07D471KJ

山东晶导微电子股份有限公司 07D Series Jingdao Microelectronics co.LTD Applications Features • S urge protection in consumer electronics. • Surge protection in industrial electronics. • Surge protection in electronics home • Appliances,gas and petroleum appliances. • Relay and electromagnetic valve surge absorption • RoHS compliant • Varistor Voltage (V1mA) range from 100V to 820V. • Fast responding to transient over-voltage. • Large absorbing transient energy capability. • Low clamping ratio and no following-on current. Part Number Code 0 7 Chip Diameter 芯片直径 05 07 10 14 20 25 Φ5mm Φ7mm D Chip Shap 芯片形状 圆形 Disc 7 4 1 K Varistor Voltage 压敏电阻动态电压 Tolerance 误差 Examples:例如 K ±10% L ±15% M ±20% or Customer Special Requirement 4 7 0 Φ10mm Φ14mm Φ20mm 47*10 0 =47V Φ25mm 47*10 =470V 4 7 1 1 1 1 2 J High Surge/Lead Style 高焦/脚型 空白常规 J 高能品 11*10 2 =1100V 2018.09 www.sdjingdao.com Page 1 of 4 山东晶导微电子股份有限公司 07D Series Jingdao Microelectronics co.LTD Mechanical Requirements Solderability Min. 95% of The Terminal Should Be Covered With Solder Uniformly V1mA/V1mA≤±5% Resistance of soldering heat Solder Temp:265±5℃ Immersed Time: 2±0.5Sec. Solder Temp: 260±5℃ Immersed Time: 10±1Sec. Enviromental Requirements High Temperature Storage △V1mA/V1mA ≦±5% Ambient Temp: 125±2℃ Duration:1000h Low Temperature Storage △V1mA/V1mA ≦±5% Ambient Temp: 125±2℃ Duration:1000h High Humidity Storage/Damp Heat △V1mA/V1mA ≦±5% Ambient Temp: 125±2℃ Duration:1000h Step Temperature Temperature Cycle △V1mA/V1mA ≦±5% Period 1 -50℃ 30min 2 Room Temp 15min 3 150℃ 30min 4 Room Temp 15min High Temperature Load △V1mA/V1mA ≦±10% Ambient temp:85±2℃ Duration:1000h Load: Max. Allowable Voltage High Humidity Load △V1mA/V1mA ≦±10% Ambient Temp:125±2℃ Duration:1000H Load: MAX. Allowable Voltage Operating Temperature Range -40℃ ~ +85℃ -40℃ ~ +85℃ Storage Temperature Range -40℃ ~ +125℃ -40℃ ~ +125℃ 2018.09 www.sdjingdao.com Page 2 of 4 山东晶导微电子股份有限公司 07D Series Jingdao Microelectronics co.LTD Characteristics at Ta = 25°C Maximum Allowable Voltage Type Number V AC V DC Varistor Voltage V 1mA Maximum Clamping Voltage IT VC Withstanding Surge Current I(A) I(A) High Standard Surge Maximum Energy I(A) I(A) Rated Power Typical Capacitance (Reference) Standard High Surge W @1KHz(pF) Standard High Surge V V V A V 07D101K 07D101KJ 60 85 100(90~110) 10 165 1200 1750 6.5 12 0.25 500 07D121K 07D121KJ 75 100 120(108~132) 10 200 1200 1750 7.8 13 0.25 420 07D151K 07D151KJ 95 125 150(135~165) 10 250 1200 1750 9.7 13 0.25 330 07D181K 07D181KJ 115 150 180(162~198) 10 300 1200 1750 11.7 16 0.25 280 07D201K 07D201KJ 130 170 200(180~220) 10 340 1200 1750 13.0 17 0.25 250 07D 221K 07D 221KJ 140 180 220(198~242) 10 360 1200 1750 14.0 19 0.25 230 07D241K 07D241KJ 150 200 240(216~264) 10 395 1200 1750 15.0 21 0.25 210 07D271K 07D271KJ 175 225 270(243~297) 10 455 1200 1750 18.0 24 0.25 185 07D301K 07D301KJ 190 250 300(270~330) 10 500 1200 1750 20.0 26 0.25 165 275 330(297~363) 07D331K 07D331KJ 210 10 550 1200 1750 23.0 28 0.25 150 07D361K 07D361KJ 230 300 360(324~396) 10 595 1200 1750 25.0 32 0.25 140 07D391K 07D391KJ 250 320 390(351~429) 10 650 1200 1750 25.0 35 0.25 130 07D431K 07D431KJ 275 350 430(387~473) 10 710 1200 1750 28.0 40 0.25 115 07D471K 07D471KJ 300 385 470(423~517) 10 775 1200 1750 30.0 42 0.25 105 07D511K 07D511KJ 320 415 510(459~561) 10 845 1200 1750 30.0 45 0.25 100 07D561K 07D561KJ 350 460 560(504~616) 10 925 1200 1750 30.0 49 0.25 90 07D621K 07D621KJ 385 505 620(558~682) 10 1025 1200 1750 33.0 55 0.25 80 07D681K 07D681KJ 420 560 680(612~748) 10 1120 1200 1750 33.0 60 0.25 75 07D751K 07D751KJ 460 345 750(675~825) 10 1240 1200 1750 67.2 65 0.25 70 07D781K 07D781KJ 485 640 780(702~858) 10 1290 1200 1750 67.2 65 0.25 70 07D821K 07D821KJ 510 670 820(738~902) 10 1355 1200 1750 67.2 70 0.25 60 Remark: Voltage ＞33V,K is+10% 2018.09 www.sdjingdao.com Page 3 of 4 山东晶导微电子股份有限公司 07D Series Jingdao Microelectronics co.LTD PACKAGE OUTLINE Plastic surface mounted package; 2 leads C A SMDY L HE UNIT mm mil e E D A HE D E e C L max 4.2 11 10 8.7 2.7 min 3.8 10.6 9.6 8.3 2.3 0.15 (ref) 0.5 (ref) max 165 433 394 343 106 min 150 417 378 302 90.5 9.8 (ref) 20 (ref) The recommended mounting pad size 5 (197) 11 (433) 3 (118) 2018.09 www.sdjingdao.com Unit： mm (mil) Page 4 of 4
