TP5852111010

A B D C 1 8.50[0.335]±0.15 2 E F G 3 8 3 3.80[0.150]±0.40 6.50[0.256]±0.15 Technical parameter 技术参数 1. Rated current: DC12V 50mA 1.额定电流：DC12V 50mA 2. Withstand voltage: AC250V (50-60Hz) for 1 minute 2.耐压：AC250V(50-60Hz)持续1分钟 3. Contact impedance: 100M Ω Max 3.接触阻抗：100mΩmax 4. Insulation impedance: 100M Ω min.500v DC 4.绝缘阻抗：100MΩmin.500V DC 5. Operating force: 200 ± 100gf 0.50[0.020] 2-0.20[0.008] 6-0.60[0.024] 2.50[0.098] 2 10.10[0.398]±0.20 1.60[0.063]±0.10 4.60 [0.181]±0.10 1 6 5 4.10[0.161]±0.10 3 8 7 5.00[0.197]±0.50 7.80[0.307]±0.40 6.12[0.241]±0.50 6 5 4 2.50[0.098] L2 L1 5.00[0.197] 4 Ø1 7.80[0.307] 1 .00 [ Ø0 .03 9] Ø0 .90 [Ø 0.0 35 ] 4 COMMON A3 台普 A2 A1 DATE REVISION DESCRIPTION 5 6 1 NO 序号 Circuit diagram A4 REV 3 3 2 PCB LAYOUT 5 2 ISSUE TOLERANCE X.XX ± 0.10 X.X ± 0.15 X ± 0.25 ANGULAR UNIT Cover 盖板 Guide core 导芯 Spring 弹簧 Reed 簧片 Injection molding terminal 注塑端子 Base 底座 Terminal 端子 Part name 部件名 MM DRAWN BY FUYUAN DATE 5.操作力：200±100gf 6. Full stroke 2.0mm ± 0.4mm 6.全行程2.0mm±0.4mm 7. Conduction stroke: 0.8mm ± 0.4mm 7.导通行程0.8mm±0.4mm 8. Working temperature: - 40 ℃ ~ + 85 ℃ 8.工作温度：-40℃~+85℃ 9. Operation type: No lock 9.运行类型：无锁 10. Service life: 10.000 times 10.寿命：10.000次 LED 0.30[0.012] 2.50[0.098] 2.50[0.098] 7 4 4 2 5 L2 L1 3.50 [0.138] 5.85 [0.230] 1 7.50 [0.295]±0.15 6 2019 1 POM 1 POM 1 Steel wire 钢丝 Phosphor copper 磷铜 2 PA66 2 PA66 1 Brass 黄铜 Material 材料 QTY 数量 PROJCTED Red 红灯 Black 黑色 White 白色 1 6 Ag plating 镀银 Black 黑色 Black 黑色 Ag plating 镀银 Remark 备注 PRODUCT NAME: CHECKED BY COCO MODEL NO: TP5852111010 APPROVAL B ALEN Https: www.rocpu.tw ROCPU TECHNOLONGY CO.,LTD Copies are issued in strict confidence and shall not be reproduced or copied,or used as the basic of manufacture or sale of apparatus without permission F
