FBF25FPPR200

信昌電子陶瓷股份有限公司 Prosperity Dielectrics Co., Ltd. No.220-1, Sec. 2, Nanshan Rd., Lujhu, Taoyuan 33860, Taiwan, R.O.C. Tel.：886-3-3224471 Fax：886-3-3212216 SPECIFICATION FOR APPROVAL DATE: CUSTOMER: PART NAME: High-Power Low Resistance Lead Free & Halogen Free Chip Resistors CUSTOMER'S DWG. NO. CUSTOMER'S PART NO. PDC PART NO. FBF SERIES APPROVED DESCRIPTION. ACTION RESULT " ˇ" CUSTOMER'S SIGNATURE NOTE FULL APPROVED CONDITIONAL APPROVED REJECTED OUR ACTION SIGNATURE PREPARED BY Jenny Tseng CHECKED BY Tony Chou APPROVED BY Byron Tsai Edition : FBF-Rev.8.0.G38 CUSTOMER SIGNATURE FOR ACCEPTANCE Serial Number : K PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors 1. Features ………………………………………..……………..…….2 2. Applications…..…..………………………………..………………. 2 3. Dimension and construction ………………………..……………..2 4. Power Derating Curve …..…………………………….…………..3 5. Rating ……………………………………………………………….4 6. Part Number ………………………………..………………………5 7. Resistance Marking / Soldering 8. Reliability Performance…………………………………………….7 9. Packing ………………………………………………….…………..8 9.1 Peel Strength of Top Cover Tape……………………………….8 9.2 Tape Packaging Dimensions……………………………………8 9.3 Reel Dimensions………………………………………………....9 ………………………………..5 10. Storage / Handling ……………………………………….…………..9 Prosperity Dielectrics Co., Ltd. 1/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors 1. Features     Low resistance and high precision (1%). Excellent reliability and suitable cost. Suitable for lead free soldering. RoHS compliant & Halogen Free. 2. Applications     Consumer electronics, M/B. Battery pack, BTC. Notebook, Tablet PC. Portable Device, Electronic Equipment. 3. Dimensions and Constructions Unit：mm T Type 1. L W C D FBF03 1.60±0.10 0.80±0.10 0.30±0.20 0.30±0.20 0.45±0.10 FBF05 2.00±0.10 1.25±0.10 0.40±0.20 0.40±0.20 0.50±0.10 FBF06 3.10±0.10 1.60±0.10 0.50±0.25 0.50±0.25 0.55±0.10 FBF12 3.10±0.10 2.60±0.10 0.50±0.25 0.50±0.25 0.55±0.10 FBF20 5.00±0.20 2.50±0.20 0.60±0.25 0.60±0.25 0.60±0.10 FBF25 6.30±0.20 3.10±0.20 0.60±0.25 0.90±0.25 0.60±0.15 Type 2. L W C D T FBF03 1.60±0.10 0.80±0.10 0.30±0.20 0.50±0.20 0.50±0.10 FBF05 2.00±0.10 1.25±0.10 0.40±0.20 0.65±0.20 0.60±0.10 FBF06 3.10±0.10 1.60±0.10 0.50±0.25 0.90±0.25 0.65±0.10 FBF12 3.10±0.10 2.60±0.10 0.50±0.25 0.90±0.25 0.65±0.10 FBF20 5.00±0.20 2.50±0.20 0.60±0.25 1.25±0.25 0.65±0.10 FBF25 6.30±0.20 3.10±0.20 0.60±0.25 1.90±0.25 0.65±0.15 Prosperity Dielectrics Co., Ltd. 2/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors Type 1. Resistance ≧ 40mΩ Type 2. Resistance ≦ 39mΩ 4. Power Derating Curve Operating Temperature Range: -55 to +155 deg.C Prosperity Dielectrics Co., Ltd. 3/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors 5. Rating Normal Type Power Rating Type FBF03 Size 0603 at 70℃ 1/8W Max. RCWV (mV) 337 Max. Resistance Temperature Resistance Range Standard Overload (mΩ) Tolerance Coefficient Resistance Voltage (TCR; ppm/℃) Values (%) Min. Max. (mV) 754 ±1、±2、±5 ±200 40 91 ±100 100 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 E-24 FBF05 0805 1/4W 477 1067 ±1、±2、±5 FBF06 1206 1/3W 551 1232 ±1、±2、±5 FBF12 1210 2/3W 779 1742 ±1、±2、±5 FBF20 2010 3/4W 826 1847 ±1、±2、±5 FBF25 2512 1W 954 2133 ±1、±2、±5 Max. Max. RCWV Overload Resistance Temperature Resistance Range Standard (mΩ) Resistance Tolerance Coefficient Power Type Power Rating Type FBF03 Size 0603 at 70℃ 1/4W Voltage (mV) (mV) 477 1067 (%) ±1、±2、±5 FBF05 0805 1/2W 675 1508 ±1、±2、±5 FBF06 1206 3/4W 826 1847 ±1、±2、±5 FBF12 1210 3/4W 826 1847 ±1、±2、±5 FBF20 2010 1W 954 2133 ±1、±2、±5 FBF25 2512 2W 1349 3017 ±1、±2、±5 Prosperity Dielectrics Co., Ltd. 4/9 (TCR; ppm/℃) Min. Max. ±200 40 91 ±100 100 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 ±200 10 46 ±100 47 910 E-24 E-24 E-24 E-24 E-24 Values E-24 E-24 E-24 E-24 E-24 E-24 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors Note： 1. RCWV = (P×R)1/2 or Max. RCWV listed above, whichever is lower. RCWV：Rated Continue Working Voltage(V)，P：Rated Power(W)，R：Resistance Value(Ω) 2. Special resistance value request please contact factory. 6. Part Number Type FBF Size Tolerance 03 :0603 F :±1% 05 :0805 G :±2% 06 :1206 J :±5% Packing Paper Tape： Power R Value Code (GM) -: XXXX 0603.0805.1206 As Normal 4 digit 1210 Type Rating 12 :1210 T : 5Kpcs 20 :2010 V : 10Kpcs P: 25 :2512 W : 20Kpcs As Power Plastic Tape： Type Rating 2010.2512 P : 4Kpcs X : 8Kpcs Y : 16Kpcs Example： FBF06FT-R100 1206 size, tolerance 1%, paper tape, 100mΩ. 7. Marking/Soldering Resistance value identify： 0805/1206/1210/2010/2512 Top Marking. ( 4 Digits marking to identify the resistance value. ) R068 R068=68mΩ，R120=120mΩ 0603 Top Marking. ( 3 Digits marking to identify the resistance value. ) R12 R12=120mΩ，68M=68mΩ Prosperity Dielectrics Co., Ltd. 5/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors Soldering Reference： R12 Recommend Solder Pad Dimensions： Type W D L FBF03 0.90 1.00 3.00 FBF05 1.30 1.15 3.50 FBF06 1.80 1.30 4.70 FBF12 3.00 1.30 4.70 FBF20 3.00 1.50 6.80 FBF25 3.70 1.60 7.60 Prosperity Dielectrics Co., Ltd. Unit:mm 6/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors 8. Reliability Performance Test Item Specification DC Resistance F：±1% G：±2% Test Method IEC 60115-1 / JIS C 5201-1 , Clause 4.5 J：±5% Measure the resistance Value. Resistance to Solder Heat ∆R≦±(1%＋0.5mΩ) IEC 60115-1, Clause 4.18 F：∆R≦±(0.5%＋0.5mΩ) Solder dipping @ 260℃±5℃ for 10sec.±1sec. Solder Ability Over 95% of termination IEC 60115-1, Clause 4.17 must be covered with After immersing flux, dip in the Solder. 245±2℃ molten solder bath for 3±0.5 sec. No mechanical damage Short ∆R≦±(2%＋0.5mΩ) Time Overload F：∆R≦±(1%＋0.5mΩ) IEC 60115-1, Clause 4.13 5 × Rated power for 5 seconds Temperature Coefficient of Resistance (TCR) Within the spec. Load Life ∆R≦±(3%＋0.5mΩ) IEC 60115-1, Clause 4.25 F：∆R≦±(1%＋0.5mΩ) Rated voltage for 1.5 hours for followed IEC 60115-1, Clause 4.8 T1 T2 Test temperature： 25℃~ 155℃ TCR(ppm/℃) = (R2-R1)/R1×1 / (T2-T1)×106 by a pause 0.5 hour at 70±2℃. Cycle repeated 1000 hours. Bending strength ∆R≦ ±(1%＋0.5mΩ) IEC 60115-1 / JIS C 5201-1 ,Clause 4.33 F：∆R≦ ±(0.5%＋0.5mΩ) Resistance variance after bended on the 90mm No mechanical damage. PCB. Bending width：3mm for 0603 0805 2mm for 1206 2010 2512 Insulation Resistance Between termination and IEC 60115-1, Clause 4.6 coating must over 1000MΩ Test voltage：100±15V Prosperity Dielectrics Co., Ltd. 7/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors 9. PACKAGING 9.1 Peel Strength of Top Cover Tape The peel speed shall be about 300 mm/min The peel force of top cover tape shall between 0.1 to 0.7N 9.2 Tape Packaging Dimensions unit:mm Size A B W F E P1 P2 P0 D 0603 1.10±0.20 1.90±0.20 8.00±0.30 3.50±0.05 1.75±0.10 4.00±0.10 2.00±0.05 4.00±0.10 1.50+0.10/-0 0805 1.65±0.20 2.40±0.20 8.00±0.30 3.50±0.05 1.75±0.10 4.00±0.10 2.00±0.05 4.00±0.10 1.50+0.10/-0 1206 2.00±0.20 3.60±0.20 8.00±0.30 3.50±0.05 1.75±0.10 4.00±0.10 2.00±0.05 4.00±0.10 1.50+0.10/-0 1210 3.00±0.20 3.60±0.20 8.00±0.30 3.50±0.05 1.75±0.10 4.00±0.10 2.00±0.05 4.00±0.10 1.50+0.10/-0 2010 2.80±0.20 5.50±0.20 12.00±0.30 5.50±0.05 1.75±0.10 4.00±0.10 2.00±0.05 4.00±0.10 1.50+0.10/-0 2512 3.50±0.20 6.70±0.20 12.00±0.30 5.50±0.05 1.75±0.10 4.00±0.10 2.00±0.05 4.00±0.10 1.50+0.10/-0 Prosperity Dielectrics Co., Ltd. 8/9 FBF-REV.8.0.G38 PDC FBF series. (Metal Paste) Current Sensing Resistors Thick-film Chip Resistors 9.3 Reel Dimensions unit:mm Size 0603 0805 1206 1210 2010 2512 Packaging Q’ty A N C D B G T 5kpcs/Reel 178.0±2.0 60.0±0.5 13.0±0.5 20(Min.) 2.0±0.5 10.0±1.5 14.9max. 10kpcs/Reel 254.0±2.0 100.0±1.0 13.5±0.5 20(Min.) 2.0±0.5 10.0±1.5 14.9max. 20kpcs/Reel 330.0±2.0 100.0±1.0 13.5±0.5 20(Min.) 2.0±0.5 10.0±1.5 14.9max. 4kpcs/Reel 178.0±2.0 60.0±0.5 13.0±0.5 20(Min.) 2.0±0.5 13.8±1.5 16.7max. 8kpcs/Reel 254.0±2.0 100.0±0.5 13.5±0.5 20(Min.) 2.0±0.5 13.8±1.5 20.0max. 16kpcs/Reel 330.0±2.0 100.0±1.0 13.5±0.5 20(Min.) 2.0±0.5 13.8±1.5 20.0max. 10. Storage &. Handling … Products are recommended to be used up within one year as ensured shelf life. Check solder ability in case shelf life extension is needed. … To store products with following condition: Temperature:5 to 40℃；Humidity: 20 to 70% relative humidity. ※ All product specification and data are subject to change without notice. Prosperity Dielectrics Co., Ltd. 9/9 FBF-REV.8.0.G38 PDC
