AFC20-S06ACA-00

深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 認 書 Productacknowledgment 客户（Customer）： 品名（Product Name）： ２．０ｍｍ间距卧式贴片连接器 料号（Material number）： ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００（＊＊表示ＰＩＮ位数） 本公司确认Our confirmation 工程/日期engineering/date 刘中华 2019.12.03 业务/日期business/date 王 斌 2019.12.03 批准/日期Approval/date 幸坤新 2019.12.03 客户确认Customer confirmation 工程/日期engineering/date 公司地址： 电话： 联系人： 传真： 邮件： 品质/日期quality/date 批准/日期Approval/date 深圳市钜硕电子有限公司 产品名称 Product name ２．０ｍｍ卧式贴片 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产品型号 Product model ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 产 品 承 认 书 Product acknowledgement 版本号 Version number 页码 Page number 1版 1 version 共6页 第1页 Page 1 of 6 目录 directory 文件名称 The file name 项次 Items are 页码 Page number 1 封面The cover P-1 2 目录directory P-2 3 工程变更记录Engineering change record P-3 4 标准额定值、包装、运输、贮存、部件名称及材质、外观 Standard rating、Packing、transport、Keep in storage、storage Part name material、appearance P-4 5 电气特性、环境特性Electrical and environmental characteristics P-5 6 环境特性Environmental characteristic P-6 7 环境特性Environmental characteristic P-7 8 机械特性Mechanical properties P-8 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 认 书 Product acknowledgement 产品名称 Product name 产品型号 Product model 版本号 Version number 页码 Page number ２．０ｍｍ卧式贴片 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 1版 1 version 共6页 第1页 Page 1 of 6 工程变更记录 Engineering change record 版本号 Version number 变更记录 Change record 变更人 Change a person 日期 The date of 产品名称 product name 产品型号 Product model 版本号 Version number 页码 Page number 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 认 书 Certificate of production 1.适用范围 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 1版 1 version 共6页 第2页 Page 2 of 6 Scope of application 本规范适用于2.0系列产品。 2.标准额定值 This specification is applicable to A1251 series products. Standard rating 项目 project 规格 额定电压 The rated voltage 额定电流 specifications 250V Rated current 2.0A 使用温度范围 Operating temperature range AC/DC -25℃～+105℃ 使用湿度范围 Operating humidity range 3.环保 ２．０ｍｍ卧式贴片 相对湿度90%以下 Relative humidity is below 90% The environmental protection 产品符合ROHS环保要求。Products in line with ROHS environmental protection requirements. 4.包装 Packing 产品内包装为连带，外包装为纸箱，产品在箱内密封，不晃动。 The inner packing of the product is joint and several, the outer packing is carton, the product is sealedin the box, do not shake. 5.运输 transport 允许用任何方式运输，但需避免雨雪淋和阳光照射，不能有碰撞和挤压等机械损伤，运输环境温度为-20℃+50℃ It is allowed to be transported by any means, but it should avoid rain, snow and sunlight, no mechanicaldamage such as collision and extrusion, and the ambient temperature of transportation is -20℃+50℃ 6.贮存：Storage 包装完毕连接器应在环境温度为-20℃～+50℃，相对湿度不大于90%，周围空气中没有酸性，碱性及其它腐 蚀性气体的仓库中贮存。 After packaging, the connector should be in the ambient temperature of -20℃～+50℃, the relative humidity should not be more than 90%, there is no acid, alkaline and other decayin the surrounding air 7.部件名称/部件规格型号/部件材质 部件名称 Part name Part name/part specification/part material 型号 model 材质 The material 基座 base 2.0 插针 pin 2.0 黄铜 brass 2.0 黄铜 brass 固定片 8.外观及尺寸 8.1外观 stator LCP E130i Appearance and size appearance 塑胶件表面应无明显疤痕、杂色、开裂、毛刺、飞边、缺料及影响使用的变形；金属件表面应光洁、无锈蚀、 氧化、脱皮、发黑及明显的机械损伤等缺陷。 The surface of plastic parts shall be free of obvious scars, mottled, cracked, burr, flash, lack of material and deformation affecting the use; the surface of metal parts shall be smooth and clean No rust, oxidation, peeling, blackening and obvious mechanical damage. 8.2 尺寸 参照工程图 size Reference engineering drawing 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 认 书 Certificate of production 9.电气特性 编号 number 产品名称 product name 产品型号 Product model 版本号 Version number 页码 Page number ２．０ｍｍ卧式贴片 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 1版 1 version 共6页 第3页 Page 3 of 6 Electrical characteristics 项目 project 试验方法 Test method for 9.1 将连接器插合，用接触电阻仪进行测试，测量连接器两个端子 接触电阻 之间组成一个闭合的回路。 contact Plug in the connector and test it with a contact resistance resistance meter to measure both terminals of the connector Form a closed loop between. 9.2 将连接器插合，在相邻接触件之间和接触件与外壳之间施加1000V 绝缘电阻 DC电压，持续1分钟进行测试。 Insulation Plug in the connector and apply 1000V DC voltage between resistance the adjacent contacts and between the contacts and the enclosure for 1 minute. 9.3 将连接器插合，在相邻接触件之间和接触件与外壳之间施加1000V AC电压，持续1分钟进行测试。 耐电压 Withstand Plug in the connector and apply 1000V AC voltage between voltage the adjacent contacts and between the contacts and the enclosure for 1 minute. 性能要求 performance requirements 20mΩ 1000MΩ Max Min 无击穿和飞弧现象 No breakdown and flashover 10.环境特性 性能要求 performance requirements 外观：外观无损伤 将插合连接器放在温度为+105℃±2℃的环境中96H,取出放在正 Appearance: 常环境中1~2H后再进行测试。 appearance without Put the plug connector in the environment of +105℃±2℃ damage 接触电阻：30mΩ Max for 96H, take it out and put it in the normal environment Contact resistance: for 1~2H before testing. 30mΩ Max 编号 number 项目 project 10.1 耐热试验 Heating test 10.2 将插合连接器放在温度为-25℃±2℃的环境中96H,取出放在正常 耐冷试验 环境中1~2H后再进行测试。 The plug connector was placed in the environment with the Cold tolerance temperature of -25℃±2℃ for 96H, and was taken out and test placed in the normal environment for 1~2H before being tested. 10.3 试验方法 Test method for 外观：外观无损伤 Appearance: appearance without damage 接触电阻：30mΩ Max Contact resistance: 30mΩ Max 外观：外观无损伤 Appearance: appearance without 将插合连接器放在温度为40℃±2℃，相对湿度90~96%的环境中， damage 绝缘电阻：500MΩ MIN 耐湿性试验 持续96H,经试验后，取出放在正常环境中1~2H后再进行测试。 Insulation Moisture Place the plug connector in an environment with a resistance: 500MΩ resistance temperature of 40℃±2℃ and relative humidity of min test 90~96%.Last for 96H, after the test, take it out and put 耐电压：600V AC/min it in the normal environment for 1~2H before the test. ute MIN Withstand voltage: 600V AC/minUte MIN 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 认 书 Certificate of production 编号 number 10.4 10.5 项目 project 产品名称 product name 产品型号 Product model 版本号 Version number 页码 Page number 试验方法 Test method for 把试验样品分别放入高低温试验箱，按下列步骤调试温度： a.在-25℃±3℃的恒温条件下放置30分钟 b.在常温条件下放置1H C.在+105℃±3℃的恒温条件下放置30分钟 D.在常温条件下放置1H 从a到d为一个循环周期，共进行5个循环，在正常环境中恢 复2H后进行检查。 Put the test samples into the high and low 温度循环 temperature test chamber, and adjust the temperature Temperature according to the following steps: cycle A. Place for 30 minutes under the constant temperature of -25℃±3℃ B. Place at room temperature for 1 hour C. Place for 30 minutes at a constant temperature of +105℃±3℃ D. Place at room temperature for 1 hour From a to d is a cycle period, a total of 5 cycles are carried out, and 2H is recovered in the normal environmentCheck later. ２．０ｍｍ卧式贴片 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 1版 1 version 共6页 第4页 Page 4 of 6 性能要求 performance requirement 外观：无任何异状 接触电阻：30mΩ Max Contact resistance: 30mΩ Max 外观：无损伤、腐蚀 （五金件应无露出底金 属的严重锈蚀：使用预 镀好的型材，其落料面 允许有不影响其性能的 轻微腐蚀。 Appearance: no damage 将试验样品从试验箱顶悬挂下来，采用浓度为（5±1 or corrosion ）%的氯化钠溶液，连续喷雾24H,试验后用流动的蒸 (hardware should not 溜水轻轻洗去表面沉淀积物，在常温条件下恢复1~2H后 expose the bottom 再检查测量。 盐雾试验 metal of serious The test sample was suspended from the top of the Salt Spray corrosion: use pretest box, and the concentration of (51)% Sodium Test Chloride Solution was continuously sprayed with 24H. platingThe blanking After testing, the surface precipitates were lightly surface is allowed to have a slight washed with flowing steaming water, then the 1~2H corrosion that does was rechecked at normal temperature. not affect its performance. 接触电阻：30mΩ Max Contact resistance: 30mΩ Max 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 认 书 Certificate of production 编号 number 10.6 10.7 项目 project 产品名称 product name 产品型号 Product model 版本号 Version number 页码 Page number 试验方法 Test method for 把试验样品需要焊接的部位浸入245±5℃的锡溶液中， 可焊性 保持2.5±0.5秒。 weldability Dip the welded part of the test sample into 245±5℃ tin solution and hold 2.5±0.5 seconds. 耐焊性 Soldering resistance ２．０ｍｍ卧式贴片 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 1版 1 version 共6页 第5页 Page 5 of 6 性能要求 performance requirement 沾锡面积95%以上 Tin area above 95% 1.塑胶件不得有明显变 形损坏起泡。 2.电气特性必须符合规格。 将连接器置于PCB板上，然后将产品通过260℃±5℃回 Plastic parts shall be 流焊或波峰焊5±1S进行测试。 free from obvious Place the connector on the PCB, and then reflow the deformation, damage and product through 260 ℃± 5 ℃ blistering. Or wave soldering for 5 ± 1s. 2. The electrical characteristics must meet the specifications. 产品名称 ２．０ｍｍ卧式贴片 product name 产品型号 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ Product model 版本号 1版 Version number 1 version 页码 共6页 第6页 Page number Page 5 of 6 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 产 品 承 认 书 Certificate of production 11.机械特性 编号 number 11.1 mechanical properties 项目 project 性能要求 performance requirement 试验方法 Test method for 将针座固定在插拔力机上，在针脚前端施加力，以每分钟 25±3mm的速率，直到针退出针座的拔出力。 PIN针固定力 Fix the pin holder on the drawing machine and apply Pin fixing force on the front end of the pin at a rate of 25±3mm force per minute until the pin is withdrawn from the pin holder. 11.2 端子在塑胶 件中保持力 Terminal retention in plastic parts 11.3 机械寿命 Mechanical life 端子与孔座配合，以每分钟25±3mm的速率沿导线方向，将端子 从孔座中拔出的力。 The terminal shall be matched with the hole seat, and at the rate of 25±3mm per minute along the conductor direction, theThe force that the terminal is pulled out of the socket. 无通电状态下，10次/分钟的速度插拔50次。 Under no power on state, plug and unplug 50 times at the speed of 10 times / min. 单一PIN针10N Min Single pin 10n min 单一端子：7N Min Single terminal: 7n min 接触电阻：30mΩ Max Contact resistance: 30m Ω Max 试验方法：Test methods （1）将孔座和端子配合好，与针座在同一轴线上进行插拔测试，测试时需将孔座锁 扣去掉。（测试速度：20±5mm）minute (1) Fit the hole seat and the terminal, and conduct the insertion and removal test on the same axis with the needle seat. Remove the lock of the hole seat (test speed: 20 ± 5mm) minute during the test （2）性能要求:Performance requirements 11.4 插入力拔出力 Insertion pull out force 孔位 插入(N) insert 拔出（N) Pull out 孔位 插入(N) insert 拔出（N) Pull out 1 4.00 1.50 9 52.00 16.50 2 24.00 6.00 10 56.00 18.00 3 28.00 7.50 11 60.00 19.50 4 32.00 9.00 12 64.00 21.00 5 36.00 10.50 13 68.00 22.50 6 40.00 12.00 14 72.00 24.00 7 44.00 13.50 15 76.00 25.50 8 48.00 15.00 16 80.00 27.00 ２．０ｍｍ卧式贴片 幸坤新 王　斌 刘中华 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００ 深圳市钜硕电子有限公司 ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ ＳＨＥＮＺＨＥＮ　ＪＵＳＨＵＯ　ＥＬＥＣＴＲＯＮＩＣ　ＣＯ．，ＬＴＤ 深圳市钜硕电子有限公司 幸坤新 ２．０ｍｍ卧式贴片 ＡＦＣ２０－Ｓ＊＊ＡＣＡ－００
