ELECTRONICS
TVS/ESD
Arrays
RLSD52Axx1V Series
Circuit Protection
System
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
TVS/ESD Arrays - RLSD52Axx1V Series
Features
• 100 Watts Peak Pulse Power per Line (tp = 8/20μs)
• Working voltages: 3.3V、5V、8V、12V、15V、
24V、36V
• Low Leakage Current
• Low operating and clamping voltages
• Lead Free/RoHS compliant
• Solid-state silicon avalanche technology
• Provides ESD protection to IEC61000-4-2(ESD):
±15kV (air discharge)
±8kV (contact discharge);
Mechanical Characteristics
Pinout and Functional Block Diagram
• SOD-523 package
• Molding compound flammability rating: UL 94V-0
• Packaging: Tape and Reel per EIA 481
• Quantity Per Reel : 3,000pcs
• Lead Finish: Matte tin
• RoHS Compliant
1
Applications
• Cell Phone Handsets and Accessories
• Microprocesor based equipment
• Personal Digital Assistants (PDA’s)
• Notebooks, Desktops, and Servers
• Portable Instrumentation
• Pagers Peripherals
Circuit Protection
System
2
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
Page:1
TVS/ESD Arrays - RLSD52Axx1V Series
Absolute Maximum Rating
Rating
Symbol
Value
Units
Peak Pulse Power (tp =8/20μs)
PPK
100
Watts
ESD Voltage (Contact)
VESD
±8
Kv
ESD Voltage (Air)
VESD
±15
Kv
TL
260 (10 sec.)
°C
TJ
-55 to +125
°C
TSTG
-55 to +150
°C
Lead Soldering Temperature
Operating Temperature
Storage Temperature
Electrical Parameters (T=25°C)
ElectrIcal CharacterlstIcs Per Lin (@ 25°C Unless Otherwise Specified)
Reverse
Stand-Off
Voltage
Minimum
Breakdown
Voltage
Peak Pulse
Voltage
@8/20μS
Peak Pulse
Current
@8/20μS
Reverse
Leakage
@VRWM
VRWM
VBR@1mA
VC@1A
IPP
IR@VRWM
V
V
V
A
μA
pF
RLSD52A031V
3.3
4
6.5
14
200
200
RLSD52A051V
5
6
9
12
5
110
RLSD52A081V
8
8.5
13
10
5
70
RLSD52A121V
12
13.3
16.5
6
1
60
RLSD52A151V
15
16.6
21
5
1
50
RLSD52A241V
24
26.7
34.7
3
1
25
RLSD52A361V
36
40
62
2
1
25
Type Number
Circuit Protection
System
Typical
Capacitance
DC=0V
CJ@ 1 MHz
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
Page:2
TVS/ESD Arrays - RLSD52Axx1V Series
Typical Characteristics
Circuit Protection
System
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
Page:3
TVS/ESD Arrays - RLSD52Axx1V Series
Recommended Soldering Conditions
Profile Feature
Pb-Free Assembly
Average ramp-up rate (TL to TP)
3°C/second max.
Preheat
-Temperature Min (TS min)
-Temperature Max (TS max)
-Time (min to max) (ts)
TS max to TL
-Ramp-up Rate
Time maintained above:
-Temperature (TL)
-Time (tL)
150°C
200°C
60-180 seconds
3°C/second max.
217°C
60-150 seconds
Peak Temperature (TP)
260°C
Time within 5°C of actual Peak Temperature (tP)
Ramp-down Rate
Time 25°C to Peak Temperature
Circuit Protection
System
20-40 seconds
6°C/second max.
8 minutes max.
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
Page:4
TVS/ESD Arrays - RLSD52Axx1V Series
Package dimension SOD-523
F
E
Dimensions
B
A
G
F
B
E
C
0.80
(2X)
D
Inches
C Symbol
D
G
Millimeters
Min
Nom
Max
Min
Nom
Max
A
0.020
0.024
0.028
0.50
0.60
0.70
B
0.003
0.006
0.008
0.07
0.14
0.20
C
0.028
0.031
0.70
0.80
0.90
D
0.010
0.012
0.014
0.25
0.30
0.35
E
0.043
0.047
0.051
1.10
1.20
1.30
F
0.059
0.063
0.067
1.50
1.60
1.70
G
0.006
0.008
0.010
0.15
0.20
0.25
0.035
0.60
(2X)
Part Number Code
R
0.80
(2X)
L
S
D
1.1
5
2
A
0
5
1
V
1.9
LOGO
Package
SOD-523
Straight foot
overhanging
VRWM:5V
V= Unidirectional
C= Bidirectional
Protects 1
Lines
1.1
Ordering Information
1.9
Part Number
Package
Min. Order Qty.
RLSD52Axx1V
SOD-523
3000pcs
Circuit Protection
System
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
Page:5
RuiLongYuan Electronics Co., Ltd.
· Reproducing and modifying information of the document is prohibited without permission from
Ruilongyuan International Inc.
· Ruilongyuan International Inc. reserves the rights to make changes of the content herein the document anytime
without notification. Please refer to our website for the latest document.
· Ruilongyuan International Inc. disclaims any and all liability arising out of the application or use of any product
including damages incidentally and consequentially occurred.
· Ruilongyuan International Inc. does not assume any and all implied warranties, including warranties of fitness
for particular purpose, non-infringement and merchantability.
· Applications shown on the herein document are examples of standard use and operation. Customers are responsible
in comprehending the suitable use in particular applications.Ruilongyuan International Inc. makes no representation or
warranty that such applications will be suitable for the specifed use without further testing or modifcation.
· The products shown herein are not designed and authorized for equipments requiring high level of reliability or relating to
human life and for any applications concerning life-saving or life-sustaining, such as medical instruments, transportation
equipment,aerospace machinery et cetera. Customers using or selling these products for use in such applications do so at
their own risk and agree to fullyindemnify Ruilongyuan International Inc. for any damages resulting from such improper use or
sale.
Tel: +86-755-8290 8296
Circuit Protection
System
Fax: +86-755-8290 8002
E-mail: jack@ruilon.com
Specifications are subject to change without notice.
Please refer to http://www.ruilon.com.cn for current information.
Page:6
