RS8751XF

RS8751, RS8752, RS8754 250MHz, Rail-to-Rail Output CMOS Operational Amplifier FEATURES DESCRIPTION  HIGH GAIN BANDWIDTH:250MHz  RAIL-TO-RAIL OUTPUT  1.5mV Typical Vos  INPUT VOLTAGE RANGE: -0.2V to +3.9V with Vs = 5V  SUPPLY RANGE: +2.5V to +5.5V  SPECIFIED UP TO +125°C  MicroSIZE The RS875X families of voltage-feedback (VFB) products offer low voltage operation, negative-rail input, rail-to-rail output, as well as excellent speed/power consumption ratio, providing an excellent bandwidth (250MHz) and slew rate of 180V/us. The op-amps are unity gain stable and feature an ultra-low input bias current. PACKAGES: SOT23-5 These amplifiers set an industry-leading power-toperformance ratio for rail-to-rail amplifiers. The RS875X families of operational amplifiers are specified at the full temperature range of −40°C to +125°C under single or dual power supplies of 2.5V to 5.5V. APPLICATIONS  AUDIO ADC INPUT BUFFERS  PHOTODIODE PREAMP  HIGH-DENSITY SYSTEMS  PORTABLE SYSTEMS  DRIVING A/D CONVERTERS PIN CONFIGURATIONS RS8751 OUT 1 V- 2 +IN 3 RS8752 5 + - 4 V+ -IN RS8751B 1 V- 2 - IN 3 1 -IN 2 +IN 3 V- 4 8 NC 7 V+ 6 OUT 5 NC SOIC-8,MSOP-8 5 V+ 1 8 V+ -IN A 2 7 OUTB 6 -IN B 5 +IN B +IN A 3 V- 4 + A B+ SOIC-8,MSOP-8,TDFN-8,TSSOP-8 RS8754 OUT A 1 A D 14 OUT D -IN A 2 13 -IN D +IN A 3 12 +IN D V+ 4 11 V- +IN B 5 10 +IN C 9 -IN C 8 OUT C - + + - + + IN NC - SOT23-5 + RS8751 OUT A 4 OUT SOT23-5 Note: NC indicates no internal connection -IN B 6 OUT B 7 - + B + C SOIC-14,TSSOP-14 REV B.1 1 www.run-ic.com RS8751, RS8752, RS8754 ABSOLUTE MAXIMUM RATINGS (1) Supply Voltage, V+ to V-...............................................7.0V (2) Input Terminals, Voltage …………... – 0.5 to (V+) + 0.5V (2) Current …………………....…..... ±10mA Storage Temperature ……….…………… −65°C to +150°C Operating Temperature ……….………… −40°C to +125°C Junction Temperature................................................150°C Package Thermal Resistance @ TA = +25°C SOT23-5, SOT23-6………………….………………200°C/W MSOP-10, SOIC-8 ,TSSOP-8……….………….... 150°C/W SOIC-14, TSSOP-14………….……….……………100°C/W Lead Temperature (Soldering, 10s) ……………........260°C ESD Susceptibility HBM …......................................................................5000V MM ……………………….........………………...……….400V ESD SENSITIVITY CAUTION ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more susceptible to damage because very small parametric changes could cause the device not to meet its published specifications. (1) Stresses above these ratings may cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade device reliability. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those specified is not implied. (2) Input terminals are diode-clamped to the power-supply rails. Input signals that can swing more than 0.5V beyond the supply rails should be current-limited to 10mA or less. PACKAGE/ORDERING INFORMATION PRODUCT RS8751 RS8752 RS8754 ORDERING TEMPERATURE PACKAGE PACKAGE NUMBER RANGE LEAD MARKING RS8751XK -40℃~125℃ SOIC-8 RS8751 Tape and Reel,2500 RS8751XF -40℃~125℃ SOT23-5 8751 Tape and Reel,3000 RS8751BXF -40℃~125℃ SOT23-5 8751B Tape and Reel,3000 RS8751XM -40℃~125℃ MSOP-8 RS8751 Tape and Reel,3000 RS8752XK -40℃~125℃ SOIC-8 RS8752 Tape and Reel,2500 RS8752XM -40℃~125℃ MSOP-8 RS8752 Tape and Reel,3000 RS8752XT -40℃~125℃ TDFN-3x3-8L RS8752 Tape and Reel,3000 RS8752XQ -40℃~125℃ TSSOP-8 RS8752 Tape and Reel,3000 RS8754XP -40℃~125℃ SOIC -14 RS8754 Tape and Reel,2500 RS8754XQ -40℃~125℃ TSSOP-14 RS8754 Tape and Reel,3000 2 PACKAGE OPTION www.run-ic.com RS8751, RS8752, RS8754 ELECTRICAL CHARACTERISTICS (At TA = +25℃, VS = 5V, G = +2, RF = 1K Ω, and RL = 1KΩ connected to VS/2, VIN_CM =Vs/2, unless otherwise noted.) PARAMETER CONDITIONS RS8751,RS8752,RS8754 MIN TYP MAX UINTS 2.9 5.5 3.5 V mA POWER SUPPLY Vs IQ PSRR Operating Voltage Range Quiescent Current/Amplifier 2.5 Vs=2.5V to 5.5V, Vcm=(V-)+0.5V Power-Supply Rejection Ratio 70 90 dB INPUT Vos ΔVos/ΔT IB Ios Vcm CMRR Input Offset Voltage Input Offset Voltage Drift Input Bias Current Input Offset Current Common-Mode Voltage Range Common-Mode Rejection Ratio ±1.5 4 1 1 Vcm=Vs/2 Vcm=Vs/2, -40°C ≤ TA ≤125°C ±7.5 mV µV/°C 10 10 pA pA 3.9 V Vs= 5V -0.2 Vs= 5.5V, Vcm=-0.2V to 3.5V 66 85 dB Vs=5.0V,RL=1KΩ,Vo=Vs-0.2V 95 110 dB Vs=5.0V,RL=150Ω,Vo=Vs-0.3V 78 85 dB RL=1KΩ 23 85 125 mV mA mA VOUT=100mVpp,G=1 VOUT=100mVpp,G=2 VOUT=100mVpp,G=5 VOUT=100mVpp,G=10 250 130 33 15 180 250 62 MHz MHz MHz MHz V/us MHz ° f = 0.1 Hz to 10 Hz f = 1 MHz 13 8 nV/√Hz OUTPUT AOL Open-Loop Voltage Gain Iout Iout Output Swing From Rail Output Current Source Output Current Sink FREQUENCY RESPONSE Small-Signal Bandwidth SR GBP PM NOISE enp-p en Slew Rate Gain-Bandwidth Product Phase Margin Input Voltage Noise Input Voltage Noise Density 3 μVpp www.run-ic.com RS8751, RS8752, RS8754 TYPICAL CHARACTERISTICS At TA = +25℃, VS = 5V, G = +2, RF = 1K Ω, and RL = 1KΩ connected to VS/2, VIN_CM =Vs/2, unless otherwise noted Non-Inverting Small-Signal Frequency Response G=1, RF=24Ω 1 0 RL=1KΩ Normalized Gain (dB) Normalized Gain (dB) 2 -3dB_GW_Gain=1 -1 G=2 -2 -3 -4 G=5 -8 -7 G=10 -10 100K RL=150Ω -5 -6 1M 10M 100M -9 10M 1000M Frequency(Hz) Frequency Response for Various CL -3dB_GW_Gain=2 8 0 Normalized Gain (dB) Normalized Gain (dB) 1000M Frequency(Hz) Vs=5V 1 RL=10KΩ -1 -2 RL=50Ω -3 RL=150Ω -4 RL=1KΩ 6 CL=100P 4 2 CL=47P 0 -2 CL=6P -4 -6 -8 -5 1M 10M 100M 1M 1000M 10M 100M 1000M Frequency(Hz) Vs=5V G=2 RF=887 Frequency(Hz) AC Response Frequency Response for Various RL 2 0.4 0 Normalized Gain (dB) Normalized Gain (dB) 100M RL=10KΩ -2 -4 RL=1KΩ -6 RL=150Ω -8 -10 RL=50Ω -12 -14 10M 0.2 0 -0.2 -0.4 -0.6 100M 1000M 1M 10M 100M Temperature(℃) Vs=5V Frequency(Hz) Vs=5V G=2 RF=887 4 www.run-ic.com RS8751, RS8752, RS8754 TYPICAL CHARACTERISTICS At TA = +25℃, VS = 5V, G = +2, RF = 1K Ω, and RL = 1KΩ connected to VS/2, VIN_CM =Vs/2, unless otherwise noted SOURCE CURRENT vs TEMPERATURE SINK CURRENT vs TEMPERATURE 130 150 145 140 135 130 125 120 115 110 105 100 Sink Current(mA) Source Current(mA) 120 110 100 90 80 70 60 50 -40 -20 0 20 40 60 80 100 120 140 -40 -20 Temperature(℃) INPUT BIAS CURRENT vs TEMPERATURE 20 40 60 80 100 120 140 Temperature(℃) SMALL−SIGNAL STEP RESPONSE 10K 50mV/div 1K 100 10 1 0.1 -40 -20 0 20 40 60 10ns/div 80 100 120 140 Temperature(℃) POSITIVE OVERLOAD RECOVERY 200mV/div LARGE−SIGNAL STEP RESPONSE 0V VIN 1V/div VS=±2.5V G=-100 VOUT 0V 10ns/div 1V/div Input Bias Current(pA) 0 50ns/div 5 www.run-ic.com RS8751, RS8752, RS8754 TYPICAL CHARACTERISTICS At TA = +25℃, VS = 5V, G = +2, RF = 1K Ω, and RL = 1KΩ connected to VS/2, VIN_CM =Vs/2, unless otherwise noted NEGATIVE OVERLOAD RECOVERY VIN 0V 1V/div 0V Percentage of Amplifiers (%) 200mV/div 25 VS=±2.5V G=-100 VOUT 20 OFFSET VOLTAGE PRODUCTION DISTRIBUTION 14300 Samples 1 Production Lot VS = ±2.5V 15 10 5 0 50ns/div -4 -3 -2 -1 0 1 2 3 Offset Voltage (mV) 6 www.run-ic.com RS8751, RS8752, RS8754 APPLICATION NOTES The RS8751, RS8752, RS8754 are high precision, rail-to-rail operational amplifiers that can be run from a single-supply voltage 2.5V to 5.5V (±1.25V to ±2.75V). Supply voltages higher than 7V (absolute maximum) can permanently damage the amplifier. Rail-to-rail input and output swing significantly increases dynamic range, especially in low-supply applications. Good layout practice mandates use of a 0.1uF capacitor place closely across the supply pins. INSTRUMENTATION AMPLIFIER In the three-op amp, instrumentation amplifier configuration shown in Figure2, V1 RS875X RS875X VOUT LAYOUT GUIDELINS RS875X Attention to good layout practices is always recommended. Keep traces short. When possible, use a PCB ground plane with surface-mount components placed as close to the device pins as possible. Place a 0.1uF capacitor closely across the supply pins. These guidelines should be applied throughout the analog circuit to improve performance and provide benefits such as reducing the EMI susceptibility. V2 Figure2. Amplifier instrumentation amplifier +Vs 10uF 0.1uF Vin Vip Vout RS875X 10uF 0.1uF -Vs Figure1. Amplifier with Bypass Capacitors 7 www.run-ic.com RS8751, RS8752, RS8754 PACKAGE OUTLINE DIMENSIONS SOT23-5 D 1.90 b 2.59 E1 E 0.99 0.69 0.95 e e1 RECOMMENDED LAND PATTERN (Unit: mm) 0.2 A A2 L A1 Symbol c θ Dimensions In Millimeters Dimensions In Inches Min Max Min Max A 1.050 1.250 0.041 0.049 A1 0.000 0.100 0.000 0.004 A2 1.050 1.150 0.041 0.045 b 0.300 0.500 0.012 0.020 c 0.100 0.200 0.004 0.008 D 2.820 3.020 0.111 0.119 E 1.500 1.700 0.059 0.067 E1 2.650 2.950 0.104 0.116 e 0.950(BSC) 0.037(BSC) e1 1.800 2.000 0.071 0.079 L 0.300 0.600 0.012 0.024 θ 0° 8° 0° 8° 8 www.run-ic.com RS8751, RS8752, RS8754 MSOP-8 b e E E1 4.8 1.02 D 0.65 0.41 RECOMMENDED LAND PATTERN (Unit: mm) A2 c A A1 L Symbol Dimensions In Millimeters θ Dimensions In Inches Min Max Min Max A 0.820 1.100 0.032 0.043 A1 0.020 0.150 0.001 0.006 A2 0.750 0.950 0.030 0.037 b 0.250 0.380 0.010 0.015 c 0.090 0.230 0.004 0.009 D 2.900 3.100 0.114 0.122 e 0.650(BSC) 0.026(BSC) E 2.900 3.100 0.114 0.122 E1 4.750 5.050 0.187 0.199 L 0.400 0.800 0.016 0.031 θ 0° 6° 0° 6° 9 www.run-ic.com RS8751, RS8752, RS8754 TSSOP-8 e b 5.6 E1 E 1.78 D 0.65 0.42 RECOMMENDED LAND PATTERN (Unit: mm) A2 A1 Symbol H C A θ L Dimensions In Millimeters Min Max A Dimensions In Inches Min Max 1.200 0.047 A1 0.050 0.150 0.002 0.006 A2 0.800 1.050 0.031 0.041 b 0.190 0.300 0.007 0.012 c 0.090 0.200 0.004 0.008 D 2.900 3.100 0.114 0.122 E 4.300 4.500 0.169 0.177 E1 6.250 6.550 0.246 0.258 e L 0.650(BSC) 0.500 H θ 0.026(BSC) 0.700 0.020 0.25(TYP) 1° 0.028 0.01(TYP) 7° 10 1° 7° www.run-ic.com RS8751, RS8752, RS8754 TSSOP-14 e b 5.6 E1 E 1.78 D 0.65 0.42 RECOMMENDED LAND PATTERN (Unit: mm) A2 A1 Symbol H C A θ L Dimensions In Millimeters Min Max A Dimensions In Inches Min Max 1.200 0.047 A1 0.050 0.150 0.002 0.006 A2 0.800 1.050 0.031 0.041 b 0.190 0.300 0.007 0.012 c 0.090 0.200 0.004 0.008 D 4.860 5.100 0.191 0.201 E 4.300 4.500 0.169 0.177 E1 6.250 6.550 0.246 0.258 e L 0.650(BSC) 0.500 H θ 0.026(BSC) 0.700 0.020 0.25(TYP) 1° 0.028 0.01(TYP) 7° 11 1° 7° www.run-ic.com RS8751, RS8752, RS8754 SOIC-8 b e 5.2 E E1 2.2 D 1.27 0.6 RECOMMENDED LAND PATTERN (Unit: mm) A2 c A A1 L Symbol Dimensions In Millimeters θ Dimensions In Inches Min Max Min Max A 1.350 1.750 0.053 0.069 A1 0.100 0.250 0.004 0.010 A2 1.350 1.550 0.053 0.061 b 0.330 0.510 0.013 0.020 c 0.170 0.250 0.007 0.010 D 4.800 5.000 0.189 0.197 e 1.270(BSC) 0.050(BSC) E 5.800 6.200 0.228 0.244 E1 3.800 4.000 0.150 0.157 L 0.400 1.270 0.016 0.050 θ 0° 8° 0° 8° 12 www.run-ic.com RS8751, RS8752, RS8754 SOIC-14 e b 5.2 1.27 E E1 0.6 D 1.27 RECOMMENDED LAND PATTERN (Unit: mm) A2 A1 c A θ L Symbol Dimensions In Millimeters Dimensions In Inches Min Max Min Max A 1.350 1.750 0.053 0.069 A1 0.100 0.250 0.004 0.010 A2 1.350 1.550 0.053 0.061 b 0.310 0.510 0.012 0.020 c 0.100 0.250 0.004 0.010 D 8.450 8.850 0.333 0.348 e 1.270(BSC) 0.050(BSC) E 5.800 6.200 0.228 0.244 E1 3.800 4.000 0.150 0.157 L 0.400 1.270 0.016 0.050 θ 0° 8° 0° 8° 13 www.run-ic.com RS8751, RS8752, RS8754 TDFN-3x3-8L E b D E1 L e D1 BOTTOM VIEW A1 A2 A TOP VIEW SIDE VIEW Symbol Dimensions In Millimeters Dimensions In Inches Min Max Min Max A 0.700 0.800 0.028 0.031 A1 0.000 0.050 0.000 0.002 A2 0.203 0.008 b 0.300 0.400 0.012 0.016 D 2.900 3.100 0.114 0.122 D1 2.510 2.610 0.099 0.103 E 2.900 3.100 0.114 0.122 E1 1.550 1.650 0.061 0.065 e L 0.650 TYP 0.350 0.026 TYP 0.450 14 0.014 0.018 www.run-ic.com
