Application Notes: AN_SY6874
Programmable Current Limit Switch
General Description
Features
SY6874 is a programmable current limit switch with
input voltage range selection and output voltage
clamping. Extremely low RDS(ON) of the integrated
protection N-channel FET helps to reduce power loss
during the normal operation. Programmable soft-start
time controls the slew rate of the output voltage during
the start-up time. Independent enable control allows the
complicated system sequencing control. It integrates
the over-temperature protection shutdown and autorecovery with hystersis. This IC along with small
DFN3X3-10 footprint provides small PCB area
application..
• Wide Input Voltage Range from 2.5V to 15V with
surge up to 30V
• Extremely Low RDS(ON) for the Integrated
Protection Switch: 50 mΩ
• Programmable Soft-Start Time
• Programmable Current Limit up to 4A
• Short-circuit Protection
• Selectable Input Range and Clamping Output
Voltage Threshold.
• Enable Interface Pin
• Thermal Shutdown Protection & Auto Recovery
• RoHS Compliant and Halogen Free
• Compact package: DFN3X3-10
Ordering Information
Applications
SY6874 □(□□)□
Temperature Code
Package Code
Optional Spec Code
Ordering Number
SY6874DBC
Package type
DFN3x3-10
Note
----
•
•
•
•
Notebook PC
I-pad Mini
Server
Service PC
Typical Applications
Figure 1. Schematic Diagram
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
1
AN_SY6874
Pinout (top view)
(DFN3x3-10)
Top mark: JTxyz for SY6874 (Device code: JT, x=year code, y=week code, z= lot number code)
Pin Name
Pin Number
Pin Description
IN
1,2,3
GND
11(exposed paddle)
OUT
ILIM
8,9,10
5
SST
6
EN
VCP
7
4
Power input pin. Decouple high frequency noise by connecting at
least 0.1uF MLCC to ground.
Ground pin.
Power output pin.
Current limit program pin. Program the current limit by
connecting a resister to ground.
Soft-start time program pin. Connect a capacitor to ground to
program the soft start time.
Enable interface pin. Pull it High to enable the IC.
Output clamp voltage selection based on the input voltage. Pull
VCP pin to High by connecting a resistor to IN, or pull VCP pin to
Low by connecting a resistor to ground, or float VCP Pin to select
different output clamping thresholds. Recommend to decoupling
this pin with 0.1uF capacitor.
Clamping Threshold
VCP
IN
Min
Typ
Max
Low
3.3V
Over 4V
3.6V
3.8V
4.0V
High
5V
Over 6V
5.4V
5.7V
6.0V
Open
12V
Over 14V 12.6V
13.3V
14V
Block Diagram
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
2
AN_SY6874
Absolute Maximum Ratings (Note 1)
Supply Input Voltage ----------------------------------------------------------------------------------------- 30V
EN pin, VCP pin, ---------------------------------------------------------------------------------------------- 30V
Power Dissipation, PD @ TA = 25°C DFN3X3-10, ------------------------------------------------------- 2.6W
Package Thermal Resistance (Note 2)
θ JA ------------------------------------------------------------------------------------------------------------- 38°C/W
θ JC ------------------------------------------------------------------------------------------------------------- 8°C/W
Junction Temperature Range -------------------------------------------------------------------------------- 125°C
Lead Temperature (Soldering, 10 sec.) --------------------------------------------------------------------- 260°C
Storage Temperature Range ---------------------------------------------------------------------------------- -65°C to 150°C
Recommended Operating Conditions (Note 3)
Supply Input Voltage ----------------------------------------------------------------------------------------- 2.5V to 15V
Junction Temperature Range -------------------------------------------------------------------------------- -40°C to 125°C
Ambient Temperature Range ------------------------------------------------------------------------------- -40°C to 85°C
Electrical Characteristics
(VIN = 5V, RLIM=10kΩ, CSST=105nF, CIN = 10uF, COUT = 10uF, TA = 25°C, unless otherwise specified )
Parameter
Input Voltage Range
Input UVLO Threshold
Symbol
VIN
VUVLO
UVLO hysteresis
VHYS
Bias Current
Shutdown Current
Protection FET RON
Current Limit Accuracy
Current Limit Program Range
Clamping Output Voltage
Soft-start Time
Soft-start Time Accuaracy
EN Turn-on Threshold
EN Turn-off Threshold
Thermal Shutdown
Temperature
Thermal Shutdown Hysteresis
IBIAS
ISHDN
RDS(ON)
ILIM
VCLP
TSST
VEN_ON
VEN_OFF
TSD
THYS
Test Conditions
VCP=LOW
VCP=HIGH
VCP=OPEN
VCP=LOW
VCP=HIGH
VCP=OPEN
Min
2.5
2.2
3.4
8.1
0.05
0.06
0.1
EN=0
(Note 5)
VCP=LOW
VCP=HIGH
VCP=OPEN
1
3.6
5.4
12.6
CSST=105nF(Note 4)
Typ
0.085
0.095
0.19
200
10
50
30%ILIM
3.8
5.7
13.3
29.4
±30%TSST
Max
30
2.4
3.8
9.0
0.13
0.15
0.29
80
4
4.0
6.0
14.0
2
Unit
V
V
V
V
V
µA
µA
mΩ
A
V
V
V
ms
140
V
V
°C
20
°C
0.4
Note 1: Stresses beyond the “Absolute Maximum Ratings” may cause permanent damage to the device. These are
for stress ratings. Functional operation of the device at these or any other conditions beyond those indicated in the
operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions may affect
device reliability.
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
3
AN_SY6874
Note 2: θ JA is measured in the natural convection at TA = 25°C on a low effective single layer thermal conductivity
test board of JEDEC 51-3 thermal measurement standard. Test condition: Device mounted on 2” x 2” FR-4 substrate
PCB, 2oz copper, with minimum recommended pad on top layer and thermal vias to bottom layer ground plane.
Note 3. The device is not guaranteed to function outside its operating conditions
Note4. Recommended Soft-start Time Program Table
SST cap (nF)
Rise time (ms)
None
1.4
10
2.8
55
15.4
105
29.4
Recommended Formula for CSST & Soft-start Time Calculation
TSS _ DLT , No external CSST
,
TSS = C SST
, TSS > TSS_DLT
I INT
Where, TSS_DLT is the internally fixed default soft-start time, about 1.4ms, which means there’s no any external
CSST; IINT is the internal current source, about 3.6uA.
Note5. Recommended Current Limit Program Table
Current Limit Resistance (kΩ)
Current Limit (A)
11
1.0
5.5
2.0
4.4
2.5
3.7
3.0
3.1
3.5
2.8
4.0
Recommended Formula for RLIM & Current Limit Calculation
RLIM =
11k
(Ω) .
I LIM
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
4
AN_SY6874
Typical Performance Characteristics
Programmable Soft-start Time
( 3.3V Mode, IO=1A, CSST=100nF)
ILIMIT(A)
VVININ
VVOUT
OUT
IOIO
2.0V/div
2.0V/div
1.0V/div
2.0V/div
500mA/div
0.5A/div
Time (10ms/div)
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
5
AN_SY6874
VIN
VIN
VV
OUT
OUT
IO
IO
Shutdown
Over Voltage Protection
( 12V Mode, IO=1A, CSST=100nF)
( 5V Mode, VIN=8V, IO=0A)
5.0V/div
5.0V/div
VIN
5.0V/div
5.0V/div
5.0V/div
0.5A/div
500mA/div
2.0V/div
VINVOUT2.0V/div
Time (2.0ms/div)
AN_SY6874 Rev. 0.9A
VOUT
2.0V/div
IOIO
0.5A/div
500mA/div
Time (400ms/div)
Silergy Corp. Confidential- Prepared for Customer Use Only
6
AN_SY6874
PCB Layout Guideline
Top Silkscreen
AN_SY6874 Rev. 0.9A
Top Layer
Bottom Layer
Silergy Corp. Confidential- Prepared for Customer Use Only
7
AN_SY6874
DFN3x3-10 Package outline
Top View
PCB layout (recommended)
Side View
Detail A
Pin1 identifier: two options
Bottom View
Notes: All dimensions are in millimeters and exclude mold flash & metal burr.
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
8
AN_SY6874
Taping & Reel Specification
3.9/4.1
1.45/1.55
11.7/12.3
1. DFN3x3-10 taping orientation
Feeding direction
2. Carrier Tape & Reel specification for packages
Reel
Width
Reel
Size
Package
types
DFN3x3
Tape width
(mm)
Pocket
pitch(mm)
Reel size
(Inch)
Reel
width(mm)
Trailer
length(mm)
Leader length
(mm)
Qty per
reel
10
8
13"
12.4
400
400
5000
3. Others: NA
AN_SY6874 Rev. 0.9A
Silergy Corp. Confidential- Prepared for Customer Use Only
9
