2SC1623
SOT-23 Plastic-Encapsulate Transistors
2SC1623
TRANSISTOR (NPN)
SOT-23
FEATURES
z High DC current gain :hFE=200(Typ) VCE= 6V,IC=1mA
z High voltage:VCEO=50V
1. BASE
2. EMITTER
MAXIMUM RATINGS (Ta=25℃ unless otherwise noted)
Symbol
Parameter
3. COLLECTOR
Value
Unit
VCBO
Collector-Base Voltage
60
V
VCEO
Collector-Emitter Voltage
50
V
VEBO
Emitter-Base Voltage
5
V
IC
Collector Current
100
mA
PC
Collector Power Dissipation
200
mW
Thermal Resistance From Junction To Ambient
625
℃/W
Tj
Junction Temperature
150
℃
Tstg
Storage Temperature
-55~+150
℃
RΘJA
ELECTRICAL CHARACTERISTICS (Ta=25℃ unless otherwise specified)
Typ
Symbol
ol
Test conditions
Collector-base breakdown voltage
V(BR)CBO
IC=100μA,IE=0
60
V
Collector-emitter breakdown voltage
V(BR)CEO
IC=1mA,IB=0
50
V
Emitter-base breakdown voltage
V(BR)EBO
IE=100μA,IC=0
5
V
Collector cut-off current
ICBO
VCB=60V,IE=0
0.1
μA
Emitter cut-off current
IEBO
VEB=5V,IC=0
0.1
μA
DC current gain
hFE
VCE=6V,IC=1mA
Parameter
Min
90
200
Max
Unit
600
Collector-emitter saturation voltage
VCE(sat)
IC=100mA,IB=10mA
0.3
V
Base-emitter saturation voltage
VBE(sat)
IC=100mA,IB=10mA
1
V
fT
Transition frequency
VCE=6V,IC=10mA
250
MHz
CLASSIFICATION OF hFE
Rank
Range
Marking
L4
L5
L6
L7
90-180
135-270
200-400
300-600
L4
L5
L6
L7
DN:T20226A0
http://www.microdiode.com
Rev:2020A0
Page :1
2SC1623
Typical Characteristics
Static Characteristic
4
10uA
3
IC
8uA
6uA
5uA
4uA
3uA
1
IC
Ta=25℃
DC CURRENT GAIN
7uA
2
——
Ta=100℃
hFE
(mA)
9uA
COLLECTOR CURRENT
hFE
1000
COMMON
EMITTER
Ta=25℃
100
2uA
COMMON EMITTER
VCE= 6V
IB=1uA
0
0
2
4
6
COLLECTOR-EMITTER VOLTAGE
VBEsat ——
Ta=25℃
Ta=100 ℃
10
COLLECTOR CURREMT
IC
IC
Ta=100 ℃
Ta=25℃
IC
β=10
10
0.1
100
1
10
COLLECTOR CURREMT
(mA)
VBE
fT
1000
IC
——
100
(mA)
IC
T =2
5℃
a
TRANSITION FREQUENCY
10
T =1
00℃
a
COLLECTOR CURRENT
IC
fT
(mA)
(MHz)
——
100
(mA)
100
β=10
1
100
——
10
IC
300
1000
100
0.1
1
COLLECTOR CURRENT
VCEsat
IC
COLLECTOR-EMITTER SATURATION
VOLTAGE VCEsat (mV)
BASE-EMITTER SATURATION
VOLTAGE VBEsat (mV)
2000
10
0.1
8
VCE (V)
1
COMMON EMITTER
VCE=6V
0.1
0.0
0.3
0.6
0.9
100
COMMON EMITTER
VCE=6V
Ta=25℃
10
1.2
1
COLLECTOR CURRENT
BASE-EMMITER VOLTAGE VBE (V)
50
Cob/Cib
——
VCB/VEB
COLLECTOR POWER DISSIPATION
PC (mW)
Ta=25 ℃
10
Cib
C
(pF)
PC
250
f=1MHz
IE=0/IC=0
CAPACITANCE
70
10
Cob
1
——
IC
(mA)
Ta
200
150
100
50
0
0.1
0.1
1
REVERSE VOLTAGE
http://www.microdiode.com
10
V
(V)
20
0
25
50
75
AMBIENT TEMPERATURE
Rev:2020A0
100
Ta
125
150
(℃ )
Page :2
2SC1623
Outlitne Drawing
SOT-23 Package Outline Dimensions
e
Suggested Pad Layout
0.037
0.95
0.037
0.95
L
L1
E
E1
Symbol
A
A1
b
c
D
E
E1
e
L
L1
θ
Dimensions In Millimeters
Min
Typ
Max
1.00
1.40
0.10
0.35
0.50
0.20
0.10
2.70
2.90
3.10
1.40
1.60
2.4
2.80
1.90
0.10
0.30
0.4
0°
10°
Note:
1. Controlling dimension:in/millimeters.
2. General tolerance: ±0.05mm.
3. The pad layout is for reference purposes only.
0.079
2.0
0.035
0.9
0.031
0.8
inches
mm
Important Notice and Disclaimer
Microdiode Electronics (Jiangsu) reserves the right to make changes to this document and its
products and specifications at any time without notice. Customers should obtain and confirm the
latest product information and specifications before final design,purchase or use.
Microdiode Electronics (Jiangsu) makes no warranty, representation or guarantee regarding
the suitability of its products for any particular purpose, not does Microdiode Electronics
(Jiangsu) assume any liability for application assistance or customer product design. Microdiode
Electronics (Jiangsu) does not warrant or accept any liability with products which are purchased
or used for any unintended or unauthorized application.
No license is granted by implication or otherwise under any intellectual property rights of
Microdiode Electronics (Jiangsu).
Microdiode Electronics (Jiangsu) products are not authorized for use as critical components
in life support devices or systems without express written approval of Microdiode Electronics
(Jiangsu).
http://www.microdiode.com
Rev:2020A0
Page :3
2SC1623
SOT-23 Tape and Reel
Packaging Description:
SOT-23 parts are shipped in tape. The carrier
tape is made from a dissipative (carbon filled)
polycarbonate resin. The cover tape is a multilayer
film (Heat Activated Adhesive in nature) primarily
composed of polyester film,adhesive laye,sealant,
and anti-static sprayed agent.These reeled parts In
standard option are shipped with 3,000 units per 7"
or 17.8cm diameter reel. The reels are clear in color
and is made of polystyrene plastic (anti-static
coated).
3000 pcs
http://www.microdiode.com
7 Inch
45,000 pcs
203×203×195
180,000 pcs
438×438×220
Rev:2020A0
Page :4
