MPIT5020-220M-LF

仕样书编号 NO.: QW-QA-345 REV1.2 CUSTOMER: DATE: 2018-09-15 纳入仕样书 SPECIFICATION 产 品 名 称 PRODUCT NAME: 贴片电感 贵 司 料 号 YOUR PART NO.:5020,10UH 敝 司 料 号 OUR PART NO.: MPIT5020-100M-LF 接受 RECEPTION THE SPECIFICATION HAS BEEN ACCEPTED. 该纳入仕样书已被我司接受 日期: DATE： 公司： COMPANY： 批准 审核 接收 CFMD CHKD RCVD 本纳入仕样书共 18 页 MANUFACTURING NAME 深圳市麦捷微电子科技股份有限公司 CFMD. CHKD. DSGD. 批准 审核 担当 罗盛滔 胡潞乐 曾艳锋 SHENZHEN MICROGATE TECHNOLOGY CO.， LTD. TEL：86-755-28085000 FAX：86-755-28085605 目录 CATALOG 规格书版本控制 Component SPEC Version Record……………………………….. .. .. 2 1 适用范围 Scope．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 3 2 品名构成 Product Identification．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 3 3 形状、尺寸和材料 Appearance, Dimensions and Material．．．．．．．．．．．．．．．．．．．．．． 3 4 测试条件 Testing Conditions．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 4 5 电气特性 Electrical Characteristics．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 4 6 工作条件 Condition of work．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 5 7 信赖性试验 Reliable Performance．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 8 焊接条件 Recommended Soldering Conditions．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 8 9 包装 Packaging．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 9 5-7 10 产品外观检查标准 Visual inspection standard of product．．．．．．．．．．．．．．．．．．．．．． 10 11 存贮条件 Products Storage．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． 10 深圳市中皇电子有限公司 地址：深圳市福田区深南中路3039号国际文化大厦808室 电话(Tel)：0755- 传真(Fax)：0755-8 邮编(Postcode)：518 Component SPEC Version Record Rev. Effective Date Changed Contents Change Reasons Approved By 01 Dec. 10.2010 New released / Wang rui 深圳市中皇电子有限公司 地址：深圳市福田区深南中路3039号国际文化大厦808室 电话(Tel)：0755- 传真(Fax)：0755-8 邮编(Postcode)：518 2 1. Scope This specification applies to the MPIT series of SMD power inductors. 2. Product Identification MPIT ① ② ③ ④ ⑤ ⑥ 5020 – ② 6R8 M ③ ④ - LF ⑤ Series name(SMD power inductor) Product dimensions (5.0×5.0×2.0mm) Inductance Value： (4R7: 4.7uH 100: 10uH; 101: 100uH) Inductance Tolerance：(K: 10% ; M: 20% ; N: 30%) Lead free products. 3. Appearance, Dimensions and Material 3.1 Appearance and dimensions f E C B D A 220 h S Recommended Pattern NOTE: S=Start F=Finish Model MPIT5020 A 5.0±0.2 B 5.0±0.2 C 2.0 Max. g E F Dimensions in mm D E 2.4±0.2 ..1.3±0.2 f 2.3Typ. g 5.1 Typ. h 4.2 Typ. 3.2 Material List No. 1 2 3 4 Item DR Core Wire Metal layer Epoxy Material Ferrite Enameled Copper Wire Ag/Ni/Sn/Cu Magnetic Epoxy 4.Testing Conditions Unless otherwise specified Temperature : Ordinary Temperature ( 5 to 35℃) Humidity : Ordinary Humidity (25 to 85% RH) Atmospheric Pressure : 86 to 106 kPa In case of doubt Temperature : 20±2℃ Humidity : 60 to 75% RH Atmospheric Pressure : 86 to 106 kPa 深圳市中皇电子有限公司 地址：深圳市福田区深南中路3039号国际文化大厦808室 电话(Tel)：0755- 传真(Fax)：0755-8 3 邮编(Postcode)：518 5. Electrical Characteristics And Test Instruments Microgate Part No. Customer Part No. MPIT5020-R47N-LF MPIT5020-R75N-LF MPIT5020-1R0N-LF MPIT5020-1R2N-LF MPIT5020-1R5N-LF MPIT5020-2R2N-LF MPIT5020-2R7N-LF MPIT5020-3R0N-LF MPIT5020-3R3N-LF MPIT5020-3R6N-LF MPIT5020-3R9N-LF MPIT5020-4R3M-LF MPIT5020-4R7M-LF MPIT5020-5R1M-LF MPIT5020-5R6M-LF MPIT5020-6R8M-LF MPIT5020-7R5M-LF MPIT5020-8R2M-LF MPIT5020-9R1M-LF MPIT5020-100M-LF MPIT5020-120M-LF MPIT5020-150M-LF MPIT5020-180M-LF MPIT5020-220M-LF Inductance (uH) DCR (Ω) ±30% Isat (A) Irms (A) SRF (MHz) 0.47±30% 0.013 0.017 0.020 0.022 0.026 0.032 0.038 0.038 0.043 0.043 0.043 0.057 0.057 0.064 0.064 0.083 0.090 0.098 0.110 0.110 0.140 0.165 0.200 0.226 6.15 5.50 4.10 4.50 4.10 3.20 2.90 2.55 2.55 2.80 2.30 2.50 2.50 2.25 2.30 2.05 1.85 1.85 1.70 1.70 1.50 1.35 1.25 1.15 4.60 4.00 3.80 3.55 3.20 2.90 2.70 2.70 2.50 2.50 2.50 2.20 2.20 2.05 2.05 1.80 1.75 1.65 1.55 1.55 1.40 1.25 1.15 1.10 160 117 114 83 68 57 52 49 46 43 40 37 37 32 32 30 26 26 24 24 22 20 16 14 0.75±30% 1.0±30% 1.2±30% 1.5±30% 2.2±30% 2.7±30% 3.0±30% 3.3±30% 3.6±30% 3.9±30% 4.3±20% 4.7±20% 5.1±20% 5.6±20% 6.8±20% 7.5±20% 8.2±20% 9.1±20% 10±20% 12±20% 15±20% 18±20% 22±20% T-I characteristic curve L-I characteristic curve 12μH 3.3μH Indictance（uH） Temperature Rise （℃） Temperature rise（℃） 70 2.2μH 60 50 40 30 20 10 Inductance (μH) 100 80 12μH 10 3.3μH 2.2μH 1 0.1 0 0.0 1.0 2.0 3.0 4.0 5.0 0.01 0.1 1 10 DC. Current(A) DC.Current（A） DC. Current(A) DC.Current（A） Test instruments and remarks * CHROMA 3302 meter for L adn DCR. * CHROMA 3302 and 1320 meter for IDC. * L test condition: 100KHz/1V. * Isat: Based on inductance change (|LI-L|/L≤30%) * Irms: Based on temperature rise(△T:40℃ TYP). 深圳市中皇电子有限公司 地址：深圳市福田区深南中路3039号国际文化大厦808室 电话(Tel)：0755- 传真(Fax)：0755-8 4 邮编(Postcode)：518 6. Condition of work 1. The part normal work be allowed ambient temperature: -25℃ ~ +85℃. 2 .The part must be allowed high temperature: +125℃. 3. The part normal work be allowed temperature dependent: 40℃ 4. Ambient temperature of the part is allowed storage temperature: -25℃ ~ +85℃. 5. Storage life: half a year 6 .The part be allowed work ambient frequency: 0.1MHz ~ 1MHz 7. Reliability and Test Condition Item Required Characteristics Test Method/Condition Temperature: 85±2℃ Time : 1000 hours Tested not less than 1 hours, nor more than 2 hours at room temperature. High temperature storage test 1000H Temperature : -25±2℃ Time : 1000 hours Tested not less than 1 hour, nor more than 2 hours at room temperature. Low temperature storage test 1. No case deformation or change in appearance. 2. |ΔL|/L≤10% 1000H 1. 2. 3. Exposure : Temperature:60±2℃, Humidity : 93±3% RH Time : 1000 hours. Tested while the specimens are still in the chamber. Tested not less than 1 hour, nor more than 2 hours at room temperature. Humidity test 1000H 深圳市中皇电子有限公司 地址：深圳市福田区深南中路3039号国际文化大厦808室 传真(Fax)：0755-8 电话(Tel)：0755- 邮编(Postcode)：518 5 Item Required Characteristics Test Method/Condition First -40℃ for T time, last 125℃ T time as 1 cycle. Go through 100 cycles. 1. Thermal test shock 2. No case deformation or change in appearance. |ΔL|/L≤10% 125℃ 30 min. 30 min. Ambient Temperature -40℃ 30 min. 20sec. (max.) Solderability test Terminal area must have 90% min. solder coverage. Heat endurance of reflow soldering Dip pads in flux then dip in solder pot at 245±5℃ for L/6 or w >W/6, NG. AQL=0.65 The area of missing resin more than 1/2single face, NG AQL=0.65 l 1 L W w 2 Missing resin L 3 Cold solder L more than 1 mm, NG. AQL=0.65 4 Solder uneven H>0.2mm. NG. AQL=0.65 H 11.Products Storage ⑴ Storage period Products which inspected in MICROGATE over 6 months ago should be examined and used, which can be confirmed with inspection No. marked on the container. Solderability should be checked if this period is exceeded. ⑵ Storage conditions Products should be storage in the warehouse on the following conditions: Temperature: -10 ~+ 40℃ Humidity : Less than 80% relative and humidity No rapid change on temperature and humidity ⑶ Don’t keep products in corrosive gases such as sulfur, chlorine gas or acid, or it may cause oxidization of electrode, resulting in poor solderability. ⑷ Products should be storage on the palette for the prevention of the influence from humidity, dust and so on. ⑸ Products should be storage in the warehouse without heat shock, vibration, direct sunlight and so on. ⑹ Products should be storage under the airtight packaged condition. 深圳市中皇电子有限公司 地址：深圳市福田区深南中路3039号国际文化大厦808室 电话(Tel)：0755- 传真(Fax)：0755-8 10 邮编(Postcode)：518
