1SS184

山东晶导微电子股份有限公司 1SS184 Jingdao Microelectronics co.LTD SOT-23 Switching Diodes FEATURES • Low forward voltage :VF(3) = 0.9 V(Typ.) • Fast reverse recovery time:trr = 1.6 ns(Typ.) • Small Total Capacitance :CT = 0.9pF(Typ.) 3 3 1 MARKING: B3 2 1 2 Symbol Value Unit V RM 85 V DC Blocking Voltage VR 80 V Average Rectified Output Current IO 100 mA Peak forward surge current I FM 300 mA Power Dissipation PD 150 mW Junction Temperature TJ 125 ℃ T STG -55 ~ +150 ℃ B3 Maximum Ratings @Ta=25℃ Parameter Peak Reverse voltage Storage temperature range Electrical Characteristics @ Ta=25℃ Typ Parameter Symbol Reverse breakdown voltage VR I R =100μA VF1 I F =1 mA 0.6 V VF2 I F =10mA 0.72 V VF3 I F =100mA IR1 Forward voltage Test conditions Min Max Unit V 80 1.2 V V R =30V 0.1 uA IR2 V R =80V 0.5 uA Capacitance between terminals CT V R =0V, f=1MHz 0.9 3.0 pF Reverse recovery time t rr I F =10mA 1.6 4.0 ns Reverse voltage leakage current 2020.12 www.sdjingdao.com 0.9 Page 1 of 4 山东晶导微电子股份有限公司 1SS184 Jingdao Microelectronics co.LTD Fig.2 Reverse Characteristics 200 10 REVERSE CURRENT I R (uA) POWER DISSIPATION P D (mW) Fig.1 Power Derating Curve 150 100 50 0 0 25 50 75 100 125 150 1 T a =25°C 0.1 0.01 0.001 0 1000 5°C 100 =2 Ta FORWARD CURRENT I F (mA) Fig.3 Forward Characteristics 1 0.1 0.01 0.0 0.2 0.4 0.6 0.8 1.0 1.2 CAPACITANCE BETWEEN TERMINALS C T (pF) AMBIENT TEMPERATURE Ta(℃) 10 Fig.4 60 80 Capacitance Characteristics 1.6 T a =25°C f=1MHz 1.2 0.8 0.4 0 0 1 10 100 300 REVERSE VOLTAGE V R (V) FORWARD VOLTAGE V F (V) 2020.12 40 20 REVERSE VOLTAGE V R (V) www.sdjingdao.com Page 2 of 4 山东晶导微电子股份有限公司 1SS184 Jingdao Microelectronics co.LTD SOT-23 Package Outline Dimensions e ∠ALL ROUND D e A M e E C a L1 L HE SOT-23 mechanical data UNIT mm mil A C D E HE max 1.1 0.15 1.4 3.0 2.6 min 0.9 0.08 1.2 2.8 2.2 e M L L1 a ∠ 0.5 1.95 0.55 0.36 0.15 (ref) (ref) 0.3 1.7 0.0 12° max 43 6 55 118 102 20 77 min 35 3 47 110 12 67 87 22 14 (ref) (ref) 6 0.0 Marking The recommended mounting pad size 0.8 (0.031) Type number Marking code 1SS184 B3 0.9 (0.039) 0.95 (0.037) 0.95 (0.037) 2.0 (0.079) mm Unit ： (inches) 2020.12 201208 Page 3 of 4 山东晶导微电子股份有限公司 1SS184 Jingdao Microelectronics co.LTD SOT-23 Packing 1.The method of packaging and dimension are shown as below figure. (Dimension in mm) 7 inX8 mm Cover Tape 3,000 pcs per reel Carrier Tape SOT-23 220mm 8 reels per box 24,000 pcs per box 5 boxes per carton 120,000 pcs per carton 105 mm m mm m 210 5m 0m 18 55 180 mm SOT-23 Embossed Carrier Tape SOT-23 Tape Leader and Trailer 2020.12 Page 4 of 4
