standard use and operation. Customers are responsible
in comprehending the suitable use in particular applications.Ruilongyuan International Inc. makes no representation or
warranty that such applications will be suitable for the specifed use without further testing or modifcation.
· The products shown herein are not designed and authorized for equipments requiring high level of reliability or relating to
human life and for any applications concerning life-saving or life-sustaining, such as medical instruments, transportation
equipment,aerospace machinery et cetera. Customers using or selling these products for use in such applications do so at
their own risk and agree to fullyindemnify Ruilongyuan International Inc. for any damages resulting from such improper use or
sale.
Circuit Protection
System
Specifications are subject to change without notice.
Page:5
